at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Planer MT191.
In the following table, look for the model of Planer and the respective parts of the code.
| Planer Maktec MT191 | ||
| # | Part Num. | Description |
| 1 | 265147-9 | SCREW M4X25 |
| 2 | 451329-1 | CONVOGLIATORE KP0800K |
| 3 | 893488-9 | GRADUATED SCALE MT191 |
| 4 | 272408-0 | KNOB 44 MT191 |
| 5 | 267278-0 | WASHER 10 MT191 |
| 6 | 140943-5 | MT191 FRAME |
| 9 | 682569-2 | CABLE SLEEVE MT601 |
| 10 | 645190-8 | CAPACITOR X MT952 |
| 11 | 687124-5 | Cable tie CLAMP MT953 |
| 12 | 266326-2 | SCREW 4x18 X MT601 |
| 14 | 650217-1 | Switch,. FA1-6 / 1B-1 X MT191 |
| 15 | 452811-3 | COVER HANDLE MT191 |
| 16 | 266326-2 | SCREW 4x18 X MT601 |
| 17 | 210067-2 | BEARING 6000ZZ X MT952 |
| 18 | 240068-6 | FAN 52 MT191 |
| 19 | 510208-3 | ARMATURE MT191 |
| 20 | 681672-6 | INSULATOR MT191 |
| 21 | 210062-2 | BEARING 607ZZ X MT601 |
| 22 | 593589-0 | STATOR FOR MT191 |
| 23 | 452812-1 | PARATIA MT191 |
| 24 | 266334-3 | SCREW 4X60 HR2460 |
| 25 | 263002-9 | PIN RUBBER 4 |
| 27 | 191940-4 | CARBON BRUSHES CB-411 X EX 422/421 |
| 28 | 643987-9 | PLUG BRUSH 5-8 MT952 |
| 29 | 265757-2 | SCREW M5x10 MT191 |
| 30 | 233395-8 | SPRING COMPRESSION 18 MT191 |
| 31 | 421858-8 | RUBBER BASE MT191 |
| 32 | 318780-7 | REAR BASE MT191 |
| 33 | 266326-2 | SCREW 4x18 X MT601 |
| 34 | 318499-8 | BASE KP0800K |
| 35 | 210029-0 | BEARING 608Z X MT601 |
| 36 | 161140-0 | DRUM MT191 |
| 37 | 265512-2 | SCREW M6X17 MT191 |
| 38 | 187679-5 | September PLATE DRUM |
| 39 | 265132-2 | SCREW M 4X5 X KP0800K |
| 40 | 345378-7 | PLATE KNIVES MT191 |
| 42 | 263002-9 | PIN RUBBER 4 |
| 43 | 210067-2 | BEARING 6000ZZ X MT952 |
| 44 | 140944-3 | LATERAL SUPPORT MT191 |
| 45 | 222163-4 | PULLEY 4-20L KP0800K |
| 46 | 266326-2 | SCREW 4x18 X MT601 |
| 47 | 452813-9 | COVER BELT MT191 |
| 48 | 265101-3 | SCREW M4 X 25 X MT240 |
| 50 | 225092-0 | BELT 4-241 MT191 |
| 51 | 222164-2 | PULLEY 4-37 KP0800K |
| 52 | 343433-9 | Set Plate (mini Blade) |
| 53 | 231698-4 | SPRING TWIST 7 X KP0810K |
| 54 | 451392-4 | FOOT KP0800K |
| 501 | D-07945 | BLADE 82 MM 2 PCS |
