Lavor Original Parts for Pressure Cleaner Vertigo 25 - 80470002C
€3.32
Tax included
Lavor Original Parts for Pressure Cleaner Vertigo 25 - 80470002C
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 80470002C - Idro Vertigo 25 230-230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS.All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner Vertigo 25 - 80470002C
Fix your Cold Water High Pressure Cleaner 80470002C - Idro Vertigo 25 230-230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| 80470002C - IDRO VERTIGO 25 230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS- Pag.1 | ||
| # | Part Num. | Description |
| 0 | 50010756C | MOTOP.PT'03 110h100 230-240/50 D.12 8°30 TS IN.1,7 (VENT.D.127,5) |
| 0 | 50090770 | ASSIEME SEMIAVVOLG.C/OCCHIELLO'11 +TUBO mt.8 |
| 0 | 50110213 | ASSIEME CARENATURA + FIANCHETTI -N/GR/G- VERTIGO C/TAMP.-LAVOR- |
| 006 | 4.008.1432 | BLACK SWITCH KNOB |
| 007 | 3.401.0202 | ROTARY SWITCH TWO GEARS BIPOLAR 16A (0-1) W/PIN 11.5 |
| 008 | 3.404.0017 | CAPACITOR 25mF 450V D.39x94 F/M |
| 009 | 4.008.1437 | BLACK CAP FOR ELECTRICAL BOX VERTIGO |
| 010 | 4.008.1425 | BLACK HANDLE FOR VERTIGO |
| 010 | 4.008.1268 | AIR CONVEYOR FOR MOTOR 110H80 (D.142) |
| 011 | 4.008.1425 | BLACK HANDLE FOR VERTIGO |
| 011 | 6.005.0579 | KIT HOSE REEL VERTIGO 28 |
| 012 | 4.008.1430 | YELLOW CABLE REEL VERTIGO PANT.108C |
| 013 | 4.008.0095 | BLACK DETERGENT TANK CAP WITH HOLE D.9 |
| 014 | 4.008.1431 | TANK FOR VERTIGO |
| 015 | 4.008.1433 | BLACK WHEEL VERTIGO |
| 015 | 4.013.0639 | BLACK BACK SIDE CABINET VERTIGO |
| 016 | 4.013.0639 | BLACK BACK SIDE CABINET VERTIGO |
| 016 | 4.008.1433 | BLACK WHEEL VERTIGO |
| 017 | 4.012.0150 | CABLE H05VV-F 3X1,5 MT.5,4 F/F SCHUKO PLUG |
| 018 | 6.001.0078 | GUN S'10Y WITH QUICK CONNECTION LAVOR |
| 022 | 6.002.0325 | LANCE L=500 W/NOZZLES HOLDER-TURNING QUICK JOINT-COGETIL FOR MULTINOZZ. |
| 023 | 6.002.0325 | LANCE L=500 W/NOZZLES HOLDER-TURNING QUICK JOINT-COGETIL FOR MULTINOZZ. |
| 024 | 3.749.0472 | ROTARY NOZZLE 1/4F ALUM.THREAD SIZE 035 + QUICK JOINT |
| 026 | 3.601.0033 | FIX BRUSH WITH ADAPT.REINFORCED COGETIL |
| 029 | 5.012.0418 | KIT 4 NOZZLES D.1,00 FOR QUICK JOINT GR.0-15-40-FOAM |
| 030 | 3.100.0082 | QUICK COUPLING INLET CONNECTOR (THREAD=11.5) |
| 031 | 7.100.1848 | INSTRUCTION MANUAL VERTIGO LAVOR |
| 034 | 4.008.1268 | AIR CONVEYOR FOR MOTOR 110H80 (D.142) |
| 035 | 5.011.0213 | ASSEMBLY COVER+FRONTAL AND LATERAL COVERS VERTIGO W/TAMP.- LAVOR- |
| 036 | 5.001.0756C | MOTOR PUMP PT'03 110h100 230-240/50 D.12 8°30 TS IN.1,7 (FAN D.127,5) |
| 038 | 4.007.0291 | FIXING CLAMP FOR MOTOR PUMP D.110 |
| 80470002C - IDRO VERTIGO 25 230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS- Pag.2 | ||
| 001 | 4.008.1428 | YELLOW LATERAL LEFT SHELL VERTIGO -PANT.108C- |
