Tanaka Spare Parts for Chain Saw ECS-3350D
€1.68
Tax included
Tanaka Spare Parts for Chain Saw ECS-3350D
Tanaka original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Chain Saw ECS-3350D.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Chain Saw ECS-3350D
Tanaka original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Chain Saw ECS-3350D.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| Chainsaw ECS-3350D | ||
| # | Part Num. | Description |
| 1 | 6687468 | SPARK PLUG CAP ASS'Y |
| 3 | 6685457 | CYLINDER SET |
| 4 | 6685724 | CYLINDER GASKET |
| 5 | 6685879 | PISTON SET |
| 6 | 6685078 | CIRCLIP |
| 7 | 6685331 | PISTON RING (XR1-1856) |
| 8 | 6686008 | PISTON PIN |
| 9 | 6684903 | HEX. HOLE BOLT M5X16/S |
| 12 | 6687700 | IGNITION COIL COMP. |
| 14 | 6695407 | HIGH TENSION SCREW 4X18WS |
| 15 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 16 | 6692900 | CORD INSULATOR TUBE |
| 22 | 6685095 | NEEDLE ROLLER 2.5X9.8 |
| 23 | 6685096 | BALL BEARING 6201 A2C3 |
| 25 | 6684668 | HEX.HOLE BOLT M5X20/S |
| 26 | 6687394 | MAGNETO ROTOR ASS'Y |
| 27 | 6685101 | D4E RETAINING RING |
| 28 | 6685105 | STARTER PAWL SPRING |
| 29A | 6685334 | STARTER PAWL |
| 30 | 6685103 | BOLT WASHER M7 |
| 31 | 6685104 | FLYWHEEL NUT |
| 32 | 6685098 | SHIM S T0.2 |
| 32 | 6685099 | SHIM S T0.3 |
| 32 | 6686475 | SHIM 0.4 |
| 33 | 6695222 | S.WASHER 7 |
| 41 | 6685173 | AIR VENT VALVE (B) |
| 42 | 6697231 | AIR VENT VALVE SET |
| 43 | 6684634 | HEX.HOLE BOLT 5X20/PS |
| 50 | 6686299 | AIRCLEANER COVER A SET, SPARE |
| 51 | 6689735 | CLEANER COVER BOLT |
| 52 | 6690064 | AIRCLEANER ELEMENT COMP. |
| 53 | 6689934 | CARBURETOR INSULATOR SET,SPARE |
| 53A | 6689935 | INSULATOR SET |
| 54 | 6689870 | INLET MANIFOLD GASKET |
| 54A | 6689871 | INSULATOR GASKET |
| 55 | 6690001 | CARBURETOR INSULATOR RUBBER |
| 56 | 6689805 | REED VALVE HOLDER |
| 56A | 6689806 | VALVE HOLDER |
| 57 | 6689802 | REED VALVE |
| 57A | 6689803 | REED VALVE |
| 61 | 6695350 | SCREW 5X45S |
| 63 | 6684864 | SMALL WASHER 5 |
| 66 | 6687344 | AIRCLEANER COVER B |
| 67 | 6684668 | HEX.HOLE BOLT M5X20/S |
| 68 | 6684864 | SMALL WASHER 5 |
| 69 | 6685224 | IDLE SPONGE |
| 70 | 6687978 | SPONGE H/L 10L |
| 71 | 6690355 | AIR CLEANER SPONGE |
| 72 | 6687182 | SEAL COVER |
| 82 | 6692734 | MUFFLER GASKET |
| 88 | 6684661 | WASHER 5 |
| 101 | 6691121 | OIL PIPE B |
| 102 | 6692312 | CLIP 7 |
| 103 | 6684661 | WASHER 5 |
| 104 | 6690919 | OIL FILTER |
| 105 | 6685249 | OIL FILTER BODY ASS'Y |
| 106 | 6693873 | THROTTLE WIRE COMP., SPECIAL |
| 108 | 6685139 | PRIMING PUMP COMP. |
| 110 | 6692292 | RUBBER PIPE |
| 113 | 6697846 | RETURN GROMMET |
| 115 | 6687956 | ADJUSTER CAP |
