AGP Europe Spare Parts for Concrete Grinder G125
€105.69
Tax included
AGP Europe Spare Parts for Concrete Grinder G125
We have the original Spares AGP Europe Spare Parts for Concrete Grinder G125 the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Concrete Grinder G125. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
AGP Europe Spare Parts for Concrete Grinder G125
We have the original Spares AGP Europe Spare Parts for Concrete Grinder G125 the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Concrete Grinder G125. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Concrete Grinderl and the respective parts of the code.
| MODEL : G125 High Endurance Concrete Grinder (AGP Europe) Version 2.2 | ||
| NO. | Code | Parts Name |
| 1.) | 206-031502350-02 | POWER SUPPLY CABLE (VDE-1.5x2Cx3.5M-H07RNF) |
| 2.) | 203-0004-00000-001 | CORD ARMOR |
| 3.) | 403-M04014003-020 | PANHEAD TAPPING SCREW-B (M4x14) |
| 4.) | 303-01003-004-001 | CABLE CLIP |
| 5.) | 303-01065-004-012 | HANDLE HALF-RIGHT (BLACK) |
| 6.) | 303-01340-004-002 | CARBON CAP (BLACK) |
| 7.) | 403-M04012003-080 | PANHEAD TAPPING SCREW-B (M4x12) |
| 8.) | 303-01066-004-012 | HANDLE HALF-LEFT (BLACK) |
| 9.) | 403-M05045003-021 | PANHEAD TAPPING SCREW-B-W/WASHER (M5x45) |
| 10.) | 403-M04020001-080 | PANHEAD TAPPING SCREW-A (M4x20) |
| 11.) | 203-0010-00100-006 | THUMB WHEEL (ORANGE-021C) |
| 12.) | 304-04004-000-025 | RHEOSTAT |
| 13.) | 402-M04030003-020 | PANHEAD TAPPING SCREW-B-W/WASHER (M4x30) |
| 14.) | 204-0021-20000-033 | ELECTRONICS UNIT (220V) |
| 15.) | 302-04009-000-004 | BRUSH SPRING (0.4x4x3T) |
| 16.) | 307-02004-000-004 | CARBON BRUSH HOLDER (7x17) |
| 17.) | 305-00001-000-031 | CARBON BRUSH (7x17x19)(220V) |
| 18.) | 407-M04006070-050 | PANHEAD MACHINE SCREW (M4x6xP0.7) |
| 19.) | 303-01303-005-002 | INSULATION PLATE (10x38x1) |
| 20.) | N/A | |
| 21.) | 0299-0135-00000-003 | LED INDICATOR LIGHT |
| 22.) | 303-01251-026-044 | MOTOR HOUSING (GRAY-RAL7016) |
| 23.) | 299-0002-20000-155 | STATOR (220V-81x46.4x55) |
| 24.) | 403-M05070001-020 | PANHEAD TAPPING SCREW-B (M5x70) |
| 25.) | 407-M04010070-050 | PANHEAD MACHINE SCREW (M4x10xP0.7) |
| 26.) | 424-041010-10 | FLAT WASHER (Ø4xØ10x1) |
| 27.) | 432-M04000-00 | RUBBER WASHER (Ø4xØ11x1) |
| 28.) | 302-01007-000-002 | PICKUP MAGNET (Ø8xØ15x5) |
| 29.) | 302-04018-901-001 | SPACER (Ø8xØ12x10.5) |
| 30.) | 302-05514-000-008 | BALL BEARING (6200) |
| 31.) | 299-0001-20000-171 | ARMATURE (220V-81x46.4x55) |
| 32.) | 303-01057-004-031 | FAN BAFFLE (BLACK) |
| 33.) | 302-05515-000-002 | BALL BEARING (6201) |
| 34.) | 303-02002-004-035 | OIL SEAL (Ø12xØ22x7) |
| 35.) | 302-06018-000-012 | BEVEL PINION GEAR (M1.5x11T) |
