Lavor Original Parts for Pressure Cleaner Idro EXPRESS PLUS
€29.00
Tax included
Lavor Original Parts for Pressure Cleaner Idro EXPRESS PLUS
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner IDRO EXPRESS PLUS 220-240/50.Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner Idro EXPRESS PLUS
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner IDRO EXPRESS PLUS 220-240/50.
In the following tables, look for the spare part and its respective code.
|
8.084.0006C Lavor IDRO EXPRESS PLUS 220-240/50 1 - CHASSIS Pag.1
|
||
| # | Part Num. | Description |
| 001 | 4.008.1199 | BLACK HANDLE |
| 002 | 6.005.0318 | FRONT+REAR PLASTIC COVER |
| 003 | 5.009.0213 | SWITCH WITH PROTECTION 12(10) |
| 004 | 4.008.1198 | BLACK PLASTIC COVER FOR MAINSWITCH |
| 005 | 5001.0644C | Substituted by 5.001.0841C MOTORPUMP PT'03 230/50 TS 5'30SPRING 13KG (7645AF) |
| 006 | 6.005.0241 | WHEELS KIT |
| 009 | 4.018.0095 | HOSE 1/4 180BAR L=6000 M22x1,5D.15-RAPID FIX |
| 010 | 6.001.0073 | GUN S'09 WITH INTEGRAL QUICK JOINT LAVOR |
| 011 | 4.012.0174 | CABLE H05VV-F 2X1 MT.5,4 F/F SCHUKO PLUG |
| 012 | 6.002.0263 | S'02V LANCE D.1,00(LIGHT BLUE) |
| 013 | 6.002.0329 | ROTOX LANCE S01 CONICAL HEAD 1,025 (BLACK) L=470 |
| 014 | 3.100.0082 | QUICK COUPLING INLET CONNECTOR(THREAD=11.5) |
| 015 | 5.011.0033 | REINFORCED FOAM LANCE |
| 016 | 3.601.0002 | YELLOW ANONYM.TANK DETERGENT FOR FOAM LANCE |
| 017 | 6.003.0048 | PIPE CLEANING HOSES MT10 +COGETIL+NOZZLE |
| 018 | 3.601.0032 | Substituted by 3.601.0074 1 Yes 1 ROTARY BRUSH FIXED HANDLE REINFORCED COGETIL |
| 019 | 3.601.0033 | FIX BRUSH WITH ADAPT.REINFORCED COGETIL |
| 020 | 7.100.1618 | INSTRUCTION MANUAL |
| 5.001.0841C MOTORPUMP PT'03 230/50 TS 5'30SPRING 13KG (7645AF) Pag.2 | ||
| 000 | 5.001.0644C | MOTORPUMP PT'03 230/50 TS 5'30SPRING 13KG (7645AF) |
| 001 | 5.009.0729 | UNIV.MOTOR 230/50+PINION CABLEL=600 WITH CAPACITOR (7645AF) |
| 002 | 6.005.0311 | THRUST RING KIT (PT'03 U76) |
| 003 | 4.007.0205 | PIN 10X70 |
| 004 | 5.009.0726 | 5'30 WOBBLE PLATE ASSEMBLY W/CROWN Z 62 (PT'03) |
| 005 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 006 | 6.005.0181 | KIT 167 LW PISTON |
| 007 | 6.005.0226 | KIT 209 O-RING |
| 008 | 6.005.0184 | KIT 170 LW HEAD VALVE KIT |
| 009 | 4.005.0210 | 03 PARTNER HEAD |
| 010 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 011 | 6.005.0134 | KIT 125 O-RING SEAL |
| 012 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 014 | 4.008.0031 | INLET WATER FILTER H2O D.16 CONICAL |
| 015 | 4.005.0234 | PISTON BODY GUIDE PT'03 WITHOUT HOLE FOR SUCTION |
| 016 | 5.009.0680 | COMPLETED VALVE TS PT'03 CABLEL=530 SPRING 9KG (BLACK FASTO |
| 017 | 5.007.0192 | GUIDE BODY PARTNER'03 PISTON D.12 W/TS-WOUT/VACUUM-COMP.VAL |
| 018 | 5.008.0182 | Substituted by 5.008.0182C '03 PARTNER HEAD D.12 |
| 13A | 6.005.0281 | KIT 256 VALVE GUIDE RID. W/OSUCTION PT'03C |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
EXPRESS PLUS - 8.084.0006C
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
