Tanaka Spare Parts for Engine Chain Saw TCS 33EB
€1.04
Tax included
Tanaka Spare Parts for Engine Chain Saw TCS 33EB
Tanaka Original spare parts at attractive prices never seen on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Engine Chain Saw TCS 33EB.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Tanaka Spare Parts for Engine Chain Saw TCS 33EB
Tanaka Original spare parts at attractive prices never seen on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Engine Chain Saw TCS 33EB.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
| Engine Chain Saw Tanaka TCS 33EB Pag.1 |
||
| # | Part Num. | Description |
| 1 | 6685416 | CHAIN BAR CLAMP NUT |
| 2 | 6696331 | NAME PLATE |
| 2 | 6696332 | NAME PLATE |
| 3 | 6685406 | SIDE COVER SUB |
| 4 | 6685387 | BRAKE SUPPORT |
| 5 | 6685388 | BRAKE LINK |
| 6 | 6685392 | BRAKE LINK COVER |
| 7 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 8 | 6685389 | BRAKE SPRING |
| 9 | 6685362 | CLUTCH |
| 10 | 6685403 | CLUTCH HOUSING |
| 11 | 6685361 | NEEDLE BEARING (D) |
| 12 | 6685414 | CLUTCH WASHER |
| 13 | 6685360 | CRANK SHAFT COLLAR |
| 14 | 6685390 | BRAKE BAND |
| 15 | 6685415 | TAPPING SCREW D3X8 |
| 16B | 6698986 | CHAIN PULLER |
| 17A | 6685394 | GUIDE PLATE |
| 18A | 6697852 | SAW CHAIN (3/8X12") 91PX-45XJ |
| 18A | 6697854 | SAW CHAIN (3/8X14") 91PX-52XJ |
| 18A | 6697889 | SAW CHAIN (3/8X16") 91PX-57XJ |
| 19 | 6685259 | BAR 12 INCH |
| 19 | 6685261 | BAR 14 INCH |
| 19 | 6685395 | BAR 16 INCH |
| 19A | 6696993 | CHAIN BAR 12 INCH 3/8 SPROCKET PRC |
| 19A | 6696994 | CHAIN BAR 14 INCH 3/8 SPROCKET PRC |
| 20 | 6685405 | CYLINDER (B) |
| 20 | 6685404 | CYLINDER (A) |
| 21A | 6699319 | SPARK PLUG ASS'Y BPMR6A |
| 21A | 6699317 | SPARK PLUG ASS'Y BPM6A |
| 22 | 6685317 | COVER PACKING (B) |
| 23 | 6685315 | SCAVENGING COVER (B) |
| 24 | 6696315 | SEAL LOCK HEX. SOCKET HD. BOLT M4X8 |
| 25 | 6685318 | INTAKE PACKING |
| 26A | 6698897 | INTAKE (A) |
| 27A | 6696860 | SEAL LOCK HEX. SOCKET HD. BOLT M4X10 |
| 28A | 6698898 | CARBURETOR INSULATOR (A) |
| 29 | 6696316 | O-RING |
| 30 | 6685321 | PULSE GUIDE |
| 31A | 6685437 | CARBURETOR (C) WLB-3 |
| 31B | 6698683 | CARBURETOR ASS'Y (E) WLB-5A |
| 32A | 6696843 | CLEANER SUPPORT |
| 33 | 302089 | TAPPING SCREW (W/FLANGE) D5X20 (BLACK) |
| 34 | 6685408 | WASHER 5 |
| 34 | 6685408 | WASHER 5 |
| 35 | 6696317 | HEX. SOCKET HD. BOLT M5X45 |
| 36 | 6699731 | IDLE ADJUSTING SCREW |
| 36A | 6696318 | IDLE ADJUSTING SCREW |
| 37A | 6696319 | PASSAGE GASKET |
| 38A | 6696320 | PASSAGE PLATE |
| 39A | 6684692 | PUMP GASKET |
| 40 | 6699645 | PUMP BODY |
| 40A | 6696322 | PUMP BODY |
| 41A | 6691305 | HINGE PIN SET SCREW |
| 42 | 6696323 | METERING LEVER SPRING |
| 43 | 6685217 | CONTROL LEVER |
| 44 | 6684690 | METERING DIAPHRAGM |
| 45 | 6685220 | DIAPHRAGM PACKING-METERING |
