Alpina Spare Parts for Brushcutter TB 250 J
€1.11
Tax included
Alpina Spare Parts for Brushcutter TB 250 J
We are Dealers of ALPINA original spare parts at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Brushcutter TB 250 J/286120100-13-2017.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter TB 250 J
We are Dealers of ALPINA original spare parts at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Brushcutter TB 250 J/286120100-13-2017.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Brushcutter TB 250 J/286120100-13-2017 Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118802113/0 | Clutch Ass'y |
| 2 | 2312010 | Flat washer |
| 3 | 2135030 | Screw |
| 4 | 118802080/0 | Transmission Support Case |
| 5 | 112293202/0 | Nut |
| 6 | 112583500/0 | Grower |
| 7 | 112521350/0 | Washer |
| 8 | 118802073/0 | Flywheel |
| 9 | 2135050 | Screw |
| 11 | 118802078/0 | Crank Case |
| 12 | 118802072/0 | Ignition Coil |
| 13 | 118801188/0 | Seal Ring |
| 14 | 119216035/0 | Bearing |
| 15 | 118802066/0 | Crankshaft |
| 16 | 123072002/0 | Flywheel Key |
| 17 | 118802090/0 | Crankcase Gasket |
| 18 | 118802079/0 | Crank Case |
| 19 | 118802069/0 | Starter Cup |
| 20 | 118802068/0 | Starter Assy Yellow |
| 21 | 118802156/0 | Starter Handle |
| 22 | 118802157/0 | Starter Pulley |
| 23 | 118802158/0 | Starter Spring |
| 24 | 118802087/0 | Grommet |
| 25 | 118802083/0 | Tank Protection |
| 26 | 123878008/0 | Screw |
| 27 | 118802075/0 | Needle Bearing |
| 28 | 118802084/0 | Circlip |
| 29 | 118802081/0 | Piston Pin |
| 30 | 118802076/0 | Piston |
| 31 | 118802077/0 | Piston Ring |
| 32 | 118802091/0 | Cylinder Gasket |
| 33 | 118802074/0 | Cylinder |
| 34 | 2135060 | Screw |
| 35 | 3210024 | Spark Plug CJ7Y |
| 36 | 118802085/0 | Black Cylinder Cover |
| 37 | 112523020/0 | Washer |
| 38 | 2135040 | Screw |
| 39 | 123878020/0 | Screw |
| 40 | 2135250 | Screw |
| 41 | 2330020 | Washer |
| 42 | 2312020 | Washer |
| 43 | 118802082/0 | Muffler Guard |
| 44 | 118802067/0 | Muffler |
| 45 | 118802093/0 | Muffler Gasket |
| 46 | 118802092/0 | Intake Manifold Gasket |
| 47 | 118802086/0 | Intake Manifold |
| 48 | 118802089/0 | Carburetor Gasket |
| 49 | 118802071/0 | Carburetor |
| 50 | 118801194/0 | Air Filter Assy |
| 51 | 118801525/0 | Deflector |
| 52 | 118801526/0 | Air Filter |
| 53 | 118802110/0 | Plate |
| 54 | 118802111/0 | Air Cleaner Cover, Black |
| 55 | 118801528/0 | Knob |
| 57 | 118802070/0 | Fuel Tank Assy |
| 58 | 118802096/0 | Fuel Pipe |
| 59 | 118802097/0 | Fuel Cap Assy |
| Brushcutter TB 250 J/286120100-13-2017 Trasmission Pag.2 | ||
| 1 | 118802062/0 | Support Transmission Assy |
| 2 | 118802094/0 | Clutch Drum |
| 3 | 2132180 | Screw |
| 4 | 2135180 | Screw |
| 5 | 2135060 | Screw |
| 6 | 118802101/0 | Transmission Tube |
| 7 | 118802057/0 | Trasmission Shaft >> 118805345/0 |
| 8 | 118802059/0 | Shaft + Connector >> 118805345/0 |
| 9 | 118802099/0 | Connector Assy |
| 10 | 118802112/0 | Transmission Tube |
| 11 | 118802058/0 | Trasmission Shaft |
| 12 | 118802103/0 | Handle Assy |
| 13 | 118802104/0 | Spring |
| 14 | 118802105/0 | Trigger |
| 15 | 118802106/0 | Safety Lever |
| 16 | 2135060 | Screw |
| 17 | 118802107/0 | Switch |
| 18 | 112728099/1 | Screw |
| 19 | 118802088/0 | Retainer |
| 20 | 118802108/0 | Stop Wire |
| 21 | 118802109/0 | Throttle Cable |
| 22 | 112727815/0 | Screw |
| 23 | 118802054/0 | Harness Support |
| 24 | 112154320/0 | Nut |
| 25 | 2135020 | Screw |
| 26 | 118802102/0 | Front Handgrip Assy |
| 27 | 2135130 | Screw |
| 28 | 112154320/0 | Nut |
| 36 | 2132180 | Screw |
| 37 | 118801184/0 | Gear Case Assy |
| 38 | 118801125/0 | 3 Teeth Disc |
| 39 | 118801124/0 | 2 Hedges Nylon Head |
| 40 | 118802056/0 | Harness |
| 41 | 112154320/0 | Nut |
| 45 | 118803203/0 | Spacer |
| 46 | 118803204/0 | Upper Ring Nut |
| 47 | 118803205/0 | Lower Ring Nut |
| 48 | 118803206/0 | Case Dust Cover |
| 49 | 2452090 | Nut |
| 50 | 118803198/0 | Safety Cover Ass.Y |
| 51 | 118803199/0 | Safety Cover, Grey |
| 52 | 2123050 | Screw |
| 53 | 118803200/0 | Plate |
| 54 | 112727799/0 | Screw |
| 55 | 2122260 | Screw |
| 56 | 118803201/0 | Line Cutter Blade |
| 57 | 118803202/0 | Support |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
