Alpina Spare Parts for Lawn Mower AL3 46 G
€2.08
Tax included
Alpina Spare Parts for Lawn Mower AL3 46 G
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Lawn Mower AL3 46 G/295485040-A12-2016.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Lawn Mower AL3 46 G
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Lawn Mower AL3 46 G/295485040-A12-2016.
In the following table, look for the model of the Lawn Mower and the respective parts of the code.
| ALPINA Lawn Mower AL3 46 G/295485040-A12-2016 | ||
| Deck Pag.1 | ||
| # | Part Num. | Description |
| 1 | 381004018/0 | Red Deck |
| 1 | 381004024/0 | Black Deck |
| 2 | 322108301/1 | Front Conveyor Assy |
| 2 | 322108301/1 | Front Conveyor Assy |
| 3 | 112728699/0 | Screw |
| 4 | 322108302/0 | Rear Conveyor Assy |
| 5 | 112728699/0 | Screw |
| 6 | 322545213/0 | Plate |
| 7 | 381005139/0 | Left Bracket |
| 8 | 112727801/0 | Screw |
| 9 | 381005137/0 | Right Bracket |
| 10 | 322060242/0 | Belt Protection |
| 11 | 322140239/0 | Mulching Deflector Cruiser 48 |
| 12 | 112728530/0 | Screw |
| Height Adjusting Pag.2 | ||
| 1 | 322545189/0 | Plate |
| 2 | 322735597/1 | Sector, Height Adjustment L. |
| 2 | 322735597/1 | Sector, Height Adjustment |
| 3 | 381005141/0 | Wheel Support |
| 3 | 381005159/0 | Wheel Support |
| 4 | 381003354/0 | Lever, Height Adjustment |
| 5 | 122519811/0 | Pin |
| 6 | 112521350/0 | Washer |
| 7 | 112155000/0 | Nut |
| 8 | 322545211/0 | Plate |
| 9 | 322735595/0 | Sector, Height Adjustment L. |
| 9 | 322735595/1 | Sector, Height Adjustment |
| 10 | 381005143/0 | Wheel Support |
| 10 | 381005161/0 | Wheel Support |
| 11 | 381003442/0 | Lever, Height Adjustment |
| 12 | 322600247/0 | Whwwl Guard |
| Mask Pag.3 | ||
| 1 | 322226170/0 | Mask, Black |
| 2 | 112728698/0 | Screw |
| Handle, Lower Part Pag.4 | ||
| 1 | 381006737/0 | Handle Lower Part |
| 2 | 112819110/0 | Screw |
| 2 | 112819120/0 | Screw |
| 3 | 122671651/0 | Washer |
| 3 | 122680006/1 | Washer |
| 4 | 122399900/0 | Knob |
| 5 | 112293200/0 | Nut |
| 7 | 112818900/0 | Screw |
| 9 | 122399900/0 | Knob |
| 10 | 112293200/0 | Nut |
| 11 | 112155000/0 | Nut |
| 12 | 112521350/0 | Washer |
| 13 | 112369500/0 | Elastic Washer |
| 14 | 112760605/0 | Screw |
| 15 | 381008691/0 | Out t, Screws |
| Handle, Upper Part Pag.5 | ||
| 1 | 381006739/1 | Handle, Upper Part |
| 1 | 381006745/1 | Handle, Upper Part with sponge handgrip |
| 1 | 381006739/2 | Manico, Parte Superiore |
| 1 | 381006745/0 | Manico, Parte Sup. Con Impugantura In Spugna |
| 1 | 381006745/1 | Manico, Parte Sup. con impugantura in spugna |
| 1 | 381006745/2 | Manico, Parte Sup. con impugantura in spugna |
| 2 | 122430313/0 | Guide Spring |
| 3 | 112521330/0 | Washer |
| 4 | 112154510/0 | Nut |
| 5 | 118390020/0 | Cable Clip |
| 6 | 181003363/0 | Lever, Engine Brake Black |
| 6 | 181003363/1 | Leva Freno Motore Nero |
| 7 | 181030056/0 | Cable, Thread Engine Brake |
| 8 | 112727783/0 | Screw |
| 9 | 112154510/0 | Nut |
| 12 | 322551640/0 | Plate |
| Wheels and Hub Caps Pag.6 | ||
| 1 | 381007448/0 | Wheel |
| 1 | 381007448/1 | Ruota - Short Lungo |
| 2 | 119216035/0 | Bearing |
| 3 | 322110687/0 | Hub Cap Grey |
| 5 | 381007449/0 | Wheel |
| 5 | 381007449/1 | Wheel |
| 6 | 119216035/0 | Bearing |
| 9 | 322110689/0 | Hub Cap Grey |
| Blade Pag.7 | ||
| 1 | 112735109/2 | Screw |
| 2 | 122463012/2 | Blade Boss Ø 22.2 |
| 3 | 181004346/3 | Blade |
| 3 | 181004460/0 | Blade Mulching |
| 4 | 112523080/0 | Washer M 10 |
| 4 | 322680021/0 | Washer |
| 5 | 112508125/0 | Spring Washer |
| 6 | 112735698/0 | Screw |
| 7 | 112139100/0 | Key |
| 8 | 112154210/0 | Nut |
| Grass-Catcher Pag.8 | ||
| 1 | 322785331/0 | Supporto Fulcro Parasassi Nero |
| 2 | 122450464/0 | Molla |
| 3 | 322109554/0 | Copertura Parasassi, Nero |
