Maruyama Spare Parts for Chainsaw MCV5100S 18" .325"
€159.59
Tax included
Maruyama Spare Parts for Chainsaw MCV5100S 18" .325"
Fix Your Chainsaw Maruyama MCV5100S 18" .325" (EU). All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Maruyama Spare Parts for Chainsaw MCV5100S 18" .325"
Fix Your Chainsaw Maruyama MCV5100S 18" .325" (EU). All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| MARUYAMA MCV5100S 18" .325" (EU) Spare Parts pag.1 | ||
| # | Part Num. | Description |
| 1 | 181114105 | FUEL TANK CPL. RED |
| 2 | 181117050 | GRIP OUTER SHELL, BLACK |
| 3 | 181117132 | CATCH LEVER |
| 4 | 181117031 | SPRING |
| 5 | 181117081 | ROCKER |
| 6 | 181117111 | SPRING |
| 7 | 181117094 | RETAINING CLIP |
| 7a | 181117041 | BOWDEN CABLE |
| 8 | 935930240 | CYLINDRICAL PIN 3x24 |
| 9 | 181117121 | THROTTLE LEVER |
| 10 | 957114061 | AIR VALVE CPL. |
| 11 | 913455204 | SCREW 5,5x20 |
| 12 | 181114065 | FUEL LINE EPA code |
| 13 | 10114010 | SUCTION HEAD |
| 14 | 10114020 | REP. KIT, FILTER (5 OF EACH) for 010114010 |
| 15 | 181114202 | TANK CAP CPL. |
| 16 | 963229036 | PACKING RING 29,3X3,6 |
| 17 | 181114301 | DAMPING SPRING, CPL. |
| 18 | 181114301 | DAMPING SPRING, CPL. |
| 20 | 913455204 | SCREW 5,5x20 |
| 21 | 913455164 | SCREW 5,5X16 |
| 22 | 181114950 | COVER NEUTRAL |
| 23 | 908006205 | SCREW M6x20 |
| 24 | 913455204 | SCREW 5,5x20 |
| 25 | 181310250 | TUBULAR HANDLE AL |
| MARUYAMA MCV5100S 18" .325" (EU) pag.2 | ||
| 26 | 181118941 | HOOD CPL. RED KAT TR |
| 27 | 181118060 | INSERT SO/WI |
| 28 | 181173190 | AIR FILTER ASS'Y VLIES |
| 29 | 181171050 | CLIP FOR AIR FILTER |
| 30 | 181171011 | INTAKE MANIFOLD |
| 31 | 908505555 | H.L. SOCKET HEAD BOLT M5x55 |
| 34 | 913455164 | SCREW 5,5X16 |
| 36 | 181131960 | BOTTOM BLACK |
| 37 | 908805205 | SCREW M5X20 |
| 40 | 181171160 | FLANGE KPL. |
| 41 | 181131090 | TUBE |
| 42 | 181131040 | SUCTION HOSE |
| 43 | 181118160 | INSERT (SNOW) |
| 44 | 181131070 | ANNULAR SPRING |
| 45 | 913455164 | SCREW 5,5X16 |
| 46 | 181155060 | CONTACT SPRING |
| 47 | 181155080 | GUIDE |
| 48 | 913455164 | SCREW 5,5X16 |
| 49 | 928405000 | DISC |
| 50 | 980114928 | LABEL CHOKE I-0 |
| 51 | 957173250 | SNOW FILTER SET |
| 52 | 181173250 | PRE-FILTER |
| 57 | 181174062 | COOLING PLATE |
| 58 | 181174050 | GASKET |
| 59 | 908005205 | SCREW M5x20 |
| 60 | 181174091 | SHEET-METAL |
| 61 | 909005105 | SCREW M5x10 |
| 62 | 908805205 | SCREW M5X20 |
| 63 | 181131021 | INSERT |
| 70 | 181118070 | DAMPING PLUG |
| 108 | 181174301 | MUFFLER KAT |
| 109 | 181174470 | SPARK ARRESTER SCREEN CPL. KAT |
| 110 | 908005095 | SCREW M5x9 |
| 112 | 181131140 | RUBBER BUSH |
| 144 | 970311580 | EARTH CABLE Stahl, Steel |
| 148 | 181155070 | CHOKE ON/OFF SWITCH |
