Maruyama Brushcutter BC3021H-RS-01 Parts
€120.02
Tax included
Maruyama Brushcutter BC3021H-RS-01 Parts
Fix Your Brushcutter Maruyama BC3021H-RS-01. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Maruyama Brushcutter BC3021H-RS-01 Parts
Fix Your Brushcutter Maruyama BC3021H-RS-01. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Maruyama Brushcutter BC2630RS Parts | ||
| Main Body Pag.1 | ||
| # | Part Num. | Description |
| 1-1 | 363965 | BC3021H-RS-01 |
| 1-2 | 215512 | Clutch Case Ass'y Incl.3-9 |
| 1-3 | 214592 | Bearing Case |
| 1-4 | 214161 | Bearing |
| 1-5 | 054676 | Snap Ring |
| 1-6 | 214162 | Buffer |
| 1-7 | 214163 | Washer |
| 1-8 | 092033 | Screw |
| 1-9 | 214593 | Driveshaft Tube Adapter |
| 1-10 | 261246 | Cap Screw |
| 1-11 | 054677 | Clutch Drum |
| 1-12 | 219268 | Driveshaft Ass'y |
| 1-13 | 218711 | Driveshaft Tube |
| 1-14 | 215532 | Shaft Grip |
| 1-15 | 215533 | Hanging Bracket Ass'y Incl.16 |
| 1-16 | 261762 | Cap Screw |
| 1-17 | 216935 | Bracket Ass'y Incl.18 |
| 1-18 | 261246 | Cap Screw |
| 1-19 | 231048 | Label |
| 1-20 | 223188 | Label |
| 1-21 | 261250 | Cap Screw |
| 1-22 | 226501 | Handle Ass'y-Left Incl.23,24 |
| 1-23 | 226502 | Handle |
| 1-24 | 226503 | Grip |
| 1-25 | 232081 | Handle Ass'y-Right Incl.26,27 |
| 1-26 | 223714 | Handle |
| 1-27 | 232082 | Throttle Trigger |
| 1-28 | 231264 | Label |
| 1-29 | 232086 | Safety Cover Ass'y Incl.30-36 |
| 1-30 | 231252 | Safety Cover Ass'y Incl.31,32 |
| 1-31 | 227819 | Bracket |
| 1-32 | 221580 | Screw |
| 1-33 | 232087 | Bracket Ass'y Incl.34-36 |
| 1-34 | 227822 | Bracket |
| 1-35 | 220632 | Cap Screw |
| 1-36 | 231704 | Washer |
| 1-37 | 231882 | String Cutter Ass'y Incl.38-40 |
| 1-38 | 230747 | String Cutter |
| 1-39 | 261250 | Cap Screw |
| 1-40 | 228325 | Nut |
| 1-41 | 230748 | Cover Extention |
| 1-42 | 228086 | Hanging Strap Ass'y |
| GearCase Pag.2 | ||
| 2-1 | 231880 | Gearcase Ass'y Incl.2-17 |
| 2-2 | 225960 | Gearcase |
| 2-3 | 234109 | Bolt |
| 2-4 | 227990 | Bearing |
| 2-5 | 228416 | Gear Set |
| 2-6 | 219087 | Cap Screw |
| 2-7 | 227991 | Bearing |
| 2-8 | 055185 | Snap Ring |
| 2-9 | 227992 | Bearing |
| 2-10 | 227993 | Bearing |
| 2-11 | 228477 | Snap Ring |
| 2-12 | 140270 | Snap Ring |
| 2-13 | 261246 | Cap Screw |
| 2-14 | 212986 | Boss Adapter |
| 2-15 | 140275 | Clamping Washer |
| 2-16 | 215547 | Stabilizer |
| 2-17 | 215610 | Bolt |
| Gear Case GT-Turbo Pag.3 | ||
| 2-1 | 232926 | Gearcase Ass'y Incl.2-17 |
| 2-2 | 232719 | Gearcase |
| 2-3 | 234109 | Bolt |
