Stiga Spare Parts for Chain Saw SP 375
€1.56
Tax included
Stiga Spare Parts for Chainsaw SP 375
Stiga original spare parts for to replace broken parts for to fix Chainsaw SP 375/203714002-11-2017.A practical, powerful and functional chainsaw, for all types of garden work, in the countryside, in woods and forests for cutting bushes, branches, trees and trunks, with spare parts at the best price on the web.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Stiga Spare Parts for Chainsaw SP 375
Stiga original spare parts for to replace broken parts for to fix Chainsaw SP 375/203714002-11-2017.
In the following table, look for the model of the Chain Saw and the respective parts of the code.
<
| Chain Saw SP 375/203714002-11-2017 Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 118800242/0 | Cylinder Assy |
| 2 | 2432040 | Nut |
| 3 | 112581500/0 | Grower |
| 4 | 2312090 | Flat Washer |
| 5 | 123878022/0 | Screw |
| 6 | 118800243/0 | Cover Plate |
| 7 | 118550582/0 | Muffler |
| 8 | 118550583/0 | Muffler Gasket |
| 9 | 118550584/0 | Screw |
| 10 | 2135030 | Screw |
| 12 | 118550585/0 | Intake Manifold Gasket |
| 13 | 118550586/0 | Intake Manifold |
| 14 | 118550587/0 | Carburettor Gasket |
| 15 | 118550588/0 | Cylinder Base Gasket |
| 16 | 118550589/0 | Piston Ring |
| 17 | 118800244/0 | Piston Pin |
| 18 | 118550590/0 | Washer, Piston Pin |
| 19 | 118800245/0 | Piston |
| 20 | 118800246/0 | Bearing |
| 21 | 118550591/0 | Needle Bearing |
| 22 | 118800247/0 | Crankshaft |
| 23 | 123072005/0 | Flywheel Key |
| 24 | 118800248/0 | Crank Case |
| 25 | 3112030 | Ball Bearing |
| 26 | 118800249/0 | Crankcase Gasket |
| 27 | 118800250/0 | Crank Case |
| 29 | 118550592/0 | Seal Ring |
| 30 | 2135050 | Screw |
| 31 | 118550593/0 | Screw |
| 34 | 118550596/0 | Spike |
| 35 | 2135180 | Screw |
| 36 | 118550597/0 | Chain Guard |
| 37 | 118800251/0 | Screw |
| 38 | 118550598/0 | Bar Plate |
| 39 | 123878020/0 | Screw |
| 40 | 118550599/0 | Seal Ring |
| 42 | 123878021/0 | Screw |
| 43 | 2321050 | Washer |
| 44 | 118550601/0 | Earth Cable |
| 45 | 123120004/0 | Nut |
| 51 | 118550603/0 | Clutch Ass.Y |
| 55 | 118800252/0 | Sprocket Washer |
| 56 | 118550604/0 | Clutch Drum Assy |
| 57 | 118550605/0 | Needle Bearing |
| 58 | 118550606/0 | Worm |
| 59 | 118800253/0 | Oil Pump Cap |
| 60 | 118550607/0 | Oil Pump Assy |
| 61 | 118800254/0 | Tube |
| 62 | 118550608/0 | Washer |
| 63 | 118800255/0 | Pickup Oil |
| 65 | 118800256/0 | Connection |
| 66 | 118550609/0 | Oil Filter Ass.Y |
| 67 | 118802952/0 | Oil Nozzle |
| 70 | 8724091 | Diaphragm Gasket Set |
| 71 | 118800210/0 | Carburetor |
| 72 | 118800211/0 | Intake Manifold |
| 73 | 118800212/0 | Screw |
| 74 | 118800203/0 | Primer |
| 75 | 118800204/0 | Pipe |
| 76 | 3657050 | Spark Plug Spring |
