Telwin Spare Parts for Flux and MIG-MAG Welding Bimax 162 Turbo
TELWIN authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for welding machine Flux and Mig-mag Bimax 162 Turbo - 821012.In the following table, look for the model of the Welding Machine and theirs spare parts codes.
| PARTS BIMAX 162 TURBO 230V cod. 821012 Pag.1 | ||
| # | Description | Part Num. |
| 1 | POTENTIOMETER 10K | 112079 |
| 2 | KNOB | 121424 |
| 3 | RECTIFIER PROTECTION | 112185 |
| 4 | WIRE FEEDER BOARD KIT | 980463 |
| 5 | CABLE 16 MMQ 1,8 M | 124502 |
| 6 | THERMOSTAT | 121069 |
| 7 | SWITCH | 122400 |
| 8 | SWITCH | 122752 |
| 9 | MAINS CABLE 3G1.5 2 M SCHUKO PLUG | 132310 |
| 10 | WIRE FEED MOTOR | 153023 |
| 11 | REACTANCE | 169228 |
| 12 | TRANSFORMER - DISCONTINUED | 169295 |
| 13 | PRESSURE ROLL | 232105 |
| 14 | FAN BLADE | 312025 |
| 15 | HANDLE | 312356 |
| 16 | CABLE BUSHING | 322112 |
| 17 | ROLL SUPPORT | 322126 |
| 18 | TORCH FIXING CASING | 322127 |
| 19 | PRESSURE ROLL BRACKET | 322128 |
| 20 | RING NUT | 322143 |
| 21 | SPINDLE | 322172 |
| 22 | REEL RING NUT | 322173 |
| 23 | REEL HANDWHEEL | 322174 |
| 24 | WHEEL | 322193 |
| 25 | FRAME | 322631 |
| 26 | WIRE FEED HANDWHEEL | 422257 |
| 28 | SPRING | 452022 |
| 29 | DOOR SPRING | 452056 |
| 30 | REEL SPRING | 452065 |
| 31 | WHEELS AXLE | 482783 |
| 32 | FOOT | 644402 |
| 33 | BACK PANEL | 644939 |
| 34 | DIAPHRAGM | 644940 |
| 35 | BOTTLE HOLDER | 645088 |
| 36 | FRONT PANEL | 649485 |
| 37 | COVER | 651026 |
| 38 | BOTTOM | 644965 |
| 39 | SIDE PANEL | 655280 |
| 40 | DOOR | 655281 |
| 41 | COLORADO 150B WORK CLAMP 150A | 712001 |
| 42 | FEED ROLL D. 0,6-0,9 MM FE/FLUX | 722529 |
| 44 | TW160 MIG TORCH 2 M 160 A | 742402 |
| 45 | GAS HOSE KIT | 990097 |
| 46 | GEARS KIT | 990251 |
| 47 | REEL KIT | 990288 |
| 48 | RECTIFIER KIT | 990745 |
| 49 | FAN MOTOR | 152080 |
| 50 | WHEEL LOCKING RING | 322223 |
| 51 | RED CHARGING CLAMP KIT | 990072 |
| 52 | KIT BLACK CHARGING CLAMP | 990073 |
| TORCH PARTS PER BIMAX 162 TURBO 230V Pag.2 | ||
| 1 | CONTACT TIP D. 1 MM AL/FLUX | 722552 |
| 2 | CYLINDRICAL NOZZLE | 722149 |
| 3 | SWAN NECK DIFFUSER | 722078 |
| 4 | VALVE | 990464 |
| 5 | CONTACT SPRING FOR MIG TORCH | 452097 |
| 6 | PUSHBUTTON | 322295 |
| 7 | KIT CABLE SET 10 MMQ | 990602 |
| 9 | GUIDE HOSE D.0,6-0,8MM 2M FE/INOX/FLUX | 722077 |
