Maruyama Parts for Brushcutter BC4321RS-01
Fix Your Brushcutter Maruyama BC4321RS-01. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Maruyama Brushcutter BC4321RS-01 Spare Parts Pag.1 |
||
| # | Part Num. | Description |
| 1-2 | 222543 | CLUTCH CASE CPL |
| 1-3 | 222544 | COVER CASE |
| 1-4 | 012649 | BEARING CASE BC5020 6201ZZ |
| 1-5 | 016732 | RING BC450 |
| 1-6 | 217045 | RUBBER CLUTCH CASE BC500H |
| 1-7 | 217046 | RUBBER CLUTCH CASE BC500H |
| 1-8 | 217047 | SPACER B500H / BC5020RS |
| 1-10 | 222370 | BC5020 CLUTCH COVER |
| 1-12 | 222546 | CLUTCH DRUM BC450 / 4320/5020 |
| 1-13 | 222522 | DRIVESHAFT ASS'Y |
| 1-14 | 220800 | DRIVESHAFT TUBE |
| 1-15 | 223188 | LABEL |
| 1-17 | 228207 | AUCTION LABEL BC5020HEO |
| 1-18 | 231143 | LEVER BC4321 / 5020 AVB |
| 1-21 | 228086 | BELT BC4321RS |
| 1-22 | 232104 | HANDLE BC3420 / BC5020 |
| 1-25 | 081027 | NUT BC520 `03 |
| 1-26 | 219113 | SCREW BKC5020RS |
| 1-27 | 232092 | SAFETY COVER ASS'Y |
| 1-28 | 231262 | SAFETY COVER ASS'Y |
| 1-31 | 232093 | CLAMP |
| 1-35 | 231882 | BLADE CPL |
| 1-36 | 230747 | BLADE |
| 1-37 | 261250 | SCREW SILENCER BC350 |
| 1-38 | 228325 | NUT |
| 1-39 | 230748 | EXTENSION BKC5020 * Ex227812 |
| Pag.2 | ||
| 2-2 | 223050 | CARTER CC BC5020 * usa223049o236695 |
| 2-5 | 210560 | BEARING 609 C.C BC4320 = 227992 |
| 2-6 | 227102 | PINION AND CROWN BKC520 / BC432 |
| 2-7 | 217057 | SHAFT |
| 2-8 | 022009 | BEARING BC5020RS 6000Z |
| 2-9 | 016732 | BC450 RING |
| 2-10 | 212394 | SPACER RING BC5020 |
| 2-11 | 211818 | SEAL OIL |
| 2-12 | 215610 | FIXED SCREW M8x1,25Sx x 17 |
| 2-13 | 014490 | BEARING 6000 = 8250312 |
| 2-14 | 106933 | BEARING 6000Z COPP.C. BC5020RS |
| 2-15 | 014210 | SEEGER RING C.CON.BC4320 901560 |
| 2-16 | 054676 | SEEGER BC350 |
| 2-17 | 217060 | FLANGE BC450 / 520 |
| 2-18 | 217061 | FLANGE BC450 / 520 |
| 2-19 | 210308 | STABILIZER * uses 8470163 |
| Pag.3 | ||
| 3-2 | 286278 | CYLINDER BC4321 / BKC4321 |
| 3-3 | 285772 | CYLINDER GASKET BC4321 |
| 3-4 | 261246 | SCREW CAP BC350 |
| 3-6 | 285779 | INSULATOR GASKET BC4321 |
| 3-9 | 285783 | GASKET SILENCER BC / BKC4321 |
| 3-11 | 266713 | SCREW SILENCER BKC5020 |
| 3-14 | 285786 | CYLINDER CASING BC4321 |
| 3-15 | 285843 | KNOB BKC / BC5020RS |
| 3-18 | 262658 | BEARING BC520 6202C3 |
| 3-19 | 262660 | OIL SEAL BC500 TC15357 |
| 3-20 | 262565 | OIL SEAL BC500 ISCD15257 |
