Tanaka Spare Parts for Chainsaw TCS33EDT
€62.42
Tax included
Tanaka Spare Parts for Chainsaw TCS33EDT
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw TCS33EDT.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Chainsaw TCS33EDT
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw TCS33EDT.
In the following table, look for the model of the Chainsaw and the respective parts of the code.
| Chainsaw TCS33EDT | ||
| # | Part Num. | Description |
| 1 | 6685225 | AIR CLEANER BASE |
| 3 | 6696826 | CLEANER SPONGE (B) |
| 4 | 6685230 | CLEANER ELEMENT A COMP. |
| 5 | 6685231 | CLEANER ELEMENT B COMP. |
| 6 | 6696825 | CLEANER SPONGE (A) |
| 7 | 6696785 | CLEANER COVER |
| 8 | 6696786 | CLEANER KNOB |
| 10 | 6696821 | MUFFLER COVER |
| 11A | 6600316 | CLUTCH |
| 12 | 6698856 | CLUTCH HOUSING |
| 13 | 6685361 | NEEDLE BEARING (D) |
| 14 | 6685414 | CLUTCH WASHER |
| 15 | 6685360 | CRANK SHAFT COLLAR |
| 17 | 6685356 | NEEDLE ROLLER 2.5X19.8 |
| 18 | 6685354 | PUMP GEAR |
| 19 | 6685355 | PUMP GEAR SPRING |
| 21A | 6699120 | PUMP ASS'Y |
| 23 | 6698849 | INTAKE PACKING |
| 24 | 6696794 | INTAKE MANIFOLD |
| 26 | 6685203 | PULSE GUIDE |
| 27 | 6696812 | ENGINE CASE COVER |
| 28 | 6696792 | CLEANER BODY |
| 30 | 6696795 | CARBURETOR ASS'Y |
| 31 | 6698857 | INLET SPACER |
| 32 | 6685210 | SCREW |
| 34 | 6685212 | PUMP GASKET |
| 35 | 6685213 | PUMP DIAPHRAGM |
| 36 | 6684700 | INLET SCREEN |
| 37 | 6685215 | NEEDLE VALVE |
| 39 | 6685217 | CONTROL LEVER |
| 40 | 6685297 | IDLE ADJUST SPRING |
| 41 | 6685298 | IDLE ADJUST SCREW |
| 42 | 6685218 | HINGE PIN SET SCREW |
| 43 | 6685219 | HINGE PIN |
| 44 | 6685220 | DIAPHRAGM PACKING-METERING |
| 45 | 6684690 | METERING DIAPHRAGM |
| 47 | 6685223 | SET SCREW |
| 49 | 6685206 | CHOKE LEVER |
| 52 | 6685139 | PRIMING PUMP COMP. |
| 53 | 6685371 | AIR VENT SPONGE |
| 54 | 6685370 | AIR VENT VALVE (B) |
| 55 | 6696811 | OIL PIPE |
| 56 | 6685358 | PIPE JOINT |
| 57 | 6698456 | FLANGED TAPPING SCREW D5X15 |
| 59A | 6696807 | ENGINE CASE ASS'Y |
| 61 | 6696816 | EXHAUST PIPE |
| 62 | 6696818 | MUFFLER SPECIAL PACKING |
| 63 | 6696817 | GAUZE FIXING PLATE |
| 64 | 6696815 | MUFFLER GAUZE |
| 65 | 6696814 | MUFFLER |
| 68 | 6696766 | SCAVENGING COVER (B) |
| 72 | 6698853 | CRANK WORM ASS'Y |
| 73 | 6685330 | WORM |
| 74 | 6685329 | OIL SEAL |
| 75 | 6685328 | BALL BEARING |
| 76 | 6696762 | CRANK SHAFT |
| 79 | 6685326 | CIRCLIP |
| 80 | 6698806 | PISTON (M) |
| 81 | 6685331 | PISTON RING (XR1-1856) |
| 82 | 6696764 | PISTON PIN |
| 83 | 6685103 | BOLT WASHER M7 |
