Metabo Spare Parts for Jig Saw STE 70
METABO Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Jig Saw STE 70 - 05700000.
In the following table, look for the model of the Jig Saw and the respective parts of the code.
| Metabo STE 70 - 05700000 | ||
| # | Part Num. | Description |
| 1 | 34337459 | Eye Shield |
| 2 | 34220057 | Protective Strap |
| 3 | 14111602 | Self-tap. Fill. H. Screw |
| 4 | 31603045 | Housing Cpl. |
| 5 | 33803790 | Rating Plate |
| 6 | 34307741 | Electronic Unit 230 V |
| 7 | 14111697 | Fillister Head Screw |
| 8 | 34340892 | Pressure switch black |
| 9 | 34151386 | Cylindrical Pin |
| 10 | 31602988 | Supporting Lever |
| 11 | 33912050 | Sliding Sheet |
| 12 | 34407004 | Felt |
| 13 | 34202168 | Pressure Spring |
| 14 | 33912932 | Guide Plate |
| 15 | 34100261 | Needle Bearing |
| 16 | 33912549 | Washer |
| 17 | 31603008 | Spur Gear Cpl. |
| 18 | 14311143 | Needle Sleeve |
| 19 | 33912929 | Balancing Plate |
| 20 | 33912936 | Pressure Spring |
| 21 | 31603009 | Bearing Support Cpl. |
| 22 | 34338006 | Cover Brush |
| 23 | 14311340 | Ball Bearing, 8x22x7 |
| 24 | 31000789 | Armature Cpl. 230 V |
| 25 | 14311566 | Ball bearing, 6x19x6 |
| 26 | 34409255 | Rubber Stopper |
| 27 | 31603010 | Field Coil 230 V |
| 28 | 31603396 | Carbon Brush Cpl. |
| 29 | 31603256 | Oscillating Guide |
| 30 | 34107031 | Cover Plate |
| 31 | 14319470 | O-ring |
| 32 | 33901052 | Sealing Washer |
| 33 | 14111916 | Cap Screw |
| 34 | 34460034 | Clamping Piece |
| 35 | 14116081 | Tightening Pin |
| 36 | 34105612 | Ram |
| 37 | 33912945 | Connecting Link |
| 38 | 14112055 | Countersunk Screw |
| 39 | 31603026 | Ram With Guide |
| 40 | 34339548 | Anti-splintering insert |
| 41 | 31602962 | Base Plate Cpl. |
| 42 | 33912931 | Position Plate |
| 43 | 14113137 | Square Nut |
| 44 | 34416153 | Hexagonal Key |
| 45 | 14112230 | Cap Screw |
| 46 | 33900562 | Champing Claw |
| 47 | 34105586 | Shift Axle |
| 48 | 31603014 | Shift Lever |
| 49 | 33811483 | Metabo Label |
| 50 | 34409142 | Rubber Plug |
| 52 | 34410114 | Cable Sleeve |
| 53 | 34448588 | Cable With Plug |
| 54 | 14118181 | Circlip |
| 55 | 99999999 | Part not needed |
| 56 | 34409758 | Rubber Plug |
| 57 | 31602958 | Brush Holder Module |
| 880 | 34413093 | Grease 50gr 1,80z |