| 2-4 | 261246 | Cap Screw |
| 2-5 | 210560 | Bearing |
| 2-6 | 233332 | Gear Set |
| 2-7 | 232724 | Cap Screw |
| 2-8 | 012381 | Bearing |
| 2-9 | 210560 | Snap Ring |
| 2-10 | 140268 | Bearing |
| 2-11 | 228477 | Snap Ring |
| 2-12 | 140270 | Snap Ring |
| 2-13 | 232927 | Boss Adapter |
| 2-14 | 232928 | Clamping Washer |
| 2-15 | 210308 | Stabilizer |
| 2-16 | 215610 | Bolt |
| 2-17 | 219087 | Cap Screw |
| Engine Pag.4 | ||
| 3-1 | 858770 | Engine |
| 3-2 | 286791 | Cylinder |
| 3-3 | 286846 | Gasket |
| 3-4 | 261250 | Cap Screw |
| 3-5 | 269144 | Insulator - New gasket required |
| 3-6 | 267049 | Gasket |
| 3-7 | 265924 | Cap Screw |
| 3-8 | 283007 | Muffler Ass'y Incl.9-12 |
| 3-9 | 283003 | Muffler Comp. |
| 3-10 | 268171 | Muffler Tail |
| 3-11 | 267056 | Spark Arrester |
| 3-12 | 265107 | Cap Screw |
| 3-13 | 281440 | Gasket |
| 3-14 | 266402 | Cap Screw |
| 3-15 | 281435 | Under Cover |
| 3-16 | 267191 | Cap Screw |
| 3-17 | 286707 | Top Cover Ass'y Incl.18-21 |
| 3-18 | 281434 | Top Cover |
| 3-19 | 286300 | Knob |
| 3-20 | 261020 | Spacer |
| 3-21 | 261734 | Snap Ring |
| 3-22 | 286851 | Crankcase |
| 3-23 | 280488 | Bearing |
| 3-24 | 261492 | Oil Seal |
| 3-25 | 261386 | Oil Seal |
| 3-26 | 055185 | Snap Ring |
| 3-27 | 261612 | Cap Screw |
| 3-28 | 281442 | Screen |
| 3-29 | 268782 | Piston |
| 3-30 | 265067 | Piston Ring |
| 3-31 | 265068 | Piston Pin |
| 3-32 | 265225 | Bearing,Needle |
| 3-33 | 261393 | Clip,Piston Pin |
| 3-34 | 265141 | Crankshaft/Conn.Rod Ass'y |
| 3-35 | 267327 | Clutch Ass'y Incl.36,37 |
| 3-36 | 267342 | Clutch Shoe |
| 3-37 | 267345 | Spring,Clutch |
| 3-38 | 264505 | Bolt |
| 3-39 | 261777 | Wave Washer |
| 3-40 | 261189 | Washer |
| 3-41 | 281433 | Fan Cover |
| 3-42 | 261250 | Cap Screw |
| 3-43 | 287898 | Magneto Ass'y Incl.44-48 |
| 3-44 | 287902 | Rotor/Fan |
| 3-45 | 281746 | Ignition Coil Ass'y Incl.46-48 |
| 3-46 | 269714 | Plug Boot |
| 3-47 | 269715 | Connector |
| 3-48 | 281756 | Insulator |
| 3-49 | 261076 | Woodruff Key |
| 3-50 | 261417 | Nut,Rotor |
| 3-51 | 280381 | Spacer |
| 3-52 | 261256 | Cap Screw |
| 3-53 | 288264 | Spark Plug |
| 3-54 | 269722 | Lead |
| 3-55 | 268044 | Lead |
| 3-56 | 269189 | Grommet |
| 3-57 | 283476 | Recoil Starter Ass'y Incl.58-68 |
| 3-58 | 283477 | Recoil Ass'y Incl.59-67 |
| 3-59 | 283504 | Reel |
| 3-60 | 283505 | Cam Plate |
| 3-61 | 283506 | Spring |
| 3-62 | 280931 | Spiral Spring |
| 3-63 | 267213 | Screw |
| 3-64 | 283578 | Stater Rope Ass'y Incl.65-67 |
| 3-65 | 283579 | Stater Rope |
