Lavor Pressure Cleaner XTR-R 1007 Parts
€65.35
Tax included
Lavor Original Parts for Pressure Cleaner XTR-R 1007
Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner 8.052.0846 - IDRO XTR-R 1007 230/50 TS -G- LAVORFix Your Pressure Cleaner IDRO XTR 1007 R. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner XTR-R 1007
Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner 8.052.0846 - IDRO XTR-R 1007 230/50 TS -G- LAVOR
In the following tables, look for the spare part and its respective code.
| 8.052.0846 - IDRO XTR-R 1007 230/50 TS -G- LAVOR | ||
| Chassis Pag.1 | ||
| Pos. | Codice | Descrizione |
| 1 | 4.013.0965 | UPPER COVER |
| 2 | 4.008.2567 | RIGHT CABINET RIO-R |
| 3 | 4.008.2566 | LEFT CABINET RIO-R |
| 4 | 5.011.0536 | HANDLE |
| 5 | 4.608.0027 | BLACK PLUG D.30 FOR TANK |
| 6 | 7.100.2488 | INSTRUCTION MANUAL RIO-R XTR-R LAVOR |
| 7 | 3.700.0036 | GUN 26Mpa-100°C-30lt/min G3/8M - M22 |
| 8 | 4.618.0049 | HOSE R1 1/4 8MT 3/8F-M22 (MAX 21MPa) |
| 9 | 3.712.0019 | HI/LO LANCE 025 M22 (MAX 220BAR 3200PSI) -RED- RAL.3020 |
| 10 | 3.100.0062 | QUICK COUPLING WITH VALVE (3029) |
| 11 | 3.100.0510 | TRANSP.QUICK COUPLING W/INSPECT.FILTER |
| Base Pag.2 | ||
| 1 | 5.611.0313 | CONTROL PANEL 230V |
| 2 | 4.008.1026 | MOTOR CONVEYER RIGHT+LEFT 2100W |
| 3 | 4.007.0355 | L-SHAPED BRACKET FOR MOTOR SUPPORT |
| 4 | 6.005.0640 | INLET EXTENSION KIT |
| 5 | 5.001.I763C | MOTORPUMP PT'03 230/50 TS W/THERM.-SUCT. 7'10AL THREAD CAPS HE |
| 6 | 4.612.0074 | PVC GROUND WIRE D.2,5 L=500 |
| 7 | 5.609.0260 | MAX PRESSURE VALVE 250BAR 1/8 |
| 8 | 5.611.0282 | DIESEL PUMP + VALVE |
| 9 | 4.007.0570 | CHIMNEY EXTENSION PATRIOT |
| 10 | 6.005.0645 | KIT CAP FOR TANK WITH SEAL |
| 11 | 4.008.2565 | GASOIL TANK RIO-R |
| 12 | 5.011.0558 | GASOIL FILTER GROUP |
| 13 | 5.009.1187 | WIRING 3X1,5 PVC MT 6 SCHUKO PLUG W/FILTER |
| 14 | 6.605.0075 | KIT WHEEL+STUD+STOP WHEEL (ONTARIO/TUCSON) |
| 15 | 4.008.2596 | WASHER 30X17 th.2.5 |
| 16 | 4.007.0602 | SUPPORT BRACKET |
| ASSIEME MANICO XTR-R Pag.3 | ||
| 1 | 5.013.0093 | HANDLE FOR XTR-R |
| 2 | 4.607.1028 | HOOK FOR HANDLE |
| 3 | 4.007.0607 | INTERNAL DETERGENT TANK SUPPORT BRACKET |
| 4 | 4.008.0868 | DETERGENT TANK |
| 5 | 4.007.0608 | EXTERNAL DETERGENT TANK SUPPORT BRACKET |
| Corredo Pag.4 | ||
| 1 | 3.100.0062 | QUICK COUPLING WITH VALVE (3029) |
| 2 | 3.100.0510 | TRANSP.QUICK COUPLING W/INSPECT.FILTER |
| 3 | 4.608.0027 | BLACK PLUG D.30 FOR TANK |
| ASSIEME TELAIO+CALDAIA XTR-R Pag.5 | ||
| 1 | 5.009.1126 | TRANSFORMER WITH CABLES (FKX-RIO) |
| 2 | 4.008.0848 | GASKET NEW TRANSFORMER FKX |
| 3 | 3.100.0075 | CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O-RING |
| 4 | 4.005.0194 | CAP FOR BOILER FKX |
| 5 | 5.009.0637 | BOILER CAP KIT |
| 6 | 4.006.0187 | NOZZLE HOLDER PIN |
| 7 | 3.104.0031 | GAS OIL NOZZLE 0.50 60 H |
| 8 | 6.005.0307 | COMPLETE DEFLECTOR WITH ELECTRODE |
| 9 | 5.013.0027 | DISK HEAD HOLDER |
| 10 | 5.013.0092 | BODY BOILER PATRIOT/RIO-R |
| 11 | 3.099.0124 | RING LOCKER X SHAFT D.42 UNI 7435 |
| 12 | 4.007.0303 | TUBE D.40 L=325 FE 37 PREZINCE D |
