Lavor Original Parts for Pressure Cleaner MISSOURI - 8.619.0601.
Fix Your Pressure Cleaner MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR - 8.619.0601 - 8.619.0603.. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
In the following tables, look for the spare part and its respective code.
| 8.619.0601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.1 | ||
| # | Part Num. | Description |
| 0 | R56120025 | CORREDO UGELLO 15035 PORTAGOM. ATT.RAP. |
| 0 | R8619X004 | IDRO MISSOURI '07 230/50 B.D.F (SP.SCHUKO) |
| 001 | 4.613.0175 | YELLOW UPPER COVER FOR MUSSOURI |
| 002 | 4.613.0299 | REAR BLACK COVER |
| 003 | 4.608.0027 | BLACK PLUG D.30 FOR TANK |
| 004 | 7.700.0473 | INSTRUCTION MANUAL PARANA'/MEK/MISSOURI/MISSISSIPPI-R |
| 008 | 3.700.0036 | GUN 26Mpa-100°C-30lt/min G3/8M - M22 |
| 009 | 4.618.0049 | HOSE R1 1/4 8MT 3/8F-M22 (MAX 21MPa) |
| 010 | 3.701.0015 | LANCE INOX L.700 +PL4/1+WASHER+ QUICK CONN.M22 |
| 015 | 5.612.0025 | CORREDO UGELLO 15035 PORTAGOM. ATT.RAP. |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.2 | ||
| 001 | 3.100.0062 | QUICK COUPLING WITH VALVE (3029) |
| 002 | 3.103.0048 | HIGH PRESSURE NOZZLE 15035 1/8M (C25035) |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.3 | ||
| 0 | R50010817 | MOTOP.PT'03 125H110ALL 230-240/50 12' TS IN.1,7 TEST.OTT.(PARANA') |
| 0 | R56090348 | ASSIEME CALDAIA MISSISSIPPI-R 230/50 (C/UG.0,65) |
| 001 | 4.608.0142 | PLASTIC BASE FOR PARANA' |
| 002 | 4.607.0220 | AXLE FOR VICTORIA-PARANA' |
| 003 | 6.605.0018 | WHEELS KIT + STUDSD.250 |
| 004 | 5.009.0830 | WIRING PARTN. 3X1,5 PVC MT 6 SCHUKO PLUG |
| 005 | 4.008.0922 | COVER FOR MOTOR FAN (MOTOR'96) |
| 006 | 5.611.0043 | GAS OIL FILTER UNIT JOLLY 4/93 |
| 008 | 4.008.0470 | FAN MOTOR COVER |
| 009 | 3.304.0056 | BURNER MOTOR 230/50 C/W FAN, FLANGE, CABLES AND COVER |
| 010 | 5.609.0327 | THERMOSTAT BODY BULB + QUICK JOINT 3/8 M |
| 013 | 5.609.0348 | ASSIEME CALDAIA MISSISSIPPI-R 230/50 (C/UG.0,65) |
| 014 | 4.608.0140 | ELECTRICAL BOX COVER FOR MOTOPUMP |
| 015 | 4.608.0141 | ELECTRICAL BOX BASE FOR MOTOPUMP |
| 016 | 5.609.0328 | JOINT FOR PUMP/BOILER W/SAFETY VALVE |
| 019 | 4.007.0287 | FIXING CLAMP |
| 020 | 5.001.0817 | MOTORPUMP PT'03 125h110AL 230-240/50 12' TS IN.1,7 BRASS HEAD |
| 021 | 4.008.0514 | BLACK EAGLE FOOT FOR MOTOR- PUMP SUPPORT |
| 022 | 5.613.0154 | MOTOPUMP-BOILER SUPPORT FOR PARANA' |
| 023 | 4.608.0071 | GUIDING CABLE COVER DASHBOAR D '93 |
| 024 | 3.405.0011 | TERMINAL BOARD PA 32/6 |
| 025 | 5.009.0538 | SWITCH ASSY + PROTECTION COVER 14 (14) |
| 026 | 4.608.0164 | BLACK THERMOSTAT KNOB PARANA' |