| 3-66 | 261725 | Starter Grip |
| 3-67 | 283511 | Rope Stopper |
| 3-68 | 283575 | Starter Pawl Ass'y |
| 3-69 | 284698 | Adapter Ass'y |
| 3-70 | 283391 | Cap Screw |
| 3-71 | 265726 | Cap Screw |
| 3-72 | 282096 | Cap Screw |
| 3-73 | 264588 | Clamp |
| 3-74 | 286143 | Label |
| 3-75 | 265694 | Label |
| 3-76 | 267561 | Label |
| Carburetor - Fuel Tank Pag.5 | ||
| 4-1 | 284111 | Carburetor Ass'y Incl.2-16 New gasket required |
| 4-2 | 264155 | Pump Body |
| 4-3 | 262991 | Purge Body |
| 4-4 | 262992 | Cover Plate |
| 4-5 | 261874 | Primer Bulb |
| 4-6 | 283905 | Diaphragm, Meterring |
| 4-7 | 262993 | Gasket |
| 4-8 | 262994 | Diaphragm,Fuel Pump |
| 4-9 | 282576 | Gasket |
| 4-10 | 261876 | E-Ring |
| 4-11 | 261658 | Swivel |
| 4-12 | 261875 | Screw |
| 4-13 | 264677 | Bracket |
| 4-14 | 261657 | Packing |
| 4-15 | 262996 | Screw |
| 4-16 | 264678 | Washer |
| 4-17 | 261352 | Label |
| 4-18 | 281714 | Cap Screw |
| 4-19 | 281715 | Cap Screw |
| 4-20 | 269762 | Gasket |
| 4-21 | 268055 | Air Filter Case Ass'y Incl.22-25 |
| 4-22 | 268056 | Air Filter Case |
| 4-23 | 268057 | Valve |
| 4-24 | 268157 | Sleeve |
| 4-25 | 268412 | Sleeve |
| 4-26 | 263345 | Packing |
| 4-27 | 263942 | Washer |
| 4-28 | 263815 | Stay |
| 4-29 | 264016 | Cap Screw |
| 4-30 | 265026 | Screen |
| 4-31 | 265027 | Foam Element |
| 4-32 | 268058 | Air Filter Cover Ass'y Incl.33-35 |
| 4-33 | 268059 | Air Filter Cover |
| 4-34 | 281438 | Knob |
| 4-35 | 261734 | Snap Ring |
| 4-36 | 284954 | Fuel Tank Ass'y Incl.37-47 |
| 4-37 | 281439 | Fuel Tank |
| 4-38 | 281564 | Fuel Tank Cap Ass'y Incl.39 |
| 4-39 | 269377 | Gasket |
| 4-40 | 282538 | Fuel Pipe Pick-up Ass'y Incl.41-47 |
| 4-41 | 282539 | Fuel Pipe Ass'y Incl.42-45 |
| 4-42 | 268065 | Grommet |
| 4-43 | 261690 | Fuel Pipe |
| 4-44 | 261590 | Breather |
| 4-45 | 261117 | Clip |
| 4-46 | 264653 | Filter Ass'y |
| 4-47 | 261117 | Clip |
| 4-48 | 261117 | Clip |
| 4-49 | 281441 | Stand |
| Accessories Pag.6 | ||
| 5-1 | 210418 | Box Spanner |
| 5-2 | 022865 | Double-ended Wrench |
| 5-3 | 210181 | Lever Handle |
| 5-4 | 220534 | Blade Cover |
| 5-5 | 227910 | 3-Teeth Blade |
| 5-6 | 232226 | Semi-Auto Head (L) |
| 5-7 | 233234 | Instruction Manual |
| 5-8 | 233326 | Instruction Manual |
| 5-9 | 523302 | Parts List |
| 5-10 | 219432 | Wrench |
| 5-11 | 219433 | Wrench |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Maruyama websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Maruyama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
