Tanaka Spare Parts for Engine Brush Cutter TBC-340
€2.65
Tax included
Tanaka Spare Parts for Engine Brush Cutter TBC-340
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Engine Brush Cutter TANAKA TBC-340.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Engine Brush Cutter TBC-340
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Engine Brush Cutter TANAKA TBC-340.
In the following table, look for the model of the Brush Cutter and the respective parts of the code.
| Engine Brush Cutter Tanaka TBC-340 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 6699326 | SPARK PLUG ASS'Y RCJ6Y |
| 1 | 6699323 | SPARK PLUG ASS'Y CJ6Y |
| 2 | 6685487 | CYLINDER SET |
| 3 | 6684903 | HEX. HOLE BOLT M5X16/S |
| 4 | 6685746 | CYLINDER GASKET |
| 5 | 6685331 | PISTON RING (XR1-1856) |
| 6 | 6685898 | PISTON SET |
| 7 | 6686008 | PISTON PIN |
| 8 | 6685078 | CIRCLIP |
| 9 | 6696499 | CRANK SHAFT COMP |
| 10 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 11 | 6695407 | HIGH TENSION SCREW 4X18WS |
| 12 | 6688319 | INSULATOR TUBE, 110L |
| 14A | 6699772 | IGNITION COIL ASS'Y - DISCONTINUED |
| 15 | 6687888 | HIGH TENSION CORD 140L |
| 16 | 6684602 | RUBBER CAP |
| 17 | 6697836 | LEAD WIRE ASS'Y |
| 18 | 6684600 | WASHER T1.6 |
| 31 | 6686580 | CRANK CASE ASS'Y |
| 32 | 6684607 | OIL SEAL TB 12227 |
| 33 | 6684608 | BALL BEARING 6001 C3 |
| 34 | 6686721 | CRANK CASE GASKET |
| 35 | 6689177 | GEAR SHAFT SHIM 0.10 |
| 35 | 6689178 | GEAR SHAFT SHIM 0.15 |
| 35 | 6684604 | GEAR SHAFT SHIM 0.20 |
| 35 | 6684605 | GEAR SHAFT SHIM 0.30 |
| 36 | 6687375 | MAGNETO ROTOR COMP. |
| 37 | 6684612 | HEX. NUT M8 |
| 38 | 6695184 | SMALL WASHER 8 |
| 39 | 6684903 | HEX. HOLE BOLT M5X16/S |
| 40 | 6689645 | CLUTCH WASHER B |
| 51 | 6689864 | INLET MANIFOLD GASKET |
| 52 | 6689924 | CARBURETOR INSULATOR SET,SPARE |
| 53 | 6695514 | HEX.HOLE BOLT 5X22/WS |
| 54 | 6684616 | CARBURETOR PACKING |
| 55 | 6690503 | CARBURETOR SET WYJ296 |
| 56 | 6691278 | CHOKE PLATE 1.0 |
| 57 | 6690120 | CLEANER BODY COMP. |
| 58 | 6690365 | CLEANER SPONGE |
| 59 | 6690421 | CLEANER COVER ASS'Y |
| 60 | 6698730 | COVER FIXING BOLT COMP. |
| 61 | 6695353 | SCREW 5X57/S |
| 62 | 6684864 | SMALL WASHER 5 |
| 63 | 6691239 | CHOKE CONTROL LEVER |
| 64 | 6691588 | TANK COMP. WHT |
| 65 | 6684623 | COLLAR C |
| 66 | 6688156 | FUEL PIPE GROMMET |
| 67 | 6684880 | FUEL PIPE 3X5X85 |
| 68 | 6684620 | PUMP FILTER BODY COMP. |
| 69 | 6685198 | CLIP D6 |
| 70 | 6688169 | FUEL PIPE ASS'Y |
| 71 | 6695506 | HEX. HOLE BOLT 5X20PS |
| 72 | 6685049 | TANK CAP ASS'Y |
| 73 | 6684625 | TANK CAP CHAIN |
| 74 | 6694793 | STAND |
