Metabo WEV 15-125 Quick Parts
€74.43
Tax included
Metabo Spare Parts for Angle Grinder WEV 15-125 Quick
Metabo genuine spare parts for replacing or repairing Angle Grinder WEV15-125 Quick - 00468001.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Angle Grinder WEV15-125 Quick
Metabo genuine spare parts for replacing or repairing Angle Grinder WEV 15-125 Quick - 00468001.In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| WEV 15-125 Quick - 00468001 | ||
| # | Part Num | Description |
| 1 | 310010990 | Armature compl., 230V |
| 2 | 311012180 | Field coil w.field coil, 230V |
| 3 | 343410120 | Switch 2-pole |
| 4 | 399999990 | Part not needed |
| 5 | 399999990 | Part not needed |
| 6 | 343362490 | Cable clip |
| 7 | 315013520 | Motor housing 2 part |
| 8 | 339151180 | Baffle |
| 9 | 339151200 | Baffle |
| 10 | 343082890 | Electronic unit, 230V 50/60Hz |
| 11 | 143115690 | Ball bearing, 6x19x6 |
| 12 | 344097870 | Rubber bushing |
| 13 | 339133060 | Washer, 8.05x17x0.4 |
| 14 | 143115700 | Ball bearing, 8x22x7 |
| 15 | 339006390 | Washer, 7.05x19.5x0.2 |
| 16 | 341100940 | Hexagon nut w.recess |
| 17 | 343433070 | Switch rod |
| 18 | 343433030 | Cap |
| 19 | 343433100 | End cap |
| 20 | 343437100 | Switch slide |
| 21 | 341031160 | Clamping flange |
| 23 | 339204500 | Wheel guard, D125 |
| 24 | 314000970 | Anti-vibration handle, M8 |
| 26 | 342022490 | Spring clip |
| 28 | 141121430 | Fill. head screw (DIN 7985) |
| 30 | 339012430 | Gasket |
| 31 | 141121640 | Fill. head screw (DIN 7985) |
| 32 | 141116980 | Self-tap. fill. h. screw |
| 33 | 141117060 | Self-tap. fill. h. screw |
| 34 | 338060250 | Rating plate |
| 36 | 399999990 | Part not needed |
| 40 | 341604420 | Spindle M14 |
| 41 | 316055350 | Clamping nut compl., M14 |
| 42 | 141151120 | Washer 10.2x14.8x0.2 |
| 43 | 141152300 | Washer 10.2x14.8x0.1 |
| 44 | 141153920 | Washer 10.2x14.8x0.5 |
| 50 | 343433280 | Flange compl. |
| 51 | 341102460 | Nut |
| 52 | 316054980 | Bevel gear w.pinion |
| 53 | 316055080 | Friction washer set compl. |
| 54 | 316055100 | Gear housing compl. |
| 55 | 316054260 | Safety clutch w.pinion |
| 57 | 316054850 | Fan w. dust guard |
| 58 | 316067170 | Carbon brush with brush holder Set 230V |
| 59 | 316066040 | Clamping lever compl. |
| 61 | 141156650 | Retaining ring |
| 62 | 143196000 | O-ring |
| 63 | 342003390 | Pressure spring |
| 64 | 343433130 | Push button |
| 65 | 341515640 | Bolt |
| 70 | 343433060 | Tacho disc |
| 71 | 343433090 | Pivoting switch |
| 72 | 339007800 | Washer |
| 75 | 143192490 | O-ring |
| 92 | 143195640 | O-ring |
| 880 | 344130920 | Grease 100G |
| 885 | 344130560 | Grease SF 011 50Gr 1.8oz |
| 1001 | 338505780 | Diagram |
| 1005 | 316067320 | Cable with sleeve |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