| 77 | 3748880 | Spark Plug Cap |
| Chain Saw SP 375/203714002-11-2017 Housing Pag.2 | ||
| 1 | 118801175/0 | Clutch Ho. W/Br. Assy Yellow |
| 2 | 123878017/0 | Screw |
| 3 | 123044213/0 | Bushing |
| 4 | 123044214/0 | Bushing |
| 5 | 118800765/0 | Hand Guard |
| 6 | 118800748/0 | Balance Weigth |
| 7 | 123430572/0 | Spring |
| 8 | 118800747/0 | Spring |
| 9 | 123657007/0 | Washer |
| 10 | 112154320/0 | Nut |
| 11 | 323670001/0 | Plate |
| 12 | 118800745/0 | Front Guard Spring |
| 13 | 118800257/0 | Bar Plate |
| 14 | 123753001/0 | Pin |
| 15 | 383315051/0 | Chain Brake Lever |
| 17 | 123753000/0 | Needle |
| 18 | 323315067/0 | Lever |
| 19 | 118800746/0 | Brake Spring |
| 20 | 118800185/0 | Brake Band |
| 21 | 123878023/0 | Screw |
| 22 | 323109525/0 | Brake Spring Cover |
| 24 | 118800186/0 | Nut |
| 25 | 118800767/0 | Filter Cover |
| 26 | 118800756/0 | Knob |
| 27 | 118800188/0 | Air Filter |
| 28 | 118801177/0 | Clutch Housing Yellow |
| 30 | 118800740/0 | Pin |
| 31 | 118800768/0 | Knob |
| 32 | 118800749/0 | Cap |
| 34 | 118800189/0 | Screw |
| 35 | 118800742/0 | Grommet |
| 36 | 118800264/0 | Grommet Air-Lever |
| 37 | 118800755/0 | Choke Knob |
| 38 | 118800758/0 | Air Conveyor |
| 39 | 118801172/0 | Starter Assy Yellow |
| 42 | 118800754/0 | Starter Cup |
| 43 | 118800753/0 | Starter Spring |
| 44 | 118801178/0 | Wire |
| 45 | 118800760/1 | Starter Pulley Assy |
| 47 | 118800741/0 | Starter Spring |
| 48 | 118800759/0 | Starter Handle |
| 50 | 123878024/0 | Screw |
| 51 | 123878025/0 | Screw |
| 52 | 118800743/0 | Dust Cover |
| 53 | 118800266/0 | Shock Absorber |
| 54 | 123878022/0 | Screw |
| 55 | 118800194/0 | Shock Absorber |
| 56 | 118800195/0 | Cap |
| 57 | 118800196/0 | Spring |
| 58 | 118800197/0 | Handle |
| 59 | 323208402/0 | Plate |
| 60 | 118800198/0 | Breather Valve Ass.Y |
| 64 | 118800744/0 | Grommet |
| 65 | 112728124/0 | Screw |
| 66 | 118800255/0 | Pickup Oil |
| 67 | 118800214/0 | Fuel Filter |
| 68 | 118801067/0 | Screw |
| 69 | 118801065/0 | Chain Tightener Block |
| 70 | 118801066/0 | Pinion |
| 72 | 118800199/0 | Fuel Filter |
| 73 | 118801173/0 | Crankcase Yellow |
| 74 | 118800201/0 | Spring |
| 75 | 118800761/0 | Fuel Cap Assy |
| 79 | 118800762/0 | Oil Tank Cap |
| 82 | 123510098/0 | Elastic Pin |
| 83 | 118800205/0 | Safety Lever |
| 84 | 118800206/0 | Spring |
| 85 | 118800207/0 | Throttle Lever |
| 86 | 118800750/0 | Spring |
| 87 | 118800763/0 | Handle Cover |
| 89 | 118800213/0 | Stop Wire |
| 90 | 118800202/0 | Switch |
| 96 | 118800752/0 | Crankcase |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Stiga websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Stiga brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
SP 375/203714002-11-2017
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