| 46 | 6685222 | DIAPHRAGM COVER-METERING |
| 47A | 6684699 | SET SCREW |
| 48A | 6684693 | PUMP DIAPHRAGM |
| 49 | 6684700 | INLET SCREEN |
| 50 | 6685215 | NEEDLE VALVE |
| 51 | 6685219 | HINGE PIN |
| 52A | 6698700 | GLASS WASHER |
| 53B | 6699989 | IGNITION COIL |
| 54 | 6696326 | HEX. SOCKET HD. BOLT (W/FLANGE) M4X18 |
| 55A | 6699991 | CORD |
| 56A | 6685331 | PISTON RING (XR1-1856) |
| 57 | 6685326 | CIRCLIP |
| 58 | 6685325 | PISTON |
| 58 | 6696313 | PISTON |
| 59 | 6685327 | PISTON PIN |
| 60 | 6685316 | COVER PACKING (A) |
| 61 | 6685314 | SCAVENGING COVER (A) |
| 62 | 6685396 | CRANK WORM ASS'Y |
| 63 | 6685330 | WORM |
| 64 | 6685329 | OIL SEAL |
| 65 | 6685328 | BALL BEARING |
| 66 | 6685324 | CRANK SHAFT |
| 67A | 6699993 | MAGNETO SUB ASS'Y |
| 68 | 6685336 | RETAINING RING D4 |
| 69B | 6699990 | MAGNETO ROTOR |
| 70 | 6685335 | STARTER PAWL SPRING |
| 71 | 6685334 | STARTER PAWL |
| 72 | 6685410 | BOLT WASHER D8 |
| 73 | 6685337 | FLYWHEEL NUT |
| 74 | 6685311 | CLIP |
| 75A | 6698715 | FUEL PIPE |
| 75B | 6698998 | FUEL PIPE |
| 76 | 6685308 | FUEL GROMMET (A) |
| 77A | 6600351 | PUMP FILTER |
| 78 | 6685339 | CRANK CASE |
| 79 | 6685412 | SEAL LOCK HEX. SOCKET HD. BOLT M5 |
| 80 | 6685313 | DAMPER (B) |
| 81 | 6685407 | BOLT WASHER D5 |
| 82 | 6685249 | OIL FILTER BODY ASS'Y |
| 83 | 6685310 | OIL FILTER BODY |
| 84 | 6685413 | DAMPER SET BOLT |
| 85 | 696314 | DISTANCE PIECE (B) |
| 86 | 6696327 | DAMPER (A) |
| 87 | 6685363 | CHAIN CATCHER |
| 88B | 6696329 | SPIKE SET |
| 89 | 6685369 | CHOKE ROD RUBBER |
| 90 | 6685368 | CHOKE BUTTON |
| 91A | 6601275 | STOP SWITCH |
| 92 | 6685307 | ENGINE CASE |
| 93 | 6685365 | CORD (A) |
| 94 | 6685370 | AIR VENT VALVE (B) |
| 95 | 6685371 | AIR VENT SPONGE |
| 96A | 6685179 | TANK CAP PACKING |
| 97A | 6698854 | FUEL TANK CAP ASS'Y (VERMILION) |
| 97A | 6698855 | FUEL TANK CAP ASS'Y (GREEN) |
| 97B | 6698358 | FUEL TANK CAP ASS'Y (BLACK) |
| 98 | 6685391 | NEEDLE ROLLER D3 |
| 99 | 949454 | SPRING WASHER M5 (10 PCS.) |
| 100B | 6601421 | PLUG CAP |
| 101 | 6699186 | PLUG CAP METAL |
| 121A | 6699415 | SEAL LOCK HEX. SOCKET HD. BOLT M5X16 |
| 122B | 6699412 | EXHAUST PIPE (B) |
| 122C | 6601472 | EXHAUST PIPE (C) |
| 123B | 6699414 | GAUZE FIXING PLATE (B) |
| 123C | 6601473 | GAUZE FIXING PLATE (C) |
| 124A | 6699413 | MUFFLER GAUZE (B) |
| 124B | 6601474 | MUFFLER GAUZE (C) |
| 125A | 6699411 | MUFFLER (B) |
| 125B | 6601471 | MUFFLER (C) |
| 126 | 6685346 | MUFFLER PACKING |
| 127 | 6685382 | CLEANER COVER |
| 128A | 6696849 | CLEANER KNOB |
| 129A | 6696846 | THROTTLE ROD |
| 130A | 6698805 | REAR HANDLE GRIP |
| 131 | 6685350 | TRIGGER LOCKOUT (VERMILION) |
| 132A | 6600341 | THROTTLE LEVER SPRING |
| 133 | 6685282 | SPRING PIN 5X25 |
| 134 | 6685348 | THROTTLE LEVER |
