Metabo Spare Parts for Router OFE 1229 SIGNAL
€1.58
Tax included
Metabo Spare Parts for Router OFE 1229 SIGNAL
We are METABO original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for repair Router OFE 1229 SIGNAL - 01229000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Router OFE 1229 SIGNAL
We are METABO original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for repair Router OFE 1229 SIGNAL - 01229000.
In the following table, look for the model of the Milling Machine and the respective parts of the code.
| Router OF E 1229 SIGNAL/01229000 | ||
| # | Part Num. | Description |
| 1 | 34410064 | Cord Armor |
| 2 | 14111602 | Self-tap fill h screw |
| 3 | 34336578 | Motor cap |
| 4 | 34307133 | Electronic unit,230V |
| 5 | 31603342 | Carbon brush Set |
| 6 | 14111990 | Self-tapp. fill. h. screw |
| 7 | 34300048 | Brush holder |
| 8 | 33802465 | Rating plate |
| 9 | 34336383 | Motor housing |
| 11 | 31100792 | Field coil 220 V |
| 12 | 14112168 | Self-tap. fill. h. screw |
| 13 | 34336385 | Baffle cover |
| 15 | 34340626 | Switch |
| 16 | 14116029 | Cylindrical pin |
| 17 | 34448918 | Strand cpl. AWG18SW |
| 18 | 34336372 | Switch rod |
| 19 | 34200183 | Pressure spring |
| 20 | 31602159 | Switch slide cpl. |
| 21 | 33912456 | Guide |
| 22 | 14111697 | Fillister head screw |
| 23 | 33918720 | Cable clip |
| 24 | 14111613 | Self-tap. fill. h. screw |
| 25 | 34336384 | Cover |
| 26 | 33812237 | M-Label,56x25 |
| 27 | 62390200 | Tren-end spanner 19mm |
| 28 | 34449318 | Cable with plug |
| 29 | 14115132 | Washer |
| 30 | 14311580 | Ball bearing, 8x22x7 |
| 31 | 31000578 | Armature cpl. 220 V |
| 32 | 31601708 | Dial gauge adjuster |
| 33 | 14118009 | snap ring |
| 34 | 14311402 | Ball bearing, 15x35x11 |
| 35 | 14111212 | Countersunk screw |
| 36 | 34336021 | Clamping lever |
| 37 | 34170213 | Hexagon head screw |
| 38 | 33912498 | Support |
| 39 | 34111156 | Handle upper part |
| 40 | 31603305 | Handle bottom part |
| 41 | 34105267 | Bolt |
| 42 | 34200177 | Pressure spring |
| 43 | 33912449 | Slide |
| 44 | 33900495 | Plate |
| 45 | 14112007 | Fill. head screw |
| 46 | 14319213 | O-ring |
| 47 | 33000095 | Fan |
| 48 | 14112232 | Countersunk screw |
| 49 | 33912472 | Bearing flange |
| 51 | 14118012 | Retaining ring |
| 52 | 31602160 | Bearing flange cpl. |
| 53 | 14111698 | Self-tap. fill. h. screw |
| 54 | 34110150 | Flange nut |
| 55 | 63194600 | Collet 8 mm |
| 56 | 34336411 | Trigger |
| 57 | 34200198 | Pressure spring |
| 58 | 14111390 | Cap screw |
| 59 | 34105266 | Sleeve |
| 60 | 14115262 | Cup spring |
| 61 | 14111123 | Cap screw |
| 62 | 33900066 | Washer |
| 63 | 14111678 | Fillister head screw |
| 64 | 14111597 | Fillister head screw |
| 65 | 34409328 | Compensating Washer |
| 66 | 34105265 | Bush |
| 67 | 14312030 | Ball |
| 68 | 34200005 | Pressure spring |
| 69 | 34111132 | Handle upper part |
| 70 | 34111080 | Thumbscrew |
| 71 | 14115013 | Washer |
| 72 | 34336363 | Guide |
| 73 | 14111322 | Fillister head screw |
| 74 | 63150700 | Fine-adjustment parallel edge guide |
| 76 | 34105189 | Guide rod |
| 77 | 14111500 | Grub screw |
| 78 | 34114248 | Bridge |
| 79 | 34200176 | Pressure spring |
| 80 | 34435028 | Pointer |
| 81 | 33811373 | Scale |
| 83 | 31541257 | Guide holder |
| 85 | 14116341 | Tubular rivet |
| 86 | 34200182 | Pressure spring |
| 91 | 31602514 | Exhaust nozzle |
| 92 | 34111103 | Thumbscrew |
| 93 | 33912448 | Support |
| 94 | 31602073 | Base plate cpl. |
| 95 | 33901087 | Insulating plate |
| 96 | 34410007 | Insert |
| 97 | 14319006 | O-ring |
| 98 | 31603304 | Handle bottom part |
