| Michelin Pressure Cleaner MPX 25EH - 14652 | ||
| Chassis Pag.1 |
||
| # | Part Num | Description |
| 1 | 4720040 | Casing |
| 2 | 50943 | Screw |
| 3 | 4720630 | Accessory holder |
| 4 | 3085230 | Accessory holder |
| 5 | 4720240 | Disc |
| 6 | 3085940 | Screw |
| 7 | 4720050 | Protection Blue 7455C |
| 8 | 4720230 | Knob Yellow 107C |
| 9 | 4720060 | Protection Blue 7455C |
| 10 | 4380394 | Button Yellow 107C |
| 11 | 4720210 | Foot |
| 12 | 50943 | Screw |
| 13 | 4720520 | Accessory holder |
| 14 | 4720510 | Protection |
| 15 | 5480500 | Screw |
| 16 | 3080580 | Cable gland |
| 17 | 50943 | Screw |
| 18 | 4720190 | Protection |
| 19 | 50943 | Screw |
| 20 | 4720250 | Stop |
| 21 | 4380590 | Protection |
| 22 | 4380580 | Protection |
| 23 | 4380491 | Base |
| 24 | 4380540 | Accessory holder |
| 25 | 2180330 | Rubber |
| 26 | 50943 | Screw |
| 27 | 50943 | Screw |
| 28 | 4720760 | Wheel |
| 29 | 4383970 | Stop |
| 30 | 4720020 | Protection |
| 31 | 4720030 | Cap Blue 7455C |
| M | 4381470 | Screw kit |
| Hose Reel Pag.2 | ||
| 1 | 4720090 | Knob Yellow 107C |
| 2 | 4720080 | Handle |
| 3 | 50943 | Screw |
| 4 | 5460810 | Screw |
| 5 | 4720110 | Tube |
| 6 | 4720780 | Washer |
| 7 | 5460810 | Screw |
| 8 | 4720120 | Guide |
| 9 | 50943 | Screw |
| 10 | 4720100 | Yellow hook 107C |
| 11 | 4821020 | Spring |
| 12 | 4720130 | Protection |
| 13 | 4720260 | Protection |
| 14 | 50943 | Screw |
| 15 | 4820410 | Cover |
| 16 | 4720160 | Bracket |
| 17 | 4101680 | Disc |
| 18 | 4102120 | Support |
| 19 | 50943 | Screw |
| 20 | 4720150 | Bracket |
| 21 | 4101660 | Lever |
| 22 | 4581980 | Screw |
| 23 | 5460700 | Screw |
| 24 | 4101672 | Knob Yellow 107C |
| Electric pump Pag.3 | ||
| 1 | 4383820 | Electric pump pre-assembly |
| 2 | 4380170 | Conveyor |
| 3 | 3085940 | Screw |
| 4 | 4720590 | Shift |
| 5 | 4380160 | Conveyor |
| 6 | 3081450 | Switch |
| 7 | 3980160 | Rod |
| 8 | 3980130 | Cover |
| 9 | 3085940 | Screw |
| 10 | 4720140 | Pin |
| 11 | 3086010 | Capacitor kit |
| 12 | 4382480 | Connection |
| 13 | 3500090 | Fork |
| 14 | 5480770 | Inductance |
| 15 | 3082360 | Cable |
| A | 3081290 | Valve + seal kit |
| B | 3081270 | Piston + seal kit |
| C | 4384420 | TSS kit |
| D | 4720810 | Brush kit for motor |
| E | 4384300 | TSS valve kit |
| Accessories Pag.4 | ||
| 1 | 4381483 | Gun |
| 2 | 3083700 | O-ring |
| 3 | 4381493 | Extension (Lance) |
| 4 | 3083370 | O-ring |
| 5 | 4100800 | Lance head |
| 6 | 4101550 | Head (Adjustable jet) |
| 7 | 4381500 | Foam |
| 8 | 3083400 | O-ring |
| 9 | 4381750 | High pressure tube |
| 10 | 3082130 | Water coupling kit |