| 3-21 | 012380 | O-RING BELL CLUTCH BKC5020RS |
| 3-23 | 285795 | PISTON BKC4321RS / BC4321 |
| 3-24 | 262476 | BC420 / BC450 PISTON RING |
| 3-25 | 262749 | PISTON PIN 520 / BKC520 |
| 3-26 | 262659 | CAGE ROLLER BC520 / BK520 |
| 3-27 | 262479 | CIRCLIP BC520 / BKC52 |
| 3-28 | 285797 | CRANKSHAFT BC4321 / BKC4321 |
| 3-29 | 282743 | CLUTCH BC / BKC-5020/4320 |
| 3-31 | 263617 | CLUTCH SPRING BC5020 |
| 3-32 | 282321 | CLUTCH SCREW BC4320 |
| 3-33 | 262683 | WASHER BC450 |
| 3-34 | 262682 | BC450 CLUTCH WASHER |
| 3-35 | 282285 | BC5020RS CLUTCH SIDE CARTER |
| 3-36 | 261250 | SCREW SILENCER BC350 |
| 3-39 | 287598 | ELECTRONIC COIL BC4321RS |
| 3-40 | 261076 | WOODRUF BKC5020RS |
| 3-55 | 280995 | SPRING STARTER BKC520RS |
| 3-59 | 262633 | STARTING HANDLE BC520 |
| 3-60 | 262981 | CAP HANDLE BC520 |
| 3-61 | 285679 | STARTER PAWL CPL BC5020 T.N. |
| 3-63 | 285681 | STARTER RECOIL PAWL BC5020 T.N. |
| 3-65 | 262638 | SEEGER BKC520 |
| 3-67 | 285736 | NUT M8 MCV3501 |
| 3-70 | 265694 | LABEL WARNING BC |
| 3-71 | 262714 | MARUYAMA RED / BLUE LABEL |
| 3-72 | 267561 | CARTER CYLINDER LABEL |
| Pag.4 | ||
| 4-3 | 263726 | LOWER COVER MCV3100 |
| 4-4 | 283905 | MEMBRANE MCV3100TS |
| 4-5 | 263727 | MEMBRANE BC450 |
| 4-6 | 262994 | DIAPHRAGM BC350 / BC520 |
| 4-7 | 282576 | MEMBRANE BKC5020RS |
| 4-10 | 261875 | SCREW HOLDER VALVE BCF500H |
| 4-12 | 261876 | SEEGER CARBURETTOR VALVE BC350 |
| 4-14 | 261658 | SWIVWL BKC520 |
| 4-15 | 261657 | BK520 CARBURETOR GASKET |
| 4-17 | 282299 | PRIMER BC5020 / BKC5020RS |
| 4-18 | 282512 | PRIMER HOSE BC5020 |
| 4-19 | 282301 | CARBURETOR GASKET BC5020 |
| 4-20 | 282302 | AIR FILTER CASE ASS'Y BC5020RS |
| 4-21 | 282303 | AIR FILTER CASE BC5020 |
| 4-23 | 282304 | AIR COVER VALVE BKC5020RS |
| 4-24 | 282305 | AIR LEVER BC5020H |
| 4-25 | 269032 | SCREW AIR VALVE BKC5020RS |
| 4-29 | 282481 | AIR FILTER PLATE BC5020 |
| 4-30 | 282306 | AIR FILTER BC5020 / BKC5020RS |
| 4-31 | 285814 | AIR FILTER COVER BC4321RS |
| 4-32 | 281438 | FILTER KNOB BC5020H |
| 4-34 | 286067 | BKC4321RS TANK |
| 4-35 | 281564 | CAP S.CPL BC5020 * uses 275306 |
| 4-36 | 269377 | GASKET BC5020 |
| 4-38 | 268065 | GROMMET BC/BKC5020 |
| 4-39 | 261117 | CLAMP TANK BC450 |
| 4-41 | 261590 | TANK VALVE |
| 4-42 | 261117 | CLAMP TANK BC450 |
| 4-43 | 267328 | FUEL FILTER BC5020 |
| 4-45 | 261117 | CLAMP TANK BC450 |
