Telwin Spare Parts for Welding Bimax 140 Turbo

€4.03
Tax included

Telwin Spare Parts for Welding Bimax 140 Turbo

TELWIN Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Welding Inverter Bimax 140 Turbo - 821076.

Telwin Bimax 140 Turbo - 821076
ITEM CODE: 112185
Quantity
on 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Telwin Spare Parts for Welding Bimax 140 Turbo

TELWIN Authorized Technical Assistance and original spare parts Worldwide Distributors

 and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Welding Inverter Bimax 140 Turbo - 821076.

In the following table, look for the model of the Welding and the respective parts of the code.
Telwin Bimax 140 Turbo - 821076

Welding Bimax 140 Turbo - 821076 Pag.1
# Part Num. Description
1 113533 POTENTIOMETER
2 121424 KNOB
3 112185 RECTIFIER PROTECTION
4 990746 RECTIFIER KIT
5 990178 KIT PCB MOG/LIVE AUTOMATIC + CABLE
6 124502 CABLE 16 MMQ 1,8 M
7 122752 SWITCH
8 121714 THERMOSTAT --> New Code  982000 THERMOSTAT Kit
9 132310 MAINS CABLE 3G1.5 2M SCHUKO PLUG
10 152080 FAN MOTOR
11 981828 MOTOR KIT
12 169167 TRANSFORMER
14 312026 FAN BLADE
15 322677 HANDLE
16 322112 CABLE BUSHING
20 322143 RING NUT
22 322173 REEL RING NUT
23 322174 REEL HANDWHEEL
26 452065 REEL SPRING
27 617024 DOOR
28 981820 BOTTOM KIT
29 981819 COVER KIT
30 644229 BACK PANEL
31 644734 DIAPHRAGM
32 642530 FRONT PANEL
33 712001 COLORADO 150B WORK CLAMP 150A
35 722529 FEED ROLL D. 0,6-0,9 MM FE/FLUX
36 742402 TW160 MIG TORCH 2M
37 990072 RED CHARGING CLAMP KIT
38 990073 KIT BLACK CHARGING CLAMP
39 990097 GAS HOSE KIT
41 990288 REEL KIT
42 122400 SWITCH
43 322681 CAP FOR HANDLE
Parts Torch Pag.2
1 722552 CONTACT TIP D. 1 MM AL/FLUX
2 722149 CYLINDRICAL NOZZLE
3 722078 SWAN NECK DIFFUSER
4 990464 VALVE
5 452097 CONTACT SPRING FOR MIG TORCH
6 322295 PUSHBUTTON
7 990602 KIT CABLE SET 10 MMQ
9 722077 GUIDE HOSE D.0,6-0,8MM 2M FE/INOX/FLUX