| 135A | 6685351 | INNER CAP |
| 136 | 6685347 | REAR HANDLE |
| 136A | 6698685 | REAR HANDLE |
| 137A | 6698997 | FRONT HANDLE |
| 138 | 6685378 | CLEANER ELEMENT |
| 139 | 6685381 | SHUTTER PLATE |
| 140 | 6685376 | CYLINDER COVER |
| 140 | 6685377 | CYLINDER COVER |
| 140A | 6698687 | CYLINDER COVER |
| 140A | 6699001 | CYLINDER COVER |
| 141 | 6696335 | CAUTION LABEL (D) |
| 141 | 6696336 | CAUTION LABEL (E) |
| 142 | 6685373 | BRAKE HANDLE |
| 143 | 6685374 | BRAKE LEVER SPRING |
| 144 | 6685356 | NEEDLE ROLLER 2.5X19.8 |
| 145A | 6699118 | PUMP CASE |
| 146 | 6685355 | PUMP GEAR SPRING |
| 147 | 6685354 | PUMP GEAR |
| 148 | 6685357 | OIL PIPE |
| 149 | 6685359 | PUMP COVER |
| 150 | 6685358 | PIPE JOINT |
| 151A | 6600345 | AIR DEFLECTOR |
| 152 | 6698931 | FUEL GROMMET |
| 160B | 6696847 | RECOIL STARTER |
| 160C | 6698684 | RECOIL STARTER (C) |
| 161 | 6696339 | TANAKA LABEL |
| 161 | 6696340 | TANAKA LABEL |
| 162 | 305558 | TAPPING SCREW (W/FLANGE) D5X25 (BLACK) |
| 163A | 6601442 | FUEL PIPE |
| 164A | 6697846 | RETURN GROMMET |
| 165A | 6601459 | FUEL PIPE |
| 166 | 6685139 | PRIMING PUMP COMP. |
| 167 | 6698847 | INTAKE SPACER |
| 168 | 6685308 | FUEL GROMMET (A) |
| 169 | 6699000 | PRIMER LABEL |
| 170 | 6698923 | CAUTION LABEL (L) |
| 171 | 6698921 | TANK MARK LABEL (50:1) |
| 171 | 6698922 | TANK MARK LABEL (25:1) |
| 172 | 6698999 | START LABEL |
| 173 | 6699475 | SET SCREW |
| 174 | 6699481 | REEL |
| 175 | 6699480 | SPIRAL SPRING CASE |
| 176 | 6699476 | SET SCREW |
| 177 | 6699478 | CAM PLATE - DISCONTINUED |
| 178 | 6699479 | DAMPER SPRING |
| 179 | 6699485 | REEL |
| 180 | 6699468 | STARTER ROPE |
| 180 | 6699469 | STARTER ROPE |
| 181 | 6699465 | ROPE STOPPER |
| 182 | 6699467 | STARTER KNOB |
| 183 | 6699471 | STARTER HANDLE ASS'Y |
| 183 | 6699473 | STARTER HANDLE ASS'Y |
| 184 | 6699486 | FAN CASE |
| 184A | 6699494 | FAN CASE |
| 185 | 329983 | HEX. SOCKET HD. BOLT (W/FLANGE) M4X10 |
| 185B | 370899 | HEX.SOCKET BOLT M4X6 |
| 186 | 6699407 | MUFFLER SET (REPAIR) TO YEAR 2013 |
| 186 | 6699408 | MUFFLER SET (REPAIR) |
| 186A | 6601475 | EXHAUST (C) ASS'Y |
| 187A | 6600344 | IGNITION COIL + FLYWHEEL SET |
| 188 | 6600343 | CORD INSULATION TUBE |
| STANDARD ACCESSORIES Pag.2 |
||
| 501 | 6685401 | CHAIN COVER 12" |
| 501 | 6685439 | CHAIN COVER 14" |
| 501 | 6685440 | CHAIN COVER 16" |
| 502 | 6685402 | COMBI BOX SPANNER 10/19MM |
| OPTIONAL ACCESSORIES Pag.3 |
||
| 601 | 6696995 | CHAIN BAR 16 INCH 3/8 SPROCKET PRC |
| 601A | 6696993 | CHAIN BAR 12 INCH 3/8 SPROCKET PRC |
| 601A | 6696994 | CHAIN BAR 14 INCH 3/8 SPROCKET PRC |
| 602 | 6696329 | SPIKE SET |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Tanaka websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Tanaka brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