| 002 | 4.008.1467 | GREY FRONTAL COVER VERTIGO W/TAMP. -LAVOR- |
| 003 | 4.008.1427 | YELLOW LATERAL RIGHT SHELL VERTIGO -PANT.108C- |
| 004 | 4.008.1429 | GREY LOW FRONTAL COVER VERTIGO -RAL.9006- |
| 005 | 4.013.0640 | BLACK FRONT SIDE CABINET VERTIGO |
| 80470002C - IDRO VERTIGO 25 230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS- Pag.3 | ||
| 001 | 4.018.0101 | 1/4 HOSE 25MPa L=810 FOR CONNEC.HOSE REEL/MOTORPUMP (METAL MESH TUBE R1) |
| 002 | 4.018.0102 | HOSE 1/4 225BAR L=8000 INTEGRAL COUPLING-QUICK COUPLING FOR HOSE REEL'10 |
| 80470002C - IDRO VERTIGO 25 230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS- Pag.4 | ||
| 0 | R50090882C | GRUPPO C.GUIDA C/TS 13KG-ASP.+TEST.TAPPI FIL. (PT'03) |
| 0 | R50090905C | ASS.MOT.09 D110H100 230-240/50 2P C/TER. PT03 +PIATT.8°30 |
| 001 | 6.005.0387 | KIT 353 LW FAN + RING |
| 002 | 5.009.0905C | MOTOR ASSEMBLY 09 D110H100 230-240/50 -C- |
| 003 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 004 | 5.009.0882C | BODY GUIDE+HEAD ASSEMBLED TS W/SUCTION-THREAD CAPS-PLASTIC CHECK VALVE |
| 80470002C - IDRO VERTIGO 25 230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS- Pag.5 | ||
| 001 | 4.005.0320 | CASING'10 110 H100 |
| 002 | 3.001.0033 | BALL BEARING 6003 2RS (17x35x10) |
| 003 | 5.005.0067 | ROTOR FOR 110H100-10 |
| 004 | 4.005.0277 | MOTOR FLANGE D.110-'10 PT'03 |
| 007 | 3.001.0030 | RADIAL |
| 008 | 4.005.0278 | WOBBLE PLATE 8'30 PT'03 |
| 80470002C - IDRO VERTIGO 25 230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS- Pag.6 | ||
| 0 | R50070187C | CORPO GUIDA PT'03 PIST.D.12 C/ TS-ASP.-VALV.COMP.-M.13KG |
| 0 | R50080265C | TESTATA PT'03 D.12 C/TAPPI FIL.ALL. |
| 001 | 5.007.0187C | PISTON BODY GUIDE PT'03 W/TS-SUCTION 13KG (40050260) |
| 002 | 6.005.0282 | KIT 257 O-RING SEAL |
| 003 | 5.008.0265C | PT'03 HEAD W/ALUM.THREAD CAPS |
| 80470002C - IDRO VERTIGO 25 230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS- Pag.7 | ||
| 001 | 5.009.0716 | COMPLETED VALVE TS PT'03 CABLE L=530 SPRING 13KG (WHITE FASTON COVER) |
| 002 | 6.005.0277 | KIT 252 |
| 003 | 6.005.0226 | KIT 209 O-RING |
| 004 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 005 | 4.005.0263C | PISTON BODY GUIDE PT'03 WITH SUCTION VALVE |
| 005 | 4.008.1176 | GASKET PISTON BODY GUIDE-HEAD PT'03 29.7X12.9X2.7 |
| 006 | 6.005.0181 | KIT 167 LW PISTON |
| 80470002C - IDRO VERTIGO 25 230-240_50 -G_GR- TS EU C_AVV. +SPAZZ.FISSA LWS- Pag.8 | ||
| 001 | 5.009.0820 | PT'03 DELIVERY VALV.CAP WITH O-RING (aluminum) |
| 001 | 6.005.0595 | KIT HEAD VALVE KIT +CAPS PT'03 |
| 002 | 4.005.0296C | PT'03 HEAD WITH THREAD FOR VALVE CAPS |
| 003 | 5.009.0534C | SUCTION VALVE ASSEMBLY FOR '03 HEAD |
| 003 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 004 | 3.201.0020 | WATER SEAL 12X18X5 |
| 005 | 5.009.0744 | VALVE PT '03 FOR THREAD CAPS |
