Alpina Spare Parts for Brushcutter BJ 335 D
€2.43
Tax included
Alpina Spare Parts for Brushcutter BJ 335 D
Alpina original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Brushcutter BJ 335 D (2011) 285321002/09.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter BJ 335 D
Alpina original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Brushcutter BJ 335 D (2011) 285321002/09.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Alpina BJ 335 D (2011) 285321002/09 - Engine Pag.1 | ||
| # | Part Num. | Description |
| 3 | 123604007/0 | Starter Pulley |
| 5 | 123430585/0 | Spring |
| 10 | 183058041/0 | Starter Ass.Y |
| 11 | 123784010/0 | Engine Support |
| 12 | 123275034/0 | Grommet |
| 14 | 183082004/0 | Starter Cup Ass.Y |
| 15 | 119035159/0 | Seal Ring |
| 16 | 123685026/0 | Crank Case |
| 17 | 123280047/0 | Gasket |
| 18 | 114215218/0 | Ball Bearing |
| 19 | 123020025/0 | Crankshaft |
| 20 | 123072002/0 | Key |
| 22 | 123685027/0 | Crank Case |
| 24 | 123880018/0 | Flywheel REPLACED BY 123880009/0 BUY WITH COIL |
| 28 | 123044018/0 | Electronic Coil REPLACED BY 123044011/0 BUY WIYH FLYWHEEL |
| 33 | 123430583/0 | Clutch Ass.Y |
| 35 | 123878058/0 | Screw |
| 36 | 123208422/0 | Transm.Support Case |
| 37 | 123235007/0 | Needle Bearing |
| 38 | 123202009/0 | Circlip |
| 39 | 123590008/0 | Piston |
| 40 | 123760007/0 | Piston Pin |
| 41 | 123204010/0 | Piston Ring |
| 42 | 123280045/0 | Cylinder Gasket |
| 43 | 123071024/0 | Cylinder |
| 45 | 123087025/0 | Cylinder Cover Yellow |
| 47 | 3210024 | Spark Plug |
| 50 | 123053002/0 | Spark Plug Cover |
| 51 | 123275023/0 | Grommet |
| 52 | 123109552/0 | Cover, Spark Plug |
| 53 | 123280043/0 | Gasket |
| 54 | 183740022/0 | Muffler |
| 58 | 123280041/0 | Intake Manif-Gasket |
| 59 | 123073509/0 | Intake Manifold |
| 60 | 123280039/0 | Intake-Carb Gasket |
| 61 | 123054026/1 | Carburettor |
| 62 | 123315089/0 | Choke Lever |
| 66 | 2132160 | Screw |
| 67 | 123190000/0 | Shutter |
| 68 | 183220003/0 | Air Filter assy |
| 69 | 123220011/0 | Air Filter |
| 70 | 123090026/0 | Air Cleaner Cover |
| 71 | 123878056/0 | Screw |
| 74 | 183520005/0 | Intake Filter |
| 75 | 123867030/0 | Tube |
| 76 | 123275021/0 | Grommet |
| 77 | 123867031/0 | Tube |
| 79 | 123733003/0 | Kit Fuel Tank |
| 81 | 2122210 | Vite |
| 85 | 123280060/0 | Gasket |
| 86 | 183790009/0 | Fuel Cap Assy |
| BJ 335 D (2011) 285321002/09 - Handle - Trasmission Pag.2 | ||
| 1 | 8563830 | Handle Ass.Y |
| 2 | 2123030 | Screw |
| 3 | 2135050 | Screw |
| 4 | 3743431/1 | Throttle Lever |
| 5 | 3654270/1 | Spring |
| 6 | 3743441 | Safety Lever |
| 7 | 3654280/1 | Spring |
| 8 | 3210970 | Stop Switch |
| 9 | 12154330/0 | Nut |
| 10 | 23655001/0 | Reduction |
| 11 | 83394003/0 | Handle Ass.Y |
| 12 | 23395050/0 | Left Handle |
| 13 | 2135060 | Screw |
| 14 | 4541500/1 | Upper Handgrip Support |
| 15 | 4541490/1 | Handle Support |
| 16 | 4541510 | Lower Handgrip Support |
| 17 | 2135050 | Screw |
| 18 | 2135040 | Screw |
| 19 | 2412030 | Nut |
| 20 | 23780000/0 | Harness Support |
| 21 | 123066014/0 | Wire Ass.Y |
| 22 | 123065024/0 | Coil-Switch Cable |
| 23 | 3211600/1 | Earth Cable (Black) |
| 24 | 3786240 | Wire Sheath |
| 25 | 8251201 | Trasmission Pipe Ass.Y |
| 26 | 4251400 | Trasmission Shaft |
| 27 | 4121861/1 | Clutch |
| 28 | 8562960 | Support Trasm.Assy |
| 29 | 3353080 | Seeger Ring |
| 30 | 3112170 | Bearing |
| 31 | 2135160 | Screw |
| 32 | 2123030 | Screw |
| 33 | 3744260 | Shock Absorber |
| 34 | 2123110 | Screw |
| 35 | 2123100 | Screw |
| 36 | 8563570 | Safety Cover Ass.Y (Incl.40-43) |
| 37 | 2432040 | Nut |
| 38 | 2312150 | Washer |
| 39 | 3615000 | Line Cutter |
| 40 | 2135030 | Screw |
| 41 | 2312150 | Washer |
| 42 | 2135060 | Screw |
| 43 | 123046000/0 | Harness |
| BJ 335 D (2011) 285321002/09 - Gear Case Pag.3 | ||
| 1 | 4252780/1 | Gear Case Assy - Available in Adaptable Version, with Universal Head Adapter and Stone Guard Kit |
| 7 | 2135050 | Screw |
| 8 | 2653090 | Screw |
| 9 | 2653460 | Screw |
| 15 | 3121170 | Oil Seal |
| 16 | 3641700/1 | 1 Collar |
| 17 | 3641640 | Upper Ring Nut |
| 18 | 3612640 | Lower Ring Nut |
| 19 | 4560610 | Stabilizer |
| 22 | 4611880 | 4 Teeth Disc 25 Cm |
| 31 | 4353240/1 | 2 Hedges Nylon Head |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
BJ335D 2011 285321002/09
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
