Makita Spare Parts for Brush Cutter BBC5700
€1.44
Tax included
Makita Spare Parts for Brush Cutter BBC5700
Makita Original spare parts at attractive and competitive prices on the web, we are a service center with a repair service able to quickly solve the maintenance or repair any issues for Brush Cutter BBC5700.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Brush Cutter BBC5700
Makita Original spare parts at attractive and competitive prices on the web, we are a service center with a repair service able to quickly solve the maintenance or repair any issues for Brush Cutter BBC5700.
In the following table, look for the model of Brush Cutter and the respective parts of the code.
| Brush Cutter BBC5700 | ||
| # | Part Num. | Description |
| 1 | BB630070 | STARTER ROPE |
| 2 | BB510190 | PLATE |
| 3 | BB724740 | START CUTTER C / PIASTR.FERMO FUN. |
| 4 | BB091640 | STOPPED FOR ROPE |
| 5 | BB543600 | QUICK MOTOR SUPPORT RUBBER |
| 6 | BB724300 | STARTER COVER |
| 7 | BB180240 | STARTER SPRING |
| 8 | BB541320 | STARTER PULLEY |
| 9 | BB090720 | FLAT WASHER D.4,3 X 16 |
| 10 | BB030800 | SCREW TCB M 4 X 10 |
| 11 | BB724070/NE | STARTER CPL M.QUICK BLACK --> Substituited by BB730050 |
| 12 | BB030410 | SCREW TCEI M 5 X 18 |
| 13 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 14 | BB541340 | RUBBER TANK |
| 15 | BB060370 | NUT M 9 X 25.1 |
| 16 | BB480900 | STARTER CUP --> Substituited by BB730080 |
| 17 | BB541330 | STARTER PAWL |
| 18 | BB180200 | STARTER SPRING |
| 19 | BB120160 | STOP RING D4 |
| 20 | BB722460 | RECOIL STARTER ASS'Y |
| 21 | BB240370 | SEAL RING 15X26X7 |
| 22 | BB721430 | MOTOR HOUSING ASSEMBLY |
| 23 | BB240260 | GASKET |
| 24 | BB420200 | PIN D.8X10 |
| 25 | BB270070 | BALL BEARING 6202 |
| 26 | BB751600 | KRANKSHAFT |
| 27 | BB090150 | WASHER 5.1 |
| 28 | BB030620 | SCREW TCEI M 5 X 35 |
| 29 | BB240030 | O RING 15X26X7 |
| 30 | BB420030 | TONGUE 10X3,7X3 |
| 31 | BB270050 | NEEDLE BEARING K10X14X13FKI PB-V1 |
| 32 | BB150040 | RING D.10 |
| 33 | BB420040 | PISTON PIN D.10X30 |
| 34 | BB480970 | PISTON. 46 |
| 35 | BB150350 | PISTON RING D.46 |
| 36 | BB723100 | PISTON ASS'Y D.46 |
| 37 | BB240270 | CYLINDER GASKET |
| 38 | BB090620 | KNURLED WASHER D.6,4 |
| 39 | BB030630 | SCREW TCEI M 6 X 25 |
| 40 | BB752340 | DECOMPRESSOR N39 / 57E |
| 41 | BB480960 | CYLINDER DIAM.46 |
| 42 | BB240290 | MANIFOLD GASKET |
| 43 | BB541270 | INTAKE MANIFOLD |
| 44 | BB090800 | KNURLED WASHER D.5,3 |
| 44A | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 45 | BB030070 | TE SCREW M 5 X 30 |
| 46 | BB240130 | CARBURETOR GASKET |
| 47A | BB331650A | CARBURETOR BBK4500 |
| 48 | BB726390 | AIR FILTER HOLDER COMPL. |
| 49 | BB091630 | BUSHING |
| 52 | BB120270 | RING |
| 53 | BB031140 | SCREW M 3 X 8 |
| 54A | BB726390 | AIR FILTER HOLDER COMPL. |
| 55 | BB090830 | WAVER WATER D. 5,3 |
| 56 | BB030500 | SCREW TCEI M 5 X 45 |
| 57 | BB332100 | AIR FILTER X CARBURETOR WALBRO |
| 57A | BB332250 | AIR FILTER DBC5700 |
| 58 | BB543180 | AIR FILTER COVER |
| 59 | BB543090 | BLUE MOTOR CYLINDER COVER |
| 60 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 61 | BB030680 | SCREW TCEI M 5 X 14 |