| MARUYAMA MCV5100S 18" .325" (EU) pag.3 | ||
| 65 | 181130217 | CYLINDER / PISTON CPL. Ø 45 |
| 66 | 181132063 | PISTON CPL. Ø 45 |
| 67 | 181132080 | PISTON RING Ø 45 |
| 68 | 181132090 | PISTON PIN |
| 69 | 181132050 | SPRING RING C 12X1 |
| 72 | 908805235 | SCREW M5x23 |
| 73 | 181114401 | DAMPING SPRING, CPL. |
| 74 | 181131133 | GASKET |
| 75 | 181120102 | CRANKSHAFT CPL. |
| 76 | 962210033 | NEEDLE CAGE 10x13x12,5 |
| 77 | 960102152 | BALL BEARING (USE GLUE) 6202 |
| 78 | 960123159 | COMBINATION BALL BEARING 6202 C3 |
| 79 | 962900156 | RADIAL RING Ø 12/20x4,5 |
| 80 | 181111920 | CRANKC. M. SIDE BLACK Mg |
| 81 | 181111910 | CRANKC. CL. SIDE BLACK Mg |
| 82 | 181111060 | GASKET |
| 83 | 170114100 | TANK CAP COMPLETE |
| 84 | 963225030 | PACKING RING |
| 85 | 181118050 | STEELCLIP |
| 86 | 908006205 | SCREW M6x20 |
| 87 | 908805205 | SCREW M5X20 |
| 88 | 181111230 | IMPACT PROTECTION |
| 89 | 936430160 | CLAMPING PIN 3X16 |
| 90 | 181111230 | IMPACT PROTECTION |
| 91 | 908805205 | SCREW M5X20 |
| 92 | 908005205 | SCREW M5x20 |
| 93 | 181111050 | CHAIN CATCH |
| 94 | 908006205 | SCREW M6x20 |
| 95 | 905808210 | SCREW M8x21 |
| 96 | 181250011 | SPIKE BAR |
| 97 | 908805205 | SCREW M5X20 |
| 98 | 10245030 | VENT VALVE |
| 99 | 962900065 | RADIAL RING |
| 100 | 181213300 | CHAIN TENSIONER CPL. PROFI |
| 101 | 181213230 | TENSIONING SCREW PROFI |
| 102 | 181213240 | TENSION SLIDE PROFI |
| 103 | 181213250 | ADJUSTING SCREW PROFI |
| 104 | 181213270 | TRANSMISSION COVER PROFI |
| 105 | 181213260 | TENSIONING SCREW BEARING |
| 106 | 963207020 | PACKING RING 7X2 |
| 107 | 908705125 | SCREW M5x12 |
| MARUYAMA MCV5100S 18" .325" (EU) pag.4 | ||
| 117 | 980115936 | LABEL MARUYAMA LOGO |
| 122 | 928405000 | DISC |
| 128 | 181143212 | IGNITION COIL, CPL., BLACK Profi |
| 129 | 181147050 | IGNITION CABLE |
| 130 | 195143030 | ISOLATING WASHER black |
| 131 | 970502110 | ISOLATING HOSE A6X0,5 L=55mm |
| 132 | 957604260 | SPARK PLUG CAP CPL. |
| 133 | 965603021 | SPARK PLUG |
| 134 | 908805205 | SCREW M5X20 |
| 135 | 920308024 | HEXAGONAL NUT M8x1 |
| 136 | 926208001 | SPRING WASHER B8 |
| 182 | 181160900 | STARTER ASSY. BLACK PROFI |
| 183 | 181112960 | STARTER ASSY. BLACK |
| 184 | 181118120 | AIR GUIDE PLATE |
| 185 | 181164010 | STARTER KNOB |
| 186 | 908605205 | H.L. SOCKET HEAD BOLT M5x20 |
| 187 | 181163050 | REWIND SPRING IN HOUSING |
| 188 | 181162020 | CABLE DRUM |
| 189 | 181163080 | SPRING EASY-START |
| 190 | 181163090 | DRIVER FOR EASY-START |
| 191 | 181163095 | SCREW |
| 192 | 985000155 | STARTER ROPE ø 3,5 x 100 m |
| 192 | 181164020 | STARTER ROPE ø 3,5 x 1000 mm |
| 194 | 195141103 | FLYWHEEL CPL. |
| 195 | 195166100 | STARTER RATCHET CPL. |
| MARUYAMA MCV5100S 18" .325" (EU) pag.5 | ||