| 75 | 6695280 | TAP SCREW 4X14 P |
| 76 | 6685070 | BOLT WASHER M4 |
| 91 | 6688610 | CLUTCH ARM COMP. |
| 92 | 6689420 | CLUTCH SPRING |
| 93 | 6689645 | CLUTCH WASHER B |
| 94 | 6695203 | WAVE WASHER 10 |
| 95 | 6689628 | CLUTCH STEP BOLT |
| 96 | 6688482 | CLUTCH SET ASS'Y |
| 97 | 6687019 | FAN CASE COMP. |
| 98 | 6695512 | HEX. HOLE BOLT 5X15 WS |
| 99 | 6691838 | ANTI-VIBE RUBBER |
| 100 | 6685275 | TAPPING SCREW D5X14 |
| 101 | 6689656 | PIPE HOLDER |
| 102 | 6684664 | STOP RING C-12 OUTER |
| 103 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 104 | 6695507 | HEX. HOLE BOLT 4X12WS |
| 105 | 6688598 | CLUTCH SHAFT COMP. 78 |
| 106 | 6695304 | STOP RING R-32 INNER |
| 107 | 6686667 | BEARING CASE |
| 108 | 6695553 | BALL BEARING #6201ZZ, 32MM/OD |
| 109 | 6688057 | PRIMARY CORD GROMMET |
| 110 | 6692803 | MUFFLER PROTECTOR |
| 111 | 6687468 | SPARK PLUG CAP ASS'Y |
| 112 | 6684637 | TAPPING SCREW D4.5X12 |
| 113 | 6692732 | MUFFLER GASKET |
| 114 | 6687260 | HEAT SHIELD |
| 115 | 6692489 | MUFFLER SET |
| 116 | 6684638 | HEX. HOLE BOLT M6X55 |
| 117 | 6684639 | BOLT WASHER 6 |
| 118 | 6692887 | MUFFLER SPECIAL GASKET |
| 119 | 6692669 | TAIL PIPE SET |
| 119 | 6692712 | TAIL PIPE SET |
| 120 | 6695325 | SCREW 4X8/S |
| 120 | 6685109 | MACHINE SCREW (W/SP. WASHER) M4X8 |
| 121 | 6692699 | SPARK GUARD |
| 151 | 6692969 | RECOIL STARTER ASS'Y |
| 152 | 6693227 | STARTER HANDLE |
| 153 | 6693135 | ROPE GUIDE |
| 154 | 6693036 | RECOIL STARTER BODY |
| 155 | 6693111 | RECOIL SPRING |
| 156 | 6693157 | ROPE 3.5X890 |
| 157 | 6693057 | STARTER ROPE REEL |
| 158 | 6693419 | ROPE REEL WASHER |
| 159 | 6693632 | SET SCREW |
| 160 | 6695502 | HEX.HOLE BOLT 4X18PS |
| 161 | 6693394 | STARTER PULLEY ASS'Y |
| 162 | 6693299 | STARTER PAWL |
| 163 | 6693345 | STARTER PAWL SPRING |
| 191 | 6684879 | PUMP BODY COMP. |
| 192 | 6684687 | PRIMING PUMP COMP. |
| 193 | 6684688 | DIAPHRAGM COVER |
| 194 | 6684689 | PRIMING BODY |
| 195 | 6690830 | METERING DIAPHRAGM COMP. |
| 196 | 6684691 | DIAPHRAGM GASKET |
| 197 | 6684693 | PUMP DIAPHRAGM |
| 198 | 6691457 | PUMP GASKET |
| 199 | 6691848 | MAIN JET #43 |
| 200 | 6684695 | O-RING |
| 201 | 6684696 | STOP RING |
| 202 | 6684697 | SWIVEL |
| 203 | 6684870 | THROTTLE SET SCREW |
| 204 | 6684873 | CABLE ADJUSTER STAY |
| 205 | 6684872 | LOCK NUT M6 |
| 206 | 6684871 | CABLE ADJUSTER |
| 207 | 6684875 | CLEANER PACKING |
| 208 | 6684699 | SET SCREW |
| 209 | 6684874 | THRUST WASHER |
| 210 | 6684700 | INLET SCREEN |
| 231 | 6689478 | DRIVE SHAFT 1533L |
| 232 | 6689407 | DRAIVE SHAFT PIPE COMP. |
| 233 | 6697866 | BUSHING ASS'Y |