| 62 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 63 | BB030620 | SCREW TCEI M 5 X 35 |
| 64 | BB451060 | SPARK PLUG RCJ4 |
| 65 | BB543200 | BLUE SPARK PLUG COVER |
| 66 | BB240500 | SEAL MUFFLER |
| 67 | BB752350 | MUFFLER |
| 68 | BB090830 | WAVER WATER D. 5,3 |
| 69 | BB030410 | SCREW TCEI M 5 X 18 |
| 70 | BB090830 | WAVER SCREW D. 5,3 |
| 71 | BB030680 | SCREW TCEI M 5 X 14 |
| 73 | BB031150 | SCREW M 5 X 20 |
| 74 | BB450930 | COIL FOR CAPACITIVE N39 / 57 |
| 75 | BB450340 | CABLE MASS X BOB |
| 76 | BB541510 | FAIRLEAD |
| 77 | BB450280 | FLYWHEEL FOR N39 / 57 |
| 78 | BB091000 | WAVES WATER D.10,5 |
| 79 | BB060300 | NUT M 10 X 8 |
| 80 | BB780080 | SUPP.CEPPI FRIZ. N31 / 52 |
| 81 | BB780020 | CLUTCH LOCK N31 / 52 |
| 82 | BB180040 | EXTERNAL CLUTCH SPRING |
| 83 | BB180030 | INTERNAL CLUTCH SPRING |
| 84 | BB510200 | THREADED SPRING DISC |
| 85 | BB721390 | COMPLETE CLUTCH SIN. |
| 86 | BB090830 | WAVER WATER D. 5,3 |
| 87 | BB030620 | SCREW TCEI M 5 X 35 |
| 88 | BB751300 | DRUM CLUTCH |
| 89 | BB120070 | RING 32I UNI 7437 |
| 90 | BB270240 | 6201-ZZ BEARING |
| 91 | BB120020 | RING 12E UNI 7435-75 |
| 92 | BB480980 | HOUSING CLUTCH |
| 99 | BB724100 | SUPP GROUP. AND DRUM CLUTCH |
| 100 | BB726390 | AIR FILTER SUPPLY COMPL. |
| 107 | BB030380 | SCREW TCEI M 5 X 16 |
| 108 | BB543220 | HOUSING |
| 109 | BB543210 | HOUSING |
| 110 | BB481000 | LOWER SPACER |
| 111 | BB480990 | SUPERIOR SPACER |
| 112 | BB060100 | NUT M 5 X 4 |
| 113 | BB030410 | SCREW TCEI M 5 X 18 |
| 114 | BB724110 | FUEL TANK ASS'Y |
| 115 | BB542520 | TUBE |
| 116 | BB723740 | CAP TANK |
| 117 | BB542460 | TUBE |
| 118 | BB330820 | INTAKE FILTER |
| PAG.2 | ||
| 1 | BB543490 | NEW HANDLEBAR HANDLEBAR |
| 2 | BB511030 | SPRING X IMPUGN SUPPORT. M |
| 3 | BB750920 | CUTTING ATTACK |
| 4 | BB030630 | SCREW TCEI M 6 X 25 |
| 5 | BB090040 | FLAT WASHER D.6,4 |
| 6 | BB542450 | CRUISE SUPPORT HAT |
| 8 | BB542440 | CRUISE SUPPORT BODY |
| 9 | BB542430 | HORSE CROSS BODY |
| 10 | BB030810 | SCREW TCEI M 6 X 40 |
| 11 | BB722620 | NYLON CUBE HANDLEBAR SUPPORT |
| 12 | BB751640 | BUSH |
| 13 | BB391030 | RIGID DRIVE SHAFT |
| 14 | BB540420 | ANTI-BUSH D.27 |
| 15 | BB750540 | RUBBER HOSE CPLETO |
| 16 | BB540690 | CABLE CONTROL GAS SUPPORT |
| 17 | BB570530 | TUBE RUBBER X IMPUGN.ANT. |
| 18 | BB542420 | ANTIVIBRANTE CONTROL REG. |
| 19 | BB722830 | HANDLE |
| 20 | BB570670 | HANDBAG X EBC NBC |
| 21 | BB751620 | SUSPENDER WITH PROTECTION |
| 22 | BB751580 | SUSPENDERS |
| PAG.3 | ||
| 1 | BB090020 | CASE BOWL |
| 2 | BB030800 | SCREW TCB M 4 X 10 |
| 3 | BB120020 | RING SEEGER 12E UNI 7435-75 |
| 4 | BB120010 | RING SEEGER 28I UNI 7437 |
| 5 | BB270010 | 6001-ZZ BEARING |
| 6 | BB723380 | KIT GEAR GAR BOX |
| 7 | BB060060 | NUT M 6 X 5 |
| 8 | BB090010 | WASHER GROWER D. 6,1 |
| 9 | BB480470 | CONICA COVER CASE D.27 |
| 10 | BB030010 | SCREW TE M 6 X 30 |
| 11 | BB031080 | SCREW CAP |
| 12 | BB270020 | BALL BEARING 6000 |
| 13 | BB390010 | SPINDLE |
| 14 | BB420010 | LOCK PIN |
| 15 | BB270030 | BALL BEARING 6202-2RS |
| 16 | BB120030 | RING SEEGER 35I UNI 7437 |
| 17 | BB091560 | DISC PORTABLE D.50 |
| 18 | BB510180 | SUPERIOR FLANGE |