| 3 | 322109556/0 | Copertura Parasassi, Giallo |
| 4 | 112728699/0 | Vite |
| 5 | 322600206/1 | Parasassi Nero |
| 5 | 322600214/1 | Parasassi Giallo |
| 5 | 322600216/1 | Parasassi Grigio |
| 6 | 322393644/0 | Maniglia Sacco Nera |
| 6 | 322393646/0 | Maniglia Giallo |
| 6 | 322393715/0 | Maniglia Sacco Grigia |
| 7 | 381486016/0A | Sacco, Parte Superiore Giallo |
| 7 | 381486018/0 | Sacco, Parte Superiore Nero |
| 7 | 381486029/0 | Sacco, Parte Superiore Grigio |
| 8 | 122608561/0 | Rinforzo Inf |
| 9 | 112728692/0 | Vite |
| 10 | 322545159/0 | Piastrina |
| 11 | 181002318/0 | Sacco, Tela |
| Engine - GGP RV100 Pag.9 | ||
| 1 | 118550693/0 | Starter Assy Cover |
| 2 | 118550694/0 | Starter Handle |
| 4 | 118550695/0 | Starter Pulley + Spring |
| 5 | 118550696/0 | Starter Pawl Set |
| 6 | 118550713/0 | Screw |
| 7 | 118550714/0 | Screw |
| 8 | 112689515/0 | Screw |
| 9 | 118550712/0 | Fuel Tank |
| 10 | 118550711/0 | Fuel Cap |
| 11 | 118550715/0 | Fuel Filter |
| 12 | 118550716/0 | Fuel Pipe |
| 13 | 118550697/0 | Carburetor |
| 14 | 118550706/0 | Screw |
| 15 | 112292102/0 | Nut |
| 16 | 118550702/0 | Air Cleaner Assy |
| 17 | 118550704/0 | Air Filter |
| 18 | 118550703/0 | Air Cleaner Cover |
| 19 | 118550698/0 | Air Purge Pump |
| 20 | 118550705/0 | Breather Fule Pipe |
| 21 | 112292102/0 | Nut |
| 21 | 112292102/0 | Nut |
| 22 | 118550710/0 | Screw |
| 23 | 112735699/0 | Screw |
| 24 | 118550709/0 | Muffler Guard |
| 25 | 118550708/0 | Muffler |
| 26 | 118550707/0 | Muffler Gasket |
| 31 | 118550719/0 | Electronic Coil |
| 32 | 112792099/0 | Screw |
| 33 | 118550658/0 | Spark Plug K7RTC |
| 35 | 118550720/0 | Spring |
| 36 | 118550721/0 | Governor Link |
| 38 | 118550732/0 | Engine Assembled |
| 98 | 322055521/0 | Cappottina |
| 99 | 322055518/0 | Cuffia, Gialla |
| 99 | 381002079/0 | Ass. Cappottina Nera (pos. 98+99) |
| Motore - Pistone, Albero Motore Pag.10 | ||
| 39 | 118550728/0 | Brake assy |
| 40 | 118550727/0 | Spring |
| 41 | 118550717/0 | Nut |
| 42 | 118550718/0 | Flywheel Ass.Y |
| 43 | 118550661/0 | Oil Seal |
| 44 | 118550729/0 | Cylinder Head Assy |
| 45 | 112735699/0 | Screw |
| 46 | 118550659/0 | Cover |
| 47 | 118550733/0 | Gasket, Breath Groove |
| 48 | 118550660/0 | Oil Filter |
| 49 | 118550680/0 | Gasket |
| 50 | 118550681/0 | Cover Comp., Head |
| 51 | 112735699/0 | Screw |
| 52 | 112791500/0 | Screw |
| 53 | 118550672/0 | Crankase Cover Assy |
| 54 | 118550668/0 | Oil Seal |
| 55 | 118550669/0 | Tank Cap |
| 56 | 118550670/0 | O-Ring |
| 57 | 118550664/0 | Pin |
| 61 | 118550674/0 | Crankshaft |
| 62 | 118550673/0 | Washer |
| 63 | 118550675/0 | Connecting Rod Assy |
| 64 | 118550678/0 | Circlip + Piston Pin |
| 65 | 118550677/0 | Piston Assy |
| 66 | 118550679/0 | Piston, Ring Set |
| 67 | 118550682/0 | Camshaft assy |
| 68 | 112735699/0 | Screw |
| 69 | 118550662/0 | Speed Governor Assy |
| 70 | 118550665/0 | Shaft, Governor Arm |
| 71 | 118550666/0 | Washer |
| 72 | 118550671/0 | Gasket |
| 73 | 118550723/0 | Support Governor |
| 74 | 118550726/0 | Screw |
| 75 | 118550722/0 | Nut |
| 76 | 118550667/0 | Cotter Pin |
| 77 | 118550683/0 | Valve Lifter |
| 78 | 118550684/0 | Push Rods |
| 79 | 118550685/0 | Plate |
| 80 | 118550686/0 | Screw |
| 81 | 118550687/0 | Valve Arm |
| 82 | 118550688/0 | Nut |
| 83 | 118550689/0 | Nut |
| 85 | 118550724/0 | Plate |
| 86 | 112735699/0 | Screw |
| 87 | 118550725/0 | Spring |
| 89 | 112791500/0 | Screw |
| 90 | 112735699/0 | Screw |
| 91 | 118550692/0 | Exhaust Valve Assy |
| 92 | 118550691/0 | Intake Valve Assy |
| 93 | 118550690/0 | Spring |
| 94 | 118550699/0 | Carburettor Gasket Set |
| 95 | 118550731/0 | Cylinder Head Gasket Set |
| 96 | 118550730/0 | Engine Gasket Set |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