| 234 | 6684835 | HEX.NUT 6 |
| 235 | 6691036 | HANDLE |
| 235A | 6691049 | LOOP HANDLE, 26DIA., BLACK |
| 236 | 6691231 | BARRIER, 26 DIA, BLACK |
| 237 | 6684838 | BOLT 6X43/P (BLACK) |
| 238 | 6695255 | TAPPING SCREW 5X20 |
| 239 | 6689681 | BRAKE SHAFT WASHER |
| 240 | 6691098 | HANDLE GRIP |
| 241 | 6689275 | LIFTING METAL ASS'Y |
| 242 | 6693748 | THROTTLE LEVER ASS'Y, 26 DIA. |
| 243 | 6693978 | THROTTLE WIRE COMP. |
| 244 | 6694022 | THROTTLE WIRE |
| 245 | 6687459 | STOP SWITCH COMP. |
| 246 | 6687526 | PROTECTION TUBE 7X175 |
| 247 | 6684721 | TRIGGER LOCK OUT |
| 248 | 6684722 | RETURN SPRING |
| 249 | 6684724 | BLIND PLUG |
| 250 | 6684803 | SCREW M5X20 |
| 251 | 6684727 | CONTAL NUT 5 |
| 252 | 6684725 | SCREW M4X20 (BLACK) |
| 253 | 6684804 | THROTTLE LEVER |
| 281 | 6696497 | GEAR CASE SET PN |
| 281A | 6697660 | GEAR CASE ASS'Y |
| 281B | 6696497 | GEAR CASE SET PN |
| 282 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 282A | 6684829 | HEX. SOCKET HD. BOLT M5X12 |
| 282B | 6684709 | HEX. HOLE BOLT M5X25/S |
| 283 | 6684834 | SPRING WASHER 5 |
| 283 | 6684834 | SPRING WASHER 5 |
| 284 | 6695294 | RETAINING RING C-TYPE D26 |
| 285 | 6695315 | STOP RING OUTER 10 |
| 285A | 6684821 | STOP RING C-10,OUTER |
| 285B | 6695315 | STOP RING OUTER 10 |
| 286 | 6695526 | BALL BEARING #6000Z, 26MM/OD |
| 287 | 6695524 | BALL BEARING #6000, 26MM/OD |
| 287 | 6695524 | BALL BEARING #6000, 26MM/OD |
| 287 | 6695524 | BALL BEARING #6000, 26MM/OD |
| 288 | 6688770 | GEAR CASE 26 DIA |
| 288A | 6697738 | GEAR CASE |
| 288B | 6688770 | GEAR CASE 26 DIA |
| 289 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 289A | 6684786 | HEX. SOCKET HD. BOLT M5X30 S |
| 289B | 6684667 | HEX.HOLE BOLT M5X12/S |
| 290 | 6689109 | OILING BOLT |
| 290A | 6684737 | BOLT (W/PLUS) M6X8 |
| 290B | 6689109 | OILING BOLT |
| 291 | 6684734 | BALL BEARING 609 |
| 291 | 6684734 | BALL BEARING 609 |
| 292 | 6688924 | GEAR SHAFT |
| 292A | 6697739 | GEAR SHAFT |
| 292B | 6688924 | GEAR SHAFT |
| 293 | 6695554 | BALL BEARING 6201D, 32MM/OD |
| 293A | 6695555 | BALL BEARING #6201DD, 32MM/OD |
| 293B | 6695554 | BALL BEARING 6201D, 32MM/OD |
| 294 | 6695295 | STOP RING C-32, INNER |
| 295 | 6689032 | CUTTER HOLDER |
| 295A | 6699008 | CUTTER HOLDER |
| 295B | 6689032 | CUTTER HOLDER |
| 296 | 6689055 | CUTTER HOLDER CAP |
| 296A | 6699009 | CUTTER HOLDER CAP |
| 296B | 6689055 | CUTTER HOLDER CAP |
| 297 | 6697792 | NUT COVER |
| 297 | 6697792 | NUT COVER |
| 298 | 6689073 | FIXING NUT M10X1.25 |
| 298A | 6698658 | LEFT HAND NYLON NUT M10 |
| 298B | 6689073 | FIXING NUT M10X1.25 |
