Lavor Original Parts for Pressure Cleaner PROFESSIONAL 130 EVOLUTION
Lavor original spare parts for to replace broken parts for to fix PROFESSIONAL 130 EVOLUTION - 8.014.0029.
In the following tables, look for the spare part and its respective code.
| Professional 130 Ecolution - 8.014.0029 | ||
| IDRO TANKER PROF.130 EVOL.230/50-BLU-(EMMETRE) Pag.1 | ||
| # | Part Num | Description |
| 1 | 4.012.0071 | CABLE H05RN-F 3X1 5.2 m F/F THICKNESS SCREW EXP.03 |
| 2 | 5.012.0010 | STANDARD TROLLEY SCREW KIT |
| 3 | 4.008.0213 | TANK HANDLE FOR VULKER EXP.01 |
| 4 | 4.608.0027 | CAP DIAM. 30 FOR FIRE 100 TANK EXP.03 |
| 6 | 4.008.0277 | CABLE CLIP FOR FIXED WALL (LWS) EXP.00 |
| 7 | 7.101.0631 | LAVORWASH WARNINGS STICKER |
| 8 | 4.007.0114 | NOZZLE CLEANING PIN D.0.8 EXP.04 |
| 9 | 3.002.0112 | TC-TORX SCREW T15 3.9X25 HI-LOZNT |
| 10 | 4.007.0106 | ELECTRIC/PUMP FIXING BRACKET '93 EXP.01 |
| 11 | 7.101.1620 | RIGHT FAIRING STICKER PROFESSIONAL 130 |
| 12 | 7.101.1621 | LEFT FAIRING STICKER PROFESSIONAL 130 |
| 13 | 7.099.0049 | BUBBLE WRAP SHEET 50X60 GR. 55 X TRIPLE |
| 14 | 7.002.0113 | BOTTOM REINFORCED BOX FOR TANKER-KARJET W. 685 |
| 15 | 7.002.0112 | INTERNAL SPACING FOR EMME TANKER-KARJET BOX |
| 16 | 7.001.0224 | WHITE TANKER-KARJET PACKAGING 250X690H385 |
| 17 | 7.101.1622 | PROFESSIONAL 130 EVOLUTION PACKAGING STICKER |
| 18 | 7.100.0526 | PROFESSIONAL 130 COVER |
| 19 | 7.100.0083 | HOBBY USE-MAINTENANCE INSTRUCTIONS I-GB-F-D-E-NL-GR-S-SF-N-P |
| 20 | 7.100.0148 | SERVICE CENTERS LIST INSERT 09-01 LWS |
| 21 | 7.100.0249 | BRAKE ASSEMBLY INSERT |
| 22 | 7.100.0258 | SERVICE REQUEST INSERT (EMMETRE) |
| 24 | 3.601.0035 | ROTARY WATER BRUSH WITH FIXED HANDLE, REF. (5116) |
| 25 | 6.002.0104 | LANCE S93 D. 1.05 (GREY) REF. |
| 26 | 6.002.0147 | ROTOX S.97 PLAS. LANCE D.1.05 (2-PIN GRAY) |
| 27 | 6.002.0116 | REINFORCED COMPLETE LOW PRESSURE LANCE |
| 28 | 6.003.0038 | 4M PIPE CLEANER + COGET + EXP. 04 NOZZLE |
| 29 | 6.001.0020 | S'96 COMPLETE GUN WITH REINFORCED QUICK COUPLING |
| 30 | 4.018.0030 | 1/4 HOSE 130 BAR 6M |
| 31 | 3.100.0005 | 3/4 BLACK QUICK COUPLING WITH SEAL (UNIFLEX) |
| 32 | 4.013.0161 | TANKER TOP HOUSING (BLUE RAL5002) |
| 33 | 4.008.0185 | UNIFIED TROLLEY EXP. 07 |
| 34 | 7.101.1619 | STICKER TECHNICAL DATA PROFESSIONAL 130 EVOL. 230/50 -IN- |
| 35 | 4.007.0102 | SKANER CARELLATA WHEEL AXLE EXP. 02 |
| 36 | 3.006.0010 | WHEEL D. 100X25 HOLE D. 8 (L.WASH.) |
| 37 | 3.002.0113 | SCREW 3.9X16 HI-LO COSMETIC TEST.TORX WHITE ZNT |
| 38 | 4.007.0105 | TANKER AXLE EXP. 03 |
| 39 | 4.008.0184 | INTEGRAL WHEEL DIAM. 150x30x15 EXP. 01 |
| 40 | 5.011.0025 | BRAKE PIN COMPL. JET FIRE "TUV" |
| 41 | 3.099.0075 | DOUBLE PRESTOLA FOR M6 TE SCREW |
| 42 | 4.008.0172 | TRANSPARENT TUBE D.6x9 L.510 EXP.01 |
| MOT.PARTNER'96 230/50 D.125X80S/M(6,45)C/INIETTORE Pag.2 | ||
| 0 | 5.001.0199 | PARTNER '96 MOTOR 230/50 |
| 1 | 5.009.0213 | SWITCH ASSEMBLY + TRANSPARENT PROTECTION 12 (10) |