| 36.) | 201-0002-00001-108 | GEAR HOUSING (SILVER) |
| 37.) | 203-0018-00004-002 | SPINDLE LOCK BUTTON (BLACK) |
| 38.) | 302-04026-901-082 | SPRING (Ø0.9xØ7.4xØ9.2x5Tx16L) |
| 39.) | 302-04119-907-003 | ARBOR LOCK |
| 40.) | 303-02009-004-099 | O-RING (Ø5x1) |
| 41.) | 425-050000-00 | SPRING WASHER (M5) |
| 42.) | 403-M05030002-050 | PANHEAD TAPPING SCREW-B (M5x30) |
| 43.) | 302-05107-000-003 | NEEDLE BEARING (HK 1010) |
| 44.) | 302-06015-000-025 | BEVEL GEAR (M1.5x37T) |
| 45.) | 303-02009-004-098 | O-RING (Ø72x2) |
| 46.) | 303-02002-004-045 | OIL SEAL (Ø15xØ24x5) |
| 47.) | 201-0003-00001-070 | GEAR PLATE (SILVER) |
| 48.) | 422-S17-0 | EXTERNAL CIRCLIP (S-17) |
| 49.) | 302-05523-000-002 | BALL BEARING (6303) |
| 50.) | 425-040000-00 | SPRING WASHER (M4) |
| 51.) | 406-M04020070-080 | SOCKET CAP SCREW (M4x20xP0.7) |
| 52.) | 421-05015-00 | PARALLEL KEY (5x5x15) |
| 53.) | 302-04003-000-174 | SPINDLE (M14xP2.0-112.1MM) |
| 54.) | 303-02002-004-053 | OIL SEAL (Ø24xØ32x4) |
| 55.) | N/A | |
| 56.) | 406-M04010070-160 | SOCKET CAP SCREW (M4x10xP0.7) |
| 57.) | 413-M04010003-020 | FLAT HEAD TAPPING SCREW-B (M4x10) |
| 58.) | 303-01300-004-001 | COVER PANEL (BLACK) |
| 59.) | 403-M04014003-160 | PANHEAD TAPPING SCREW-B (M4x14) |
| 60.) | 303-01331-164-001 | HALF-MOON DOOR (RED-187C) |
| 61.) | 203-0112-00004-005 | BRUSH-SMALL (BLACK) |
| 62.) | 302-04026-000-010 | SPRING (Ø0.55xØ4.9xØ6x15Lx6T) |
| 63.) | 403-M04010003-160 | PANHEAD TAPPING SCREW-B (M4x10) |
| 64.) | 303-01081-004-007 | DUST SKIRT (BLACK) |
| 65.) | 203-0112-00004-006 | CLEANING BRUSH (BLACK) |
| 66.) | 202-0145-00901-001 | SHOULDER BOLT (M4xP0.7x26L) |
| 67.) | 302-04222-903-008 | INNER FLANGE (Ø22.2 / Ø25.4) |
| 68.) | 302-04114-901-004 | OUTER FLANGE (M14) |
| 69.) | 401-M08130125-080 | HEX BOLT (M8x130xP1.25) |
| 70.) | 303-01393-004-001 | CLAMPING KNOB |
| 71.) | 303-01392-004-001 | CLAMPING SLEEVE |
| 72.) | 303-01391-004-001 | FRONT HANDLE |
| 73.) | 410-M08000125-080 | HEX NUT (M8) |
| 74.) | 305-00039-901-001 | LOCK NUT WRENCH (30MM) |
| 75.) | 302-04171-000-001 | SPRING (Ø0.8 x Ø6.4 x Ø8 x 9T x 26L) |
| 76.) | 302-04179-901-002 | FACE SPANNER WRENCH (78MM) |
| 77.) | 204-0025-00000-002 | HALL EFFECT SWITCH |
| 78.) | 302-03182-903-005 | BEARING PLATE |
| 79.) | 403-M04008003-020 | PANHEAD TAPPING SCREW-B (M4x8) |
| 80.) | 303-02009-004-071 | O-RING (Ø32x1.5) |
| 81.) | N/A | |
| 82.) | 0299-0014-00004-019 | SWITCH ACTUATOR (BLACK)(LOCK-ON) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s AGP Europe websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to AGP Europe brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
G125 Version 2.2