| 299 | 6689159 | GEAR CASE WASHER |
| 299 | 6689159 | GEAR CASE WASHER |
| 300 | 6684714 | HEX. HOLE BUTTON BOLT M6X25 |
| 301 | 6690294 | COVER BRACKET, 26 DIA. |
| 301A | 6690315 | COVER BRACKET 26 |
| 301B | 6697867 | COVER BRACKET D26 |
| 301C | 6690315 | COVER BRACKET 26 |
| 302 | 6690242 | BLADE GUARD 26 CE |
| 302A | 6690276 | BLADE GUARD 26CE |
| 303 | 6684748 | GUARD HOLDER |
| 304 | 6690372 | COVER GUARD |
| 304A | 6690376 | BLADE GUARD |
| 305 | 6693386 | KNIFE |
| 305A | 6684750 | KNIFE |
| 306 | 6695334 | SCREW 5X12/S |
| 306A | 6684751 | TAPPING SCREW 4X14 |
| 307 | 6688875 | GEAR/PINION SET, SPARE |
| 307A | 6697741 | GEAR PINION SET,SPARE |
| 307B | 6688875 | GEAR/PINION SET, SPARE |
| 308 | 6684965 | NUT M5 |
| 309 | 6684753 | TAPPING SCREW 5X20 |
| 309 | 6684753 | TAPPING SCREW 5X20 |
| 310 | 6684754 | KNIFE |
| 310 | 6684754 | KNIFE |
| 321 | 6696497 | GEAR CASE SET PN |
| 322 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 323 | 6695294 | RETAINING RING C-TYPE D26 |
| 325 | 6695315 | STOP RING OUTER 10 |
| 326 | 6695526 | BALL BEARING #6000Z, 26MM/OD |
| 327 | 6695524 | BALL BEARING #6000, 26MM/OD |
| 328 | 6688770 | GEAR CASE 26 DIA |
| 329 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 330 | 6689109 | OILING BOLT |
| 331 | 6684734 | BALL BEARING 609 |
| 332 | 6688924 | GEAR SHAFT |
| 333 | 6695554 | BALL BEARING 6201D, 32MM/OD |
| 334 | 6695295 | STOP RING C-32, INNER |
| 335 | 6689032 | CUTTER HOLDER |
| 336 | 6689055 | CUTTER HOLDER CAP |
| 338 | 6689073 | FIXING NUT M10X1.25 |
| 339 | 6689159 | GEAR CASE WASHER |
| 340 | 6684714 | HEX. HOLE BUTTON BOLT M6X25 |
| 341 | 6690294 | COVER BRACKET, 26 DIA. |
| 341A | 6690315 | COVER BRACKET 26 |
| 342 | 6690242 | BLADE GUARD 26 CE |
| 342A | 6690276 | BLADE GUARD 26CE |
| 343 | 6684748 | GUARD HOLDER |
| 344 | 6690372 | COVER GUARD |
| 344A | 6690376 | BLADE GUARD |
| 345 | 6693386 | KNIFE |
| 345A | 6684750 | KNIFE |
| 346 | 6695334 | SCREW 5X12/S |
| 346A | 6684751 | TAPPING SCREW 4X14 |
| 347 | 6688875 | GEAR/PINION SET, SPARE |
| 348 | 6684965 | NUT M5 |
| 349 | 6684753 | TAPPING SCREW 5X20 |
| 349 | 6684753 | TAPPING SCREW 5X20 |
| 350 | 6684754 | KNIFE |
| 350 | 6684754 | KNIFE |
| 361 | 6696497 | GEAR CASE SET PN |
| 361B | 6601215 | GEAR CASE ASS'Y |
| 362 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 362A | 6684829 | HEX. SOCKET HD. BOLT M5X12 |
| 363 | 6684834 | SPRING WASHER 5 |
| 364 | 6695294 | RETAINING RING C-TYPE D26 |
| 365 | 6695315 | STOP RING OUTER 10 |
| 365A | 6684821 | STOP RING C-10,OUTER |
| 366 | 6695526 | BALL BEARING #6000Z, 26MM/OD |