| 13 | 4.007.0180 | BOILER STAY M6X352 |
| 14 | 4.604.0028 | COIL D.202 SINGLE FKX ECO |
| 15 | 4.608.0038 | RUBBER PROTECTION FOR THERMIC |
| 16 | 3.403.0003 | THERMAL PROTECTOR L01.090.05.7 00 |
| 17 | 4.606.0002 | DELIVERY CONNECTION |
| 18 | 4.008.2475 | SEAL FOR HEATING COIL |
| 19 | 4.007.0322 | TUBE FKX L=42 |
| 20 | 6.605.0141 | HOBBY BOILER REFRACTORY KIT |
| 21 | 4.007.0599 | JUNCTION |
| 22 | 4.006.0283 | FERRULE M22x1,5 L=16. |
| 23 | 3.304.0056 | BURNER MOTOR 230/50 C/W FAN, FLANGE, CABLES AND COVER |
| 24 | 4.012.0102 | CABLE L=600 SEC.0,75 IEC227-3/1979 |
| 25 | 4.007.0158 | BOILER PAD |
| 26 | 4.005.0186 | BOILER BASE PLATE X FKX (LIKE DIE CASTING ) |
| GRUPPO POMPA GASOLIO (ULKA) PATRIOT 24220056 Pag.6 | ||
| 1 | 3.551.0014 | DIESEL PUMP 48W 230/50 |
| 2 | 5.009.0304 | ADJUSTING VALVE SET (SPRING L=20) |
| ASSIEME QUADRO ELETTRICO 230V XTR-R Pag.7 | ||
| 1 | 4.008.0447 | ELECTRICAL BOX COVER |
| 2 | 3.401.0178 | SWITCH 0/1 BLACK BOTTON IP55 12/10 |
| 3 | 3.403.0012 | ELECTRICAL BOARD |
| 4 | 3.405.0011 | TERMINAL BOARD PA 32/6 |
| 5 | 4.608.0561 | GASKET |
| 6 | 4.008.0446 | ELECTRICAL BOX BASE |
| CABLAG.ALIMELINTAZIONE.3X1,5 PVC MT 6,4 SP.SCHUKO C/FILTRO ANTID. Pag.8 | ||
| 1 | 3.499.0539 | WIRE HARNESS |
| 2 | 4.012.0292 | CABLE H05VV-F 3X1,5 MT.6,4 F/F SCHUKO PLUG |
| MTP.SP.PT'03 230/50 7'10 C/TERM.-TS-ASP. 14.5KG TEST.T.FIL.S.PL.(8850) Pag.9 | ||
| 1 | 5.009.0924 | 8850 MOTOR 230/50 W/CAPACITOR-THERMAL 17AM-D 140G |
| 2 | 6.005.0180 | KIT 166 FOOTSTEP BEARING 3047 PT' 03-SD |
| 3 | 4.007.0205 | PIN 10X70 |
| 4 | 5.009.1020 | 7'10 WOBBLE PLATE ASSEMBLY W/PLASTIC INSERT+RING GEAR Z 50 |
| 5 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 6 | 5.009.0997C | BODY GUIDE+HEAD(TPAV) W/TS 14.5KG-SUCT.-THREAD CAPS-PL.CHECK VA |
| ASSIEME VALVOLA REGOLAZIONE PRESSIONE X POMPA ULKA (MOLLA L=20) Pag.10 | ||
| 1 | 4.006.0259 | HOSE HOLDER FOR DIESEL FLOW ADJUSTMENT |
| 2 | 4.006.0260 | NUT 10X1 FOR DIESEL FLOW ADJUSTMENT |
| 3 | 4.007.0306 | SPRING FOR PRESS.REG.VALVE FKX D.5,4-7,8 L=20 WIRE 1,8 |
| 4 | 3.200.0050 | O-RING 5.28X1.78 |
| 5 | 4.008.0856 | BALL VALVE |
| 6 | 4.006.0254 | BY-PASS DIESEL VALVE |
| 7 | 3.200.0021 | OR GASKET 6,75x1,78 RIF.106 |
| 8 | 3.100.0057 | CONNECTION D.4X1/8"M VITON O-RING |
| GRUPPO C.GUIDA C/TS 14.5KG-ASP.+TEST.TAPPI FIL. PT'03-TPAV Pag.11 | ||
| 1 | 5.007.0281C | PISTON BODY GUIDE PT'03 W/TS 14.5KG-SUCTION |
| 2 | 6.005.0282 | KIT 257 O-RING SEAL |
| 3 | 5.008.0298C | PT'03 HEAD (TPAV) D.12 W/ALUM.THREAD CAPS |
| CORPO GUIDA PT'03 C/TS 14.5KG-ASP. Pag.12 | ||
| 1 | 5.009.1022 | COMPLETED VALVE TS PT'03 CABLE L=530 SPRING 14.5KG (WHITE FASTON |
| 2 | 6.005.0277 | KIT 252 |
| 3 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 4 | 6.005.0226 | KIT "O-RING FOR PT'03" |
| 5 | 4.005.0263C | PISTON BODY GUIDE PT'03 WITH SUCTION VALVE |
| 6 | 6.005.0181 | KIT 167 LW PISTON |
| TESTATA PT'03 (TPAV) D.12 C/TAPPI FIL.ALL. Pag.13 | ||
| 1 | 6.005.0595 | KIT HEAD VALVE KIT +CAPS PT'03 |
| 2 | 4.005.0302 | PT'03 HEAD WITH THREAD FOR VALVE CAPS (TPAV) |
| 3 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
