Lavor Pro Original Parts for Floor Scrubber Drier SPRINTER
€14.15
Tax included
Lavor Pro Original Parts for Floor Scrubber Drier SPRINTER
Fix Your Floor Scrubber Drier SPRINTER Lavor Pro - 8.501.0501. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Pro Original Parts for Floor Scrubber Drier SPRINTER
Fix Your Floor Scrubber Drier SPRINTER Lavor Pro - 8.501.0501. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| FLOOR SCRUBBER DRIER SPRINT 230/50 GREY/GREEN LAVOR PRO 8.501.0501 | ||
| Pos. | Code | Descrition |
| 001 | 5.009.0482 | SWITCH + PROTECTION COVER ASSEMBLY |
| 002 | 4.508.0012 | UPPER COVER HANDLE GREY RAL 7043B |
| 003 | 4.508.0834 | SWITCH ON/OFF COVER (YELLOW PANT.108C) |
| 004 | 4.508.0838 | TANK CAP (YELLOW PANT.108C) |
| 005 | 5.509.1742 | ASSEMBLY FOR FILTER (YELLOW) BY-PASS D.10 |
| 006 | 6.505.0041 | VALVE RUBBER GASKET NR-EPDM 55 SH MW |
| 007 | 4.508.0029 | FILTER GASKET 10X12 L=690 |
| 008 | 5.509.0415 | GREY SOLUTION TANK WITH WASHER AND GASKET |
| 009 | 6.505.0041 | SOLUTION TANK GASKET DIAM. 46X18 SP.2 MW |
| 010 | 6.505.0041 | VALVE FOR TANK MW |
| 011 | 4.508.0459 | BLACK WATER TANK (GREY) |
| 012 | 5.509.0008 | ASSY FLEXIBLE HOSE L.800 MW |
| 013 | 5.009.0483 | SWITCH + PROTECTION COVER ASSEMBLY |
| 014 | 4.508.0021 | SOLUTION ACTUATOR GREY RAL 7043B |
| 015 | 4.508.0013 | HANDLE BACK PORTION GREY RAL 7043B |
| 016 | 4.508.0023 | CABLE HOLDER MW GREY RAL 7043 B |
| 017 | 3.099.0278 | BELT 336 RPP3-12 |
| 018 | 4.507.0001 | PULLEY Z20 MW |
| 019 | 4.506.0001 | WASHER |
| 020 | 4.508.0042 | PULLEY FOR BRUSH |
| 021 | 3.102.0003 | DIESEL FUEL FILTER TP3 |
| 022 | 3.551.0032 | SOLUTION PUMP 230-240V - 50Hz |
| 023 | 4.508.0034 | DISPENSER CONNECTION |
| 024 | 4.508.0033 | SOLUTION DISPENSER |
| 025 | 5.509.1226 | DIFFUSER ASSY+230V PUMP+ FILTER+SOLUTION HOSE |
| 026 | 5.509.0012 | JOINT ASSY Y+FLEX HOSES MW. |
| 027 | 4.505.0003 | HANDLE SUPPORT |
| 028 | 3.404.0053 | CAPACITOR 8mF D.35X57 F/M |
| 029 | 5.509.0010 | SQUEEGEE + SUPPORT ASSEMBLY |
| 030 | 5.509.0002 | BRUSH + BEARING ASSEMBLY |
| 032 | 4.508.0001 | U BUSH LOCKING |
| 033 | 4.507.0004 | SQUEEGEE SUPPORT SPRING |
| 034 | 4.508.0007 | GREY WHEEL D.100 MW |
| 035 | 5.509.0023 | LOWER CABINET GREY RAL 7043B |
| 036 | 4.508.0027 | ACOUSTIC PANEL |
| 037 | 4.508.0030 | EXHAUST AIR FILTER |
| 038 | 4.508.0009 | AIR INTAKE PORTION |
| 039 | 4.508.0032 | AIR INTAKE SEAL |
| 040 | 4.508.0031 | NON SIMMETRIC RING |
| 041 | 6.505.0040 | SUCTION MOTOR 230V/50-60Hz 800 W |
| 042 | 3.200.0092 | OR 139,37x2,62 NBR SH 70 |
| 043 | 4.507.0002 | SUCTION MOTOR SUPPORT |
| 044 | 4.508.0028 | UPPER ACOUSTIC PANEL |
| 047 | 4.508.0036 | ADHESIVE GASKET |
| 048 | 4.508.0003 | TRACTION MOTOR AIR CONVEYOR |
| 049 | 3.099.0277 | FAN FOR TRACTION MOTOR |
| 050 | 4.505.0002 | FLANGE FOR MOTOR |
| 051 | 3.001.0032 | BEARING 6002 2RS1 |
| 052 | 6.505.0003 | KIT STATOR + ROTOR + SHAFT LWS |
| 054 | 4.505.0001 | MOTOR SUPPORT |
| 055 | 4.506.0004 | SUPPORT FOR PULLEY |
| 056 | 4.508.0041 | BRUSH TRACTOR |
| 057 | 3.004.0007 | PLAIN WASHER D.6X18X2 UNI6593 |
| 058 | 3.004.0035 | WASHER GROWER D.6 UNI1751 ZNT |
| 059 | 3.002.0150 | SCREW M6X35 UNI 5931 |
| 060 | 4.012.0154 | ELECTRIC CABLE H05VV-F 3G0,75 7m SCHUKO PLUG |
| 062 | 4.012.0148 | ELECTRIC CABLE H05VV-F 5G0,75 FOR MW |
| 063 | 3.002.0106 | SELF TAPPING CROSS HEAD SCREW 3.9X16 |
| 064 | 3.002.0068 | SCREW TCEI M6X12 UNI 5931 ZNT |
| 065 | 4.506.0003 | SCREW M3 |
| 066 | 4.506.0002 | SCREW M6 |
| 067 | 3.004.0026 | PLAIN WASHER D.4.3X12 UNI6593 |
| 068 | 3.002.0028 | SCREW TC-TC M4X12 UNI 7687 ZNT |
| 069 | 3.004.0003 | WASHER D.4X8 DIN6798 ZNT |
| 070 | 3.002.0182 | TCEI SCREW M4X55 UNI ZNT |
| 071 | 3.002.0127 | SCREW TC CROSS CUT M5X35 SWAGE FORM ZNT |
| 072 | 5.509.0703 | ASSEMBLY UPPER COVER (GREY) |
| 073 | 4.508.0004 | PEDAL GREY RAL 7043B |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor SPRINTER - 8.501.0501
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