| 19 | BB090070 | FLANGE |
| 20 | BB060470 | SELF-LOCKING NUT M 10 X 1 X 12 |
| 21 | BB722760 | GEAR BOX CPL |
| 25 | BB120050 | RING SEEGER 15E UNI 7435-75 |
| 26 | BB480060 | HOLDER BEARING |
| 27 | BB270060 | 6002-ZZ BEARING |
| 28 | BB060160 | NUT M10X1 |
| 30 | BB090010 | WASHER GROWER D. 6,1 |
| 31 | BB030050 | SCREW TE M 6 X 12 |
| 33 | BB060100 | NUT M 5 X 4 |
| 34 | BB542410 | SAFETY GUARD |
| 35 | BB511020 | KNIFE |
| 36 | BB030820 | SCREW 3.9 X 16 |
| 37 | BB729200 | COVER GUARD |
| 38 | BB091360 | WASHER 5.5 X 15 X 1.6 |
| 39 | BB090150 | WASHER GROWER 5.1 |
| 40 | BB030830 | SCREW M 5 X 12 |
| 43 | BB720330 | SERVICE KEYS KIT |
| PAG.4 | ||
| 1 | BB543260 | TOP COVER FLASH LIGHT |
| 3 | BB180370 | SPRING FLASH LIGHT |
| 4 | BB091350 | BUSH |
| 5 | BB543280 | BOBINA X TESTINA FLASH LIGHT |
| 6 | BB543270 | FLASH LIGHT FLOW |
| 8 | BB542180 | RAPID SUP.TEST.FLASH COVER |
| 10 | BB180180 | SPRING X AUTOMATIC TEST |
| 11 | BB091350 | TUBE FILO GUIDE BOWL |
| 13 | BB542190 | STOP FLOW OF TEST.RAPID |
| 15 | BB391510 | NUT X HEAD FLASH QUICK |
| 16 | BB543460 | TOP TEST.QUICK COVER |
| 17 | BB091350 | TUBE FILO GUIDE BOWL |
| 18 | BB724140 | BOBINA X FLASH QUICK |
| 19 | BB180110 | SPRING X FLASH AND QUICK TEST |
| 20 | BB543430 | QUICK TAPE PUMP |
| 21 | BB091600 | NUT QUICK FLASH HEAD INF.X |
| 23 | BB390540 | NUT X HEAD FLASH |
| 24 | BB541110 | SUPERIOR TEST.FLASH COVER |
| 25 | BB091350 | TUBE FILO GUIDE BOWL |
| 26 | BB540340 | BOBINA X TEST FLASH S / FILO |
| 27 | BB180110 | SPRING X FLASH AND QUICK TEST |
| 28 | BB541100 | LOWER TEST.FLASH COVER |
| 29 | BB090590 | WASHER X M16 17X30X3 |
| 30 | BB480310 | POMOLO X TESTINA SIN. |
| 31 | P-47307 | MANUAL HEAD M10X1.0F |
| PAG.5 | ||
| 1 | BB751060 | CABLE GAS GROUP |
| 2 | BB721440 | CPL MANOPLE. X HANDLEBAR |
| 3 | BB721660 | COMPLETE HANDLE |
| 6 | BB96-166 | SCREW COP. PUMP WT |
| 7 | BB21-353 | PUMP COVER WT |
| 8 | BB96-647 | SCREW + SPRING X REGULATION. MINIMUM |
| 9 | BB92-225 | MIXING PUMP GAUGE |
| 10 | BB95-118 | PUMP MEMBER WT |
| 11 | BB88-131 | STOPPER |
| 13 | BB96-142 | BUTTERFLY VALVE WT |
| 14 | BB52-548 | PIN WT101 |
| 15 | BB30-1140 | BUTTERFLY TREE |
| 16 | BB34-158 | THROTTLE |
| 17 | BB98-234 | VALVE SPRING |
| 18 | BB140-70 | FUEL FILTER FUEL |
| 19 | BB16-71 | SAFETY RING |
| 20 | BB102-330 | NEEDLE IDLE |
| 21 | BB98-404 | ADJUST SPRING |
| 22 | BB102-3066 | WT ADJUSTMENT WT |
| 23 | BB98-405 | MAXIMUM ADJUSTMENT SPRING |
| 24 | BB140-69 | VALVE SCREW WASHER |
| 25 | BB16-42 | STOP RING |
| 26 | BB88-119 | CAP |
| 27 | BB88-171 | PLUG WELCH |
| 28 | BB96-156 | METERING LEVER |
| 29 | BB84-613 | VALVE SEAT |
| 30 | BB82-75 | SHOOTING VALVE |
| 31 | BB98-387 | SPRING BALANCE SPRING |
| 32 | BB166-48 | ROCKER |
| 33 | BB144-77 | BALANCE SHEET |
| 34 | BB92-251 | MEMBRANE GASKET DIAFR.WT |
| 35 | BB95-526 | DIAPHRAM MEMBRANE |
| 36 | BB5-2694 | AIR FILTER BODY |
| 37 | BB176-64 | CONTROL VALVE |
| 38 | BB188-12 | SEAL |
| 39 | BB21-404 | PRIMER PUMP COVER |
| 40 | BB090190 | WASHER GROWER D.3.1 |
| 41 | BB96-578 | MEMBRANE COVER |
| 42A | BB331650A | CARBURETOR FOR BBK4500 |
| 43 | BBD10-WAT | KIT MENBRANE X WT 362,364,397 |