| 116 | 6692590 | GROMMET |
| 117 | 6692513 | CHOKE BUTTON COMP. |
| 118 | 6687976 | GROMMET |
| 120 | 6692159 | OIL TANK CAP ASS'Y |
| 121A | 6692121 | TANK CAP ASS'Y |
| 122 | 6684872 | LOCK NUT M6 |
| 131 | 6692906 | RECOIL STARTER ASS'Y |
| 132 | 6685275 | TAPPING SCREW D5X14 |
| 133 | 6689681 | BRAKE SHAFT WASHER |
| 134 | 6693060 | STARTER PULLEY |
| 136 | 6693093 | RECOIL SPRING CASE ASS'Y |
| 139 | 6685191 | TAPPING SCREW D4.5X20 |
| 151 | 6684700 | INLET SCREEN |
| 153 | 6685210 | SCREW |
| 154 | 6685212 | PUMP GASKET |
| 155 | 6685213 | PUMP DIAPHRAGM |
| 157 | 6692048 | HIGH/LOW ADJUST SPRING |
| 158 | 6685217 | CONTROL LEVER |
| 159 | 6685218 | HINGE PIN SET SCREW |
| 161 | 6685219 | HINGE PIN |
| 163 | 6690827 | METERING DIAPHRAGM COMP. |
| 164 | 6685220 | DIAPHRAGM PACKING-METERING |
| 165 | 6685215 | NEEDLE VALVE |
| 166 | 6685297 | IDLE ADJUST SPRING |
| 167 | 6685298 | IDLE ADJUST SCREW |
| 169 | 6690897 | HIGH ADJUSTMENT SPRING |
| 170 | 6685223 | SET SCREW |
| 192 | 6686763 | OIL PUMP COVER |
| 193 | 6691223 | OIL PIPE A |
| 194 | 6686645 | SCREW GEAR |
| 195 | 6691400 | AIR VENT SPONGE |
| 196 | 6687324 | OIL PUMP ASS'Y |
| 197 | 6690956 | OIL ADJUST GROMMET |
| 198 | 6691070 | OIL PUMP ADJUSTER |
| 199 | 6697917 | O RING |
| 200 | 6686681 | OIL PUMP CASE SET, SPARE |
| 201 | 6697917 | O RING |
| 202 | 6685275 | TAPPING SCREW D5X14 |
| 203 | 6685154 | FUEL PIPE |
| 204 | 6685155 | CHAIN CATCHER |
| 221 | 6685166 | NUT |
| 221 | 6687105 | CHAIN BAR CLAMP NUT |
| 222 | 6685142 | CLUTCH COMP. |
| 223 | 6685143 | NEEDLE BEARING |
| 224 | 6689013 | CLUTCH HOUSING COMP.3/8 |
| 225 | 6685145 | CLUTCH WASHER |
| 226 | 6685161 | TAPPING SCREW D4X10 |
| 227 | 6690790 | PLATE |
| 228 | 6685146 | CRANK SHAFT COLLAR |
| 229 | 6685161 | TAPPING SCREW D4X10 |
| 232 | 6695269 | SCREW 2.6X5 |
| 234B | 6698986 | CHAIN PULLER |
| 235 | 6685168 | GEAR (A) |
| 237 | 6690756 | GUIDE PLATE B |
| 247 | 6687072 | TENSION ADJUSTMENT BOLT ASS'Y |
| 261 | 6695394 | SCREW 5X25 PS |
| 262 | 6695157 | U-NUT 5 |
| 264 | 6684864 | SMALL WASHER 5 |
| 265 | 6688480 | DAMPER COLLAR A |
| 266 | 6688117 | DAMPER A |
| 267 | 6695157 | U-NUT 5 |
| 269 | 6692680 | PUSH PIN CAP |
| 270 | 6686447 | STOPPER SPRING |
| 275 | 6685069 | NUT M4 |
| 279 | 6688412 | DAMPER B |
| 280 | 6688485 | DAMPER COLLAR B |
| 281 | 6695107 | TAPPING SCREW 5X35 |
| 282 | 6695107 | TAPPING SCREW 5X35 |
| 283 | 6693462 | FRONT HAND GUARD |
| 502 | 6685256 | CHAIN COVER 14" |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Tanaka websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Tanaka brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
