Alpina Spare Parts for Brushcutter TB 420
€2.43
Tax included
Alpina Spare Parts for Brushcutter TB 420
Alpina riginal spare parts at attractive prices never seen on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Brushcutter TB 420 - 286320000-13-2017.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter TB 420
Fix Your Brushcutter TB 420 - 286320000-13-2017. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Brushcutter TB 420/286320000-13-2017 Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118801189/0 | Screw |
| 2 | 118801181/0 | Clutch Ass.Y |
| 3 | 2321230 | Washer |
| 4 | 2135030 | Screw |
| 5 | 118801214/0 | Transmission Support Case |
| 6 | 2670120 | Nut |
| 7 | 118801211/0 | Flywheel Ass.Y |
| 8 | 118801209/0 | Electronic Coil |
| 9 | 2135050 | Screw |
| 10 | 118801217/0 | Crank Case |
| 11 | 118801212/0 | Fuel Tank |
| 12 | 118801392/0 | Fuel Pipe Set |
| 13 | 118801393/0 | Fuel Cap Assy |
| 14 | 118801207/0 | Support |
| 15 | 118801197/0 | Seal Ring |
| 16 | 3112040 | Ball Bearing |
| 17 | 118801213/0 | Crankshaft |
| 18 | 123072002/0 | Flywheel Key |
| 19 | 118801201/0 | Crankcase Gasket |
| 20 | 118801218/0 | Crank Case |
| 21 | 118801191/0 | Starter Cup Ass.Y |
| 22 | 118801193/0 | Gasket |
| 23 | 118801186/0 | Starter Assy |
| 24 | 118802161/0 | Starter Handle |
| 25 | 118802162/0 | Starter Pulley |
| 26 | 118802163/0 | Starter Spring |
| 27 | 118801195/0 | Needle Bearing |
| 28 | 118801196/0 | Circlip |
| 29 | 118801199/0 | Piston Pin |
| 30 | 118801216/0 | Piston |
| 31 | 118801198/0 | Piston Ring |
| 32 | 118801202/0 | Cylinder Gasket |
| 33 | 118801215/0 | Cylinder |
| 34 | 3210024 | Spark Plug |
| 35 | 118802115/0 | Black Cylinder Cover |
| 36 | 118801221/0 | Muffler Gasket |
| 37 | 118801222/0 | Muffler |
| 38 | 118801219/0 | Muffler Guard |
| 39 | 2135180 | Screw |
| 40 | 118801180/0 | Screw |
| 41 | 123878020/0 | Screw |
| 42 | 2135040 | Screw |
| 43 | 118801204/0 | Intake Manifold Gasket |
| 44 | 118801200/0 | Intake Manifold |
| 45 | 2135060 | Screw |
| 46 | 118801203/0 | Intake-Carb Gasket |
| 47 | 118801208/0 | Carburetor |
| 48 | 118802159/0 | Air Filter Assy Yellow |
| 49 | 118801525/0 | Deflector |
| 50 | 118801526/0 | Air Filter |
| 51 | 118802110/0 | Plate |
| 52 | 118802160/0 | Air Cleaner Cover,Yellow |
| 53 | 118801528/0 | Knob |
| 54 | 118801192/0 | Rubber Gasket |
| 55 | 118801188/0 | Seal Ring |
| 56 | 2312020 | Washer |
| 57 | 2330020 | Washer |
| 58 | 2122210 | Screw |
| Brushcutter TB 420/286320000-13-2017 Trasmission Pag.2 | ||
| 1 | 118801187/0 | Support Transmission Assy |
| 2 | 118801398/0 | Drum Ass'Y, Clutch |
| 3 | 2135180 | Screw |
| 4 | 2132180 | Screw |
| 5 | 118802055/0 | Transmission Tube |
| 6 | 118801190/0 | Transmission Drive Shaft Assy |
| 7 | 118802103/0 | Handle Assy |
| 8 | 112154320/0 | Nut |
| 9 | 118802104/0 | Spring |
| 10 | 118802105/0 | Trigger |
| 11 | 118802106/0 | Safety Lever |
| 12 | 2135060 | Screw |
| 13 | 118802107/0 | Switch |
| 14 | 112728099/1 | Screw |
| 15 | 118802088/0 | Retainer |
| 16 | 118802108/0 | Stop Wire |
| 17 | 118802109/0 | Throttle Cable |
| 18 | 112727815/0 | Screw |
| 19 | 112727790/0 | Screw |
| 20 | 118802054/0 | Harness Support |
| 21 | 112154320/0 | Nut |
| 22 | 118802102/0 | Front Handgrip Assy |
| 23 | 2135130 | Screw |
| 24 | 112154320/0 | Nut |
| 31 | 118801184/0 | Gear Case Assy |
| 32 | 118801125/0 | 3 Teeth Disc |
| 33 | 118801124/0 | 2 Hedges Nylon Head |
| 34 | 118802056/0 | Harness |
| 45 | 118803203/0 | Spacer |
| 46 | 118803204/0 | Upper Ring Nut |
| 47 | 118803205/0 | Lower Ring Nut |
| 48 | 118803206/0 | Case Dust Cover |
| 49 | 2452090 | Nut |
| 50 | 118803198/0 | Safety Cover Ass.Y |
| 51 | 118803199/0 | Safety Cover, Grey |
| 52 | 2123050 | Screw |
| 53 | 118803200/0 | Plate |
| 54 | 112727799/0 | Screw |
| 55 | 2122260 | Screw |
| 56 | 118804056/0 | Line Cutter Blade |
| 57 | 118803202/0 | Support |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Alpina TB420 - 286320000
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