| 027 | 4.608.0065 | BOX DASHBOARD '93 |
| 028 | 3.404.0095 | CAPACITOR 55mF 450V D.50X94 W/FASTON M |
| 030 | 4.608.0207 | DASHBOARD |
| 031 | 4.608.0078 | GASKET |
| 042 | 4.618.0067 | HOSE 5/16 R1 15DEG. 250 BAR 3/8 F ROT.-3/8 F ROT |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.4 | ||
| 0 | R50090304 | ASSIEME VALVOLA REGOLAZIONE PRESSIONE X POMPA ULKA (MOLLA L=20) |
| 0 | R56110119 | ASS.COP.CALD.PARANA' C/UG.0,65 |
| 001 | 5.009.0686 | CLA IGNITION TRANSFORMER WITH CABLES Substituited by 5.009.1150 -> Missouri/Mississippi |
| 002 | 4.608.0145 | RILSAN GASOIL HOSE X PARANA' L =500 |
| 003 | 4.607.0236 | HOSE D40 L=410 |
| 004 | 4.607.0238 | ROD FOR BOILER |
| 005 | 4.012.0102 | CABLE L=600 SEC.0,75 IEC227-3/1979 |
| 006 | 3.551.0055 | PUMP 230/50 |
| 007 | 5.013.0027 | DISK HEAD HOLDER |
| 008 | 4.604.0031 | COIL D.202 (1.5 GIRI) FOR PARANA' |
| 009 | 5.613.0188 | BOILER BODY |
| 010 | 4.008.0658 | THERMORESISTANT FELT BOTTOM PL ATE X FKX/PARANA' |
| 011 | 4.008.0450 | THERMORESISTANT PAD |
| 012 | 4.007.0184 | COUPLING PIPE FOR PARANA' |
| 013 | 4.008.0449 | THERMORESISTANT COUPLING BOW 17X23XL40 |
| 014 | 4.007.0158 | BOILER PAD |
| 015 | 4.008.0503 | BAND IN CERAMIC FIBER |
| 016 | 4.605.0042 | BASE FOR PARANA' BOILER |
| 017 | 4.007.0200 | WASHER20.2X26X3 |
| 018 | 4.607.0237 | RUBBER HOSE COUPLING FOR COIL |
| 019 | 5.611.0119 | ASS.COP.CALD.PARANA' C/UG.0,65 |
| 020 | 5.009.0304 | ADJUSTING VALVE SET (SPRING L=20) |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.5 | ||
| 001 | 3.100.0075 | CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O- RING |
| 002 | 4.005.0194 | BOILER COVER FKX |
| 003 | 5.009.0637 | BOILER CAP KIT |
| 004 | 4.006.0187 | NOZZLE HOLDER PIN |
| 005 | 3.104.0022 | GAS OIL NOZZLE 0.65 60°HR |
| 006 | 4.614.0003 | ELECTRODE D.2 FKX PARANA' |
| 007 | 3.099.0297 | COMPLETE DEFLECTOR |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.6 | ||
| 001 | 4.006.0259 | PORTAGOMMA A VITE X REGOLAZ. GASOLIO FKX |
| 002 | 4.006.0260 | DADO 10x1 ES.13 PER REGOLAZ. GASOLIO FKX |
| 003 | 4.007.0306 | SPRING FOR PRESS.REG.VALVE FKX D.5,4-7,8 L=20 WIRE 1,8 |
| 004 | 3.200.0050 | O-RING 5.28X1.78 |
| 005 | 4.008.0856 | VALVOLA SFERICA PER REGOLAZION E BY-PASS FKX-PARANA' |
| 006 | 4.006.0254 | BY-PASS DIESEL VALVE |
| 007 | 3.200.0021 | OR GASKET 6,75x1,78 RIF.106 |
| 008 | 3.100.0057 | CONNECTION D.4X1/8'M VITON O-RING |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.7 | ||
| 0 | R50070231 | CORPO GUIDA PT'03 PIST.CERAMICA D.12 C/TS-ASP.(FIL)-MOLLA17kg |
| 0 | R50080238 | TESTATA PT'03 D.12 OTT.C/TAPPI FIL.-MAN.-PRESS.(TEN.MARRONI TEL.) |