| 140 | 181245251 | OIL PUMP CPL. |
| 143 | 181245120 | CONDUITE HUILE |
| 145 | 181245100 | CONDUITE HUILE CPL. |
| 146 | 21245060 | RESSORT |
| 147 | 1245020 | TETON DE TUYAU |
| 149 | 908705125 | VIS M5x12 |
| 150 | 181245090 | LE COMMANDE DE POMPE |
| 151 | 1182042 | DISQUE 44,5x1x12 |
| 152 | 175180101 | EMBRAYAGE CPL. |
| 153 | 181184010 | RESSORT |
| 154 | 181224090 | DISQUE DE DISTANCE 10x18x0,5 |
| 155 | 181213011 | RESSORT DE FREIN |
| 156 | 181223062 | TAMBOUR CPL. SMALL |
| 157 | 962300009 | DOUILLE D’AIGUILLE 10/14X12 |
| 158 | 181224040 | PIGNON A GAGUE 325", Z=7, SM |
| 159 | 181224081 | DISQUE |
| 160 | 927408000 | RONDELLE D=8X1,3 |
| 161 | 927304000 | RONDELLE SÉCURITÉ |
| 162 | 181213100 | MECANISME DE FREINAGE |
| 163 | 181213023 | RESSORT DE TRACTION |
| 164 | 181213170 | COULISSE P. PROTÈGE-MAINS CPL. |
| 165 | 181213371 | PLAQUE DE MOUSSE DE NYLON |
| 167 | 181213161 | PROTÈGE-MAIN CPL. |
| 168 | 185114237 | PLAQUE |
| 169 | 181213310 | PIÈCE DISTANCE |
| 170 | 181213320 | DOUILLE |
| 171 | 908805205 | VIS M5X20 |
| 174 | 181213400 | PLAQUE DE MOUSSE DE NYLON |
| 175 | 957213900 | PROTÈGE-PIGNON CPL. NOIR |
| 176 | 923208004 | ECROU HEXAGONAL M8 |
| 177 | 957213220 | GUIDE DE COPEAUX |
| 178 | 181213191 | COUVERCLE |
| 179 | 908105126 | VIS M5x12 |
| MARUYAMA MCV5100S 18" .325" (EU) pag.6 | ||
| 203 | 38153360 | SCREW |
| 204 | 181153040 | DIAPHRAGM COVER |
| 205 | 1153020 | SCREW |
| 226 | 181153210 | PLUG-WELCH |
| 230 | 38155012 | RETAINING CLIP |
| 231 | 965402995 | GASKET |
| 250a | 181153301 | CARBURETOR 2012-04 => |
| 251 | 181153261 | IDLE ADJUSTMENT SCREW 2012-04 => |
| 252 | 181153271 | MAIN ADJUSTMENT SCREW 2012-04 => |
| 255 | 181153031 | PUMP COVER CPL. 2012-04 => |
| 256 | 181153021 | SET DIAPHRAGM / GASKETS (INCL. PUMP DIAPHRAGM RUBBER+MYLAR) 2012-04 => |
| 257 | 181153560 | REBUILD KIT 2012-04 => |
| 258 | 181153570 | KIT THROTTLE SHAFT 2012-04 => |
| 259 | 181153580 | KIT CHOKE SHAFT 2012-04 => |
| MARUYAMA MCV5100S 18" .325" (EU) pag.7 | ||
| 500 | 485045631 | SPROCKET NOSE BAR .325" .058" 45CM-18" |
| 501 | 415325710 | SPROCKET NOSE (MARUYAMA) |
| 503 | 514686072 | SAW CHAIN .325" .058" |
| 504 | 558083000 | TIE STRAP .325" .058" 45CM-18" |
| 505 | 558083010 | TIE STRAP WITH RIVETS .325" .058" |
| 518 | 952010840 | CHAIN PROTECTION .325" .058" |
| 520 | 957004011 | TOOL CPL. 40 cm (neutral) |
| 521 | 941719131 | UNIVERSAL WRENCH |
| 522 | 940827000 | ANGLED SCREW DRIVER SW 13/19 mm |
| 523 | 944340001 | SCREWDRIVER T27 |
| 524 | 950004002 | PLASTIK BAG |
| 525 | 944500795 | CYLINDER FIN CLEANER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Maruyama websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Maruyama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
