Hitachi Spare Parts for Impact Drill DV22V

€1.79
Tax included

Hitachi Spare Parts for Impact Drill DV22V

We have the original Spares for Hitachi-HIKOKI Impact Drill DV22V, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Impact Drill DV22V. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

ITEM CODE: 303709
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Hitachi Spare Parts for Impact Drill DV22V

Fix Your Impact Drill DV22V. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table , look for the model of the Impact Drill and the respective parts of the code .
Hitachi DV22V

Impact Drill DV22V
# Part Num. Description
4 338738 SPINDLE (A)
5 939556 RETAINING RING FOR D35 HOLE
6 971745 OIL SEAL (A)
7 6003DD BALL BEARING 6003DD
8 338771 RATCHET (D)
9 984101 SPRING (A)
10 959150 STEEL BALL D6.35
12 338769 GEAR COVER (A) ASS'Y
13 322852 WASHER (B)
14 338744 DISTANCE PIECE
15 338743 SECOND PINION (A)
16 339222 PACKING
17 338746 CHANGE LEVER
18 338747 CHANGE COVER
19 338748 CHANGE SHAFT
20 338745 INNER COVER (A)
21 338737 SHIFT LEVER ASS'Y
22 322848 SHIFT PIN
23 878885 O-RING (S-18)
24 338770 RATCHET (C)
25 981328 SPRING (H)
26 335299 STEEL BALL D3.5
27 323048 RETAINING RING (E-TYPE) FOR D15 SHAFT
28 339223 WASHER
29 338740 LOW SPEED GEAR
30 338741 HIGH SPEED GEAR
31 338742 SHIFT ARM
32 984104 PIN D5
34 608DDM BALL BEARING 608DD
35 361002E ARMATURE 230V
36 338754 FAN GUIDE (B)
37 338755 RUBBER BUSH
38 340905E STATOR 230V-240V
39 338751 DUST SEAL
40 338750 STATOR HOLDER
41 607VVC BALL BEARING 607VV
42 931701 BEARING LOCK
43 338749 HOUSING (B)
44 338761 CLICK PLATE
46 999088 CARBON BRUSH (1 PAIR)
47 339292 SPRING
48 338760 BRUSH COVER
49 338753 HANDLE COVER (B)
52 338759 BRUSH HOLDER
53 338752 HANDLE COVER (A)
55 338756 SWITCH
57 334379 FERRITE CORE
58 953327 CORD ARMOR D8.8
59 937631 CORD CLIP
61A 930039 NOISE SUPPRESSOR
502 338768 SIDE HANDLE
503 303709 DEPTH GAUGE
506 336473 HANDLE
507 336474 HINGE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