| 367 | 6695524 | BALL BEARING #6000, 26MM/OD |
| 367 | 6695524 | BALL BEARING #6000, 26MM/OD |
| 368 | 6688770 | GEAR CASE 26 DIA |
| 368A | 6697738 | GEAR CASE |
| 369 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 369A | 6684786 | HEX. SOCKET HD. BOLT M5X30 S |
| 370 | 6689109 | OILING BOLT |
| 370A | 6684737 | BOLT (W/PLUS) M6X8 |
| 371 | 6684734 | BALL BEARING 609 |
| 372 | 6688924 | GEAR SHAFT |
| 372A | 6697739 | GEAR SHAFT |
| 373 | 6695554 | BALL BEARING 6201D, 32MM/OD |
| 373A | 6695555 | BALL BEARING #6201DD, 32MM/OD |
| 374 | 6695295 | STOP RING C-32, INNER |
| 375 | 6689032 | CUTTER HOLDER |
| 375B | 6601216 | CUTTER HOLDER ASS'Y |
| 376 | 6689055 | CUTTER HOLDER CAP |
| 376A | 6699009 | CUTTER HOLDER CAP |
| 377 | 6697792 | NUT COVER |
| 378 | 6689073 | FIXING NUT M10X1.25 |
| 378A | 6698658 | LEFT HAND NYLON NUT M10 |
| 379 | 6689159 | GEAR CASE WASHER |
| 380 | 6684714 | HEX. HOLE BUTTON BOLT M6X25 |
| 381 | 6690315 | COVER BRACKET 26 |
| 381A | 6697867 | COVER BRACKET D26 |
| 382 | 6690276 | BLADE GUARD 26CE |
| 383 | 6684748 | GUARD HOLDER |
| 384 | 6690376 | BLADE GUARD |
| 385 | 6684750 | KNIFE |
| 386 | 6684751 | TAPPING SCREW 4X14 |
| 387 | 6684753 | TAPPING SCREW 5X20 |
| 388 | 6684754 | KNIFE |
| 389 | 6688875 | GEAR/PINION SET, SPARE |
| 389A | 6697741 | GEAR PINION SET,SPARE |
| STANDARD ACCESSORIES Pag.2 |
||
| 501 | 6684813 | HEX. BAR WRENCH 4MM |
| 502 | 6684764 | BOX WRENCH (HEX. SOCKET 17/19) |
| 503 | 6699555 | CUTTER COVER |
| 503B | 6684768 | CUTTER COVER |
| 504A | 875769 | PROTECTIVE GLASSES |
| 505 | 6693520 | HEX. WRENCH 3 |
| 506 | 6695789 | BLADE B4/9/1.6 |
| 507 | 6692874 | SHOULDER BELT ASS'Y |
| 508 | 6688995 | PROTECTION COVER B |
| 508 | 6688995 | PROTECTION COVER B |
| 508 | 6688995 | PROTECTION COVER B |
| 509 | 6695786 | NYLON HEAD CH-100 |
| 510 | 6688995 | PROTECTION COVER B |
| 521 | 6601148 | NYLON CORD CUTTER |
| 522 | 6601149 | CASE |
| 523 | 6601150 | NUT |
| 524 | 6693380 | REEL SPRING |
| 525 | 6601151 | LINE HOLDER |
| 526 | 6601152 | COVER |
| 527 | 6684810 | EYELET |
| OPTIONAL ACCESSORIES Pag.3 |
||
| 601 | 6694205 | NAME PLATE TBC340 |
| 602 | 6694633 | SYMBOL MARK TBC340 |
| 603 | 6697851 | CAUTION MARK TANAKA |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Tanaka websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Tanaka brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Tanaka TBC-340
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- MORE INFO:
- info@bricoutensili.com
New
You might also like
Comments (0)
No customer reviews for the moment.
Viewed products
16 other products in the same category:
