Alpina Spare Parts for Brushcutter TB 320
€1.11
Tax included
Alpina Spare Parts for Brushcutter TB 320
ALPINA authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter TB 320 - 286220000-13-2017.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter TB 320
ALPINA authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter TB 320 - 286220000-13-2017.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Brush Cutter TB 320/286220000-13-2017 Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118801189/0 | Screw |
| 2 | 118801181/0 | Clutch Ass.Y |
| 3 | 2321230 | Washer |
| 4 | 2135030 | Screw |
| 5 | 118801503/0 | Transmission Support Case |
| 6 | 2670120 | Nut |
| 7 | 118801504/0 | Flywheel |
| 8 | 118801505/0 | Electronic Coil |
| 9 | 2135050 | Screw |
| 10 | 118801506/0 | Crank Case |
| 11 | 118801188/0 | Seal Ring |
| 12 | 3112030 | Ball Bearing |
| 13 | 118801507/0 | Crankcase Gasket |
| 14 | 118801508/0 | Crankshaft |
| 15 | 123072002/0 | Flywheel Key |
| 16 | 118801509/0 | Crank Case |
| 17 | 118801191/0 | Starter Cup Ass.Y |
| 18 | 118801510/0 | Needle Bearing |
| 19 | 118801511/0 | Piston |
| 20 | 118801512/0 | Piston Pin |
| 21 | 118801513/0 | Circlip |
| 22 | 118801514/0 | Piston Ring |
| 23 | 118801515/0 | Cylinder Gasket |
| 24 | 118801516/0 | Cylinder |
| 25 | 118801517/0 | Muffler Gasket |
| 26 | 118801518/0 | Muffler |
| 27 | 118801519/0 | Muffler Guard |
| 28 | 2135180 | Screw |
| 29 | 118801520/0 | Intake Manifold Gasket |
| 30 | 118801521/0 | Intake Manifold |
| 31 | 118801522/0 | Carburetor Gasket |
| 32 | 118801523/0 | Carburetor |
| 33 | 118802159/0 | Air Filter Assy Yellow |
| 34 | 118801525/0 | Deflector |
| 35 | 118801526/0 | Air Filter |
| 36 | 118802110/0 | Plate |
| 37 | 118802160/0 | Air Cleaner Cover,Yellow |
| 38 | 118801528/0 | Knob |
| 40 | 118801529/0 | Fuel Tank Assy |
| 41 | 118801392/0 | Fuel Pipe |
| 42 | 118801393/0 | Fuel Cap Assy |
| 43 | 118801193/0 | Gasket |
| 44 | 118801186/0 | Starter Assy |
| 45 | 118802161/0 | Starter Handle |
| 46 | 118802162/0 | Starter Pulley |
| 47 | 118802163/0 | Starter Spring |
| 48 | 118801207/0 | Support |
| 49 | 118801192/0 | Rubber Gasket |
| 50 | 118802116/0 | Black Cylinder Cover |
| 51 | 2135040 | Screw |
| 52 | 123878020/0 | Screw |
| 53 | 2312020 | Washer |
| 54 | 2330020 | Washer |
| 55 | 2135250 | Screw |
| 56 | 3210024 | Spark Plug |
| Brush Cutter TB 320/286220000-13-2017 Trasmission Pag.2 | ||
| 1 | 118801187/0 | Support Transmission Assy |
| 2 | 118801398/0 | Drum Ass'Y, Clutch |
| 3 | 2135180 | Screw |
| 4 | 2132180 | Screw |
| 5 | 118802055/0 | Transmission Tube |
| 6 | 118801190/0 | Transmission Drive Shaft Assy |
| 7 | 118802103/0 | Handle Assy |
| 8 | 112154320/0 | Nut |
| 9 | 118802104/0 | Spring |
| 10 | 118802105/0 | Trigger |
| 11 | 118802106/0 | Safety Lever |
| 12 | 2135060 | Screw |
| 13 | 118802107/0 | Switch |
| 14 | 112728099/1 | Screw |
| 15 | 118802088/0 | Retainer |
| 16 | 118802108/0 | Stop Wire |
| 17 | 118802109/0 | Throttle Cable |
| 18 | 112727815/0 | Screw |
| 19 | 112727790/0 | Screw |
| 20 | 118802054/0 | Harness Support |
| 21 | 112154320/0 | Nut |
| 22 | 118802102/0 | Front Handgrip Assy |
| 23 | 2135130 | Screw |
| 24 | 112154320/0 | Nut |
| 31 | 118801184/0 | Gear Case Assy |
| 32 | 118801125/0 | 3 Teeth Disc |
| 33 | 118801124/0 | 2 Hedges Nylon Head |
| 34 | 118802056/0 | Harness |
| 45 | 118803203/0 | Spacer |
| 46 | 118803204/0 | Upper Ring Nut |
| 47 | 118803205/0 | Lower Ring Nut |
| 48 | 118803206/0 | Case Dust Cover |
| 49 | 2452090 | Nut |
| 50 | 118803198/0 | Safety Cover Ass.Y |
| 51 | 118803199/0 | Safety Cover, Grey |
| 52 | 2123050 | Screw |
| 53 | 118803200/0 | Plate |
| 54 | 112727799/0 | Screw |
| 55 | 2122260 | Screw |
| 56 | 118804056/0 | Line Cutter Blade |
| 57 | 118803202/0 | Support |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Alpina TB320 286220000-13-2017
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