| 0 | R50091016 | ASS.MOTORE D.125H110ALL 230-240/50 2P +PIATT.12' |
| 001 | 6.005.0251 | KIT 168 LW RING+FAN |
| 002 | 4.007.0416 | THRUST BEARING 35X58X12 PT'03 (180BAR) |
| 003 | 5.007.0231 | BODY GUIDE PT'03 CERAMIC PISTON W/TS-INJ.-17KG SPRING |
| 004 | 6.005.0134 | KIT 125 O-RING SEAL |
| 005 | 5.008.0238 | PUMP HEAD PARTNER '03 D.12 BRAS WITH CAPS |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.8 | ||
| 0 | R5Y090587 | FLANGIA ANTERIORE X PT'03 D.125H110 C/FILETTI |
| 001 | 5.002.0149 | HOUSING '96 D125 H110AL 230-240/50 2P |
| 002 | 3.001.0020 | RADIAL BEARING FOR MOTOR SHAFT 17X40X12 6203 2RS |
| 003 | 5.005.0072 | ROTOR D.65 H.110 x MOT.125AL PT'03 230/50 |
| 004 | 5.Y09.0587 | FLANGE FOR PT'03 D.125H110 W/THREADS |
| 007 | 3.001.0002 | OBLIQUE SPHERE BEARING 20x52x15 7304 B |
| 008 | 4.005.0225 | INCLINATED PLATE 12 DEGREE X PT'03 |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.9 | ||
| 001 | 4.Y05.0226 | FRONT FLANGE MOTOR D.125H110 PT'03 W/THREAD |
| 002 | 3.201.0001 | OIL SEAL 20/35/6/6,5 BABSL |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.10 | ||
| 001 | 5.009.0710 | BODY GUIDE ASS PT'03 D.12 CERAMIC S/V.COMP.IN.1,7 S/PORTAG. |
| 002 | 5.009.0596 | COMPLETED VALVE TS PT'03 CABLE L=530 SPRING 17KG (GREEN FASTON COVER) |
| 003 | 6.005.0254 | KIT 237 LW 3 PISTONS AISI 440 +SPRINGS PT'03 |
| 004 | 6.005.0226 | KIT 209 O-RING |
| 006 | 6.005.0277 | KIT 252 |
| 007 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 86190601 - IDRO MISSOURI 230/50 TS -G- SP.SCHUKO -LAVOR- pag.11 | ||
| 001 | 4.606.0187 | JOINT FOR MANOMETER AND PRESSURE-GAUGE |
| 001 | 6.005.0316 | KIT 288 WATER SEAL PT BRASS HEAD D.12 |
| 002 | 6.005.0315 | KIT 287 SUCTION/DELIVERY VALVE+ BRASS THREAD CAPS PT'03 |
| 003 | 5.009.0745 | PT'03 DELIVERY VALV.CAP WITH O-RING (brass) |
| 003 | 5.009.0534C | SUCTION VALVE ASSEMBLY FOR '03 HEAD |
| 004 | 4.006.0348 | PUMP HEAD PT'03 BRASS LAVOR W/THREAD FOR VALVE CAPS W/GAUGE |
| 004 | 3.107.0006 | D.40 0/300 BAR 1/8 GLYCERIN MANOMETER |
| 005 | 3.704.0006 | PRESSURE SWITCH PS2 1/8M 25BAR |
| 005 | 4.606.0187 | JOINT FOR MANOMETER AND PRESSURE-GAUGE |
| 006 | 4.607.0400 | VITE CAVA 1/8 PER BLOCCHETTO |
| 006 | 5.009.0744 | No VALVE PT '03 FOR THREAD CAPS |
| 007 | 5.009.0745 | PT'03 DELIVERY VALV.CAP WITH O-RING (brass) |
| 007 | 3.704.0006 | PRESSURE SWITCH PS2 1/8M 25BAR |
| 008 | 3.107.0006 | D.40 0/300 BAR 1/8 GLYCERIN MANOMETER |
| 008 | 4.006.0348 | PUMP HEAD PT'03 BRASS LAVOR W/THREAD FOR VALVE CAPS W/GAUGE |
| 009 | 4.607.0400 | VITE CAVA 1/8 PER BLOCCHETTO |
