FIAC Spare Parts for Pumping Unit CCS 248-338
€358.68
Tax included
FIAC Spare Parts for Pump Unit CCS 248-338
Genuine Parts FIAC for piston Air Compressors and spare parts for the repair or replacement of components of the type CCS 248-338.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Pump Unit CCS 248-338
Genuine Parts FIAC for piston Air Compressors and spare parts for the repair or replacement of components of the type CCS 248-338.
In the following table, look for the type of the Pumping Unit and the respective parts of the code.
| Pump Unit CCS 248-338 | ||
| # | Part Num. | Description |
| 3 | 5011060008 | Base |
| 4 | 7011100000 | Screw M8X25 UNI-5739 |
| 5 | 7011420000 | Screw M6X16 UNI-5739 |
| 6 | 7012060000 | Screw M4X12 UNI-8112 |
| 7 | 7012090000 | Screw M5x12 UNI-8112 |
| 8 | 7012130000 | Ø Screw 4,8X22 UNI-6954 |
| 9 | 7012200000 | Screw M8x35 UNI-8112 |
| 10 | 7012240000 | Screw M5X15 UNI-8112 |
| 12 | 7021030000 | Nut M8 UNI-7473 |
| 13 | 7038080000 | Fan Washer |
| 14 | 7051240000 | Tab "A 5X5X22" UNI 6604-69 |
| 15 | 7080160000 | Fitting "L" 1/2 |
| 16 | 7090090000 | Cap M1 / 4 "Brass |
| 17 | 7110060000 | Manometer |
| 18 | 7151060000 | Hull plastic top |
| 19 | 7151070000 | Hull plastic bottom |
| 1A | 3040130000 | Single-phase motor |
| 1B | 3040060000 | ENGINE HP.2 CCS-240 V.400 / 50HZ |
| 1C | 3040151000 | MOT.HP.3 CCS 335 V.230 / 50Hz-P.110H |
| 1D | 3040170000 | MOT-HP.3 CCS 335 V.400 / 50Hz-H.90 |
| 20 | 7151130000 | Plastic fairing |
| 21 | 7160060000 | spring A 693 |
| 22 | 7192090000 | Valve Sic. 3/8 "10,4BAR |
| 23 | 7200080000 | Cooling Fan |
| 24 | 7230060000 | Rilsan tube Ø12X10 |
| 25 | 7360020000 | Rubber Ø16 |
| 28 | 7408520000 | Pulley Øp160 1 "A" |
| 29 | 7501050000 | Cable locks |
| 2A | 4052160000 | Kit Pressure |
| 2B | 4052210000 | Kit Pressure |
| 30 | 9100040000 | GROUP AB 248 WITHOUT/FLYWHEEL - NEW AB268 |
| 40 | 7084220000 | Fitting DIR.M1 / 4 "-6 QUICK |
| 41 | 7085530000 | Fitting 1/4 "-3/8" MF |
| 52 | 7020200000 | Nut M6 UNI-5587 |
| 53 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 54 | 7500030000 | Fairlead |
| 56 | 7640070000 | Cover - DISCONTINUED |
| 57 | 7640080000 | Cover |
| 11A | 7015290000 | Guy |
| 11B | 7018470000 | Guy ENGINE CCS 335 HP.3 |
| 26A | 7371090000 | Belt SPZX 750 |
| 26B | 7370640000 | Belt SPZX 787-NOTCHED |
| 27A | 7408530000 | Pulley Øp75 1 "A" F.16 |
| 27B | 7409580000 | Pulley OP90 1-Z F16 |
| 42A | 7250240000 | Pressure switch |
| 42B | 7250460000 | Pressure switch |
| 43A | 7329070000 | Alimentation cable |
| 43B | 7328020000 | Alimentation cable |
| 50A | 4012930000 | Stator |
| 50B | 4012930000 | Stator |
| 50C | 4012930000 | Stator |
| 50D | 4012930000 | Stator |
| 51A | 7015140000 | Guy M6X130 |
| 51B | 7015370000 | Guy F = 25MM M6X149 |
| 55A | 7580150000 | SHAFT ELECTRIC HP.2 BRAND. |
| 55B | 7580160000 | SHAFT ELETTR.CCS 335 3HP. |
| 58A | 7660120000 | Armature |
| 58B | 7660060000 | Armature |
| 58C | 7660190000 | Armature |
| 58D | 7660170000 | Armature |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fiac CCS 248-338