| 2 | 3.406.0004 | WATERPROOF CABLE GLAND PG.11 |
| 3 | 4.008.0354 | ELECTRICAL BOX PART.'96 + COVER FOR TS CORN SWITCH |
| 4 | 3.002.0111 | TC-TORX SCREW M4x10 TRIFLOBE Z |
| 5 | 3.404.0017 | CAPTAINER 25mF 450V WITHOUT FAST CABLE M.39x94 |
| 7 | 4.008.0236 | FAN COVER FOR '96 MOTOR WITH GRILLE EXP.07 |
| 8 | 3.099.0049 | STOP RING D.23 FOR FB 80 FAN |
| 9 | 4.008.0092 | FB80 FAN WITH D.16.5 HOLE (PARTNER) EXP.03 |
| 10 | 5.002.0065 | '96 CASING D.125 H.80 230/50 2P |
| 11 | 3.001.0020 | RADIAL BALL BEARING 6203 2RS |
| 12 | 5.005.0026 | ROTOR SHAFT 125'96 D.65 H.80 230/50 CYL |
| 13 | 3.002.0115 | TCEI SCREW M5X35 TRILOBAL ZNT |
| 14 | 4.005.0102 | FRONT ENGINE FLANGE D.125/96 PART. EXP. 04 |
| 15 | 3.201.0001 | SEAL RING 20/35/6/6.5 BABSL |
| 16 | 3.001.0007 | RADIAL BALL BEARING 6304 |
| 17 | 4.005.0078 | PLATE INCL. 6.45 CYLINDER BORE EXP.08 |
| 18 | 3.001.0003 | AXIAL BEARING WHEEL ASS4565 |
| 19 | 3.001.0004 | PLASTIC ROLLER CAGE TYPE AXK4565 |
| 20 | 4.007.0001 | THRUST WHEEL (C10Pb) FINISHED EXP.07 |
| 21 | 5.009.0090 | GROUND PISTON/STOP ASSEMBLY D.14 |
| 22 | 3.200.0014 | NITRILE O-RING 85 X 2.5 |
| 23 | 4.007.0025 | PISTON RETURN SPRING D.14-12 EXP.07 |
| 41 | 4.006.0001 | OMNIA DETERGENT INJECTOR HOSE HOLDER, HOLE D.1 |
| 42 | 3.005.0001 | 420 STAINLESS STEEL BALL DIAM.5 (precision grade G 500) |
| 43 | 4.007.0014 | DETERGENT CHECK VALVE SPRING D.4.5/6 L=7 THREAD D.0.3 |
| 49 | 3.200.0013 | OR-RING 11.1 X 1.78 REF. 114 |
| 50 | 3.201.0004 | OIL SEAL RING D.14X22X5/7 |
| 51 | 3.002.0094 | SCREW TCEI M6X30 ZNT TRILOBAL |
| 53 | 4.006.0109 | 1/8" TAPERED CAP EXP. 01 |
| 54 | 3.200.0018 | OR SEAL 9.92X2.62 SHORE90 |
| 55 | 3.200.0019 | OR SEAL 12.4X1.78 SHORE90 |
| 56 | 5.009.0101 | INTAKE/DEPLOYMENT VALVE CAP WITH MOUNTED OR |
| 57 | 5.009.0005 | INTAKE/DEPLOYMENT VALVE LAVOR1 |
| 58 | 4.008.0031 | WATER INTAKE FILTER D.16 TAPERED EXP. 00 |
| 60 | 5.009.0030 | PARTNER INJECTOR CONNECTOR D.1.8 COMPLETE WITH OR |
| 62 | 4.008.0348 | OIL SEAL SPACER D.14 EXP. 02 |
| 63 | 4.006.0036 | SEAL SUPPORT RING D.14 HIGH EXP. 10 |
| 65 | 3.201.0009 | WATER SEAL N 14-12 D.14X22X6 |
| 66 | 5.009.0015 | COMPLETE INTAKE VALVE TOP |
| 67 | 4.005.0077 | PARTNER '93 HEAD WITH DEEP SEATS IMPREG. |
| 68 | 3.002.0093 | TCEI SCREW M6x70 ZNT TRILOBAL |
| 77 | 5.009.0033 | PARTNER VALVE CAP WITH O-RING |
| 78 | 4.007.0064 | PARTNER VALVE SPRING, DIAMETER 6.6, OD 10, L=25, THREAD DIAMETER 1.7 |
| 79 | 5.009.0177 | PISTON ASSEMBLY, DIAMETER 14 FOR INDERLYN 100 VALVE |
| 80 | 5.009.0217 | PARTNER VALVE BODY, 3.5-2.05, WITH O-RING ASSEMBLY |
| 81 | 4.005.0047 | PISTON GUIDE BODY, DIAMETER 14 WITH INNER ADJUSTMENT, PARTNER EXP. 10 |
| 82 | 5.007.0077 | STEEL PISTON GUIDE BODY, 3.5X2.05 + INNER 1.8 |
| 83 | 5.008.0048 | PARTNER CYLINDER HEAD, '93, WITHOUT INDICATOR (SEALS) |
| 85 | 5.006.0091 | '96 ENGINE, DIAMETER 125, H 80, 230/50, 2P, PART. |
| 87 | 3.406.0011 | RING FOR PG.11, TEAR-RESISTANT |