| 84 | 6685104 | FLYWHEEL NUT |
| 85 | 6685336 | RETAINING RING D4 |
| 87 | 6685335 | STARTER PAWL SPRING |
| 88 | 6685334 | STARTER PAWL |
| 89A | 6600090 | MAGNETO SUB ASS'Y |
| 90A | 6685351 | INNER CAP |
| 91 | 6685179 | TANK CAP PACKING |
| 92 | 6698854 | FUEL TANK CAP ASS'Y (VERMILION) |
| 95A | 6699999 | IGNITION COIL |
| 96 | 6698700 | GLASS WASHER |
| 98 | 6696765 | SCAVENGING COVER (A) |
| 102A | 6696791 | CORD (B) |
| 103A | 6696326 | HEX. SOCKET HD. BOLT (W/FLANGE) M4X18 |
| 104 | 6685226 | WASHER M5 (BLACK) |
| 107 | 6698860 | PROTECTION SHEET |
| 110 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 112 | 6698358 | FUEL TANK CAP ASS'Y (BLACK) |
| 123 | 6696800 | COLLAR 28.2 |
| 124 | 6696775 | DAMPER |
| 125 | 6696774 | REAR HANDLE (B) |
| 126A | 6685244 | TRIGGER LOCKOUT |
| 127 | 6696797 | THROTTLE WIRE |
| 128 | 6696940 | STOP SWITCH |
| 129 | 6698449 | NUT M6 |
| 130 | 6698691 | THROTTLE LEVER SPRING |
| 131 | 6685242 | THROTTLE LEVER |
| 132 | 6698409 | SPRING HOLDER |
| 133 | 6698859 | DAMPER SET BOLT |
| 134 | 6698428 | ANTIVIBRATION SPRING |
| 136 | 6698581 | FLANGE NUT M8 |
| 137A | 6696776 | SIDE CASE (VERMILION) |
| 138 | 6696782 | BRAKE SUPPORT PLATE |
| 139 | 6696783 | BRAKE LEVER SPRING |
| 140 | 6685388 | BRAKE LINK |
| 141 | 6685140 | BRAKE BAND - DISCONTINUED |
| 142 | 6685391 | NEEDLE ROLLER D3 |
| 143 | 6685389 | BRAKE SPRING |
| 144A | 6698986 | CHAIN PULLER |
| 145 | 6696784 | GUIDE PLATE (B) |
| 150 | 6698715 | FUEL PIPE |
| 151 | 6696827 | SPIKE SET |
| 152 | 6698851 | FUEL PIPE (FKM) L240 |
| 154 | 6698852 | FUEL PIPE (FKM) L260 |
| 155 | 6696167 | FUEL GROMMET |
| 156 | 6696773 | REAR HANDLE (A) |
| 158A | 6696798 | FRONT HANDLE - DISCONTINUED |
| 159 | 6698866 | BRAKE HANDLE |
| 163 | 6685311 | CLIP |
| 164 | 6685310 | OIL FILTER BODY |
| 166 | 6685407 | BOLT WASHER D5 |
| 167 | 6696790 | AIR DEFLECTOR |
| 168B | 6699417 | RECOIL STARTER (S) (VERMILION) |
| 171 | 6698457 | CORD INSULATION TUBE |
| 172 | 6698865 | SPRING COVER |
| 173 | 6685308 | FUEL GROMMET (A) |
| 176 | 6699483 | REEL |
| 177 | 6699480 | SPIRAL SPRING CASE |
| 178 | 6699476 | SET SCREW |
| 179 | 6699478 | CAM PLATE - DISCONTINUED |
| 180 | 6699479 | DAMPER SPRING |
| 181 | 6699484 | REEL |
| 185 | 6699473 | STARTER HANDLE ASS'Y |
| 186 | 6699490 | FAN CASE |
| 501 | 6685401 | CHAIN COVER 12" |
| 501 | 6685439 | CHAIN COVER 14" |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Tanaka websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Tanaka brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
