Makita Pruning Shear DUP362 Spare Parts

€1.47
Tax included

Makita Pruning Shear DUP362 Spare Parts

Makita original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Pruning Shear DUP362.
ITEM CODE: 251490-2
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Pruning Shear DUP362 Spare Parts

Makita original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Pruning Shear DUP362.

In the following table, look for the model of the Prining Scissor and the respective parts of the code.
Pruning Shear DUP362

Makita DUP362 BATTERY POWERED PRUNING SHEAR
# Parts No. Description
1 251490-2 H.S.H.BOLT M5X14 WITH WR
2 855F93-6 DUP362 NAME PLATE
3 456209-6 UPPER HOUSING
5 251474-0 SHOULDER SCREW M8
6 199168-8 SHEAR BLADE U SET
7 199169-6 SHEAR BLADE L SET
8 213034-6 O RING 3
9 346940-1 LOCK PLATE
10 266557-3 H.S.BUTTON HEAD BOLT M3X8
11 264118-3 HEX. NUT M8
12 266786-8 + PAN HEAD TAPPING SCREW 2X10
13 456218-5 BALL NUT COVER B
14 961011-9 STOP RING E-4
15 347165-0 LINK ARM
16 256568-6 FLAT FILLISTER HD.PIN 5
17 251484-7 + FLAT HEAD SCREW M3X4
18 456215-1 LEVER
19 216031-1 STEEL BALL 2.3
20 233491-2 COMPRESSION SPRING 2
21 688189-0 MAGNET
22 266999-1 H.S.SET SCREW(FLAT POINT)M3X4
23 231397-8 COMPRESSION SPRING 4
24 123536-3 TRIGGER ASS'Y
25 456217-7 BALL NUT COVER A
26 127142-6 BALL SCREW ASSEMBLY
27 912012-0 C.H.SCREW M3X10
28 226866-2 INTERNAL GEAR 49
29 226865-4 SPUR GEAR 19
30 253810-6 FLAT WASHER 12
31 911006-2 PAN HEAD SCREW M3X8
32 319349-0 MOTOR HOLDER
33 629397-4 DC MOTOR
34 620459-1 SUB CONTROLLER
35 456211-9 LOWER HOUSING
36 911028-2 PAN HEAD SCREW M3X16
37 143935-3 FRONT HOUSING COMPLETE
37 807L80-7 INDICATION LABEL
38 266980-2 HEX.S.BUTTON HEAD SCREW M3X16
41 183B69-2 CONTROLLER HOUSING SET
42 232267-4 LEAF SPRING
43 687053-2 STRAIN RELIEF
44 265995-6 TAPPING SCREW 4X1
45 643899-6 TERMINAL
46 620461-4 RF UNIT
47 620458-3 CONTROLLER
48 183B69-2 CONTROLLER HOUSING SET
49 265995-6 TAPPING SCREW 4X18
50 183B76-5 SWITCH HOUSING SET
50 807E89-7 INDICATION LABEL
50 807F74-6 CAUTION LABEL
51 699086-5 POWER SUPPLY CORD UNIT
52 687053-2 STRAIN RELIEF
53 265995-6 TAPPING SCREW 4X18
54 651536-8 SWITCH 1941. 1451
55 620460-6 LED CIRCUIT
56 183B76-5 SWITCH HOUSING SET
56 807E89-7 INDICATION LABEL
56 807F74-6 CAUTION LABEL
57 266429-2 TAPPING SCREW 3X16
58 266786-8 + PAN HEAD TAPPING SCREW 2X10
59 855F95-2 DUP362 SERIAL NO. LABEL
60 630999-1 CONTROLLER
A01 154511-8 CORD HOLDER COMPLETE
A02 161603-6 HARNESS
A03 161379-5 HOLSTER
A04 166062-9 ARM BAND
A05 182470-6 OIL SUPPLY
A06 661445-3 CONNECTION CORD
A07 794530-8 DIAMOND FILE 140
A08 782212-4 SOCKET WRENCH 13
A09 783021-4 HEX. WRENCH 1.5
A10 783202-0 HEX. WRENCH 4
A11 783214-3 HEX.SOCKET SCREW KEY 2
A12 831284-7 TOOL BAG
A17 199168-8 SHEAR BLADE U SET
