We supply original Maktec spare parts on offer at unbeatable prices, we are an service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Cordless Impact Driver MT691E.
In the following table, look for the model of Cordless Impact Drivers and the respective parts of the code.
Items will be shipped within 7/10 working days approx.
| Impact Drivers Maktec MT691E | ||
| 1 | 187419-1 | HOUSING ENGINE MT690-691 |
| 2 | 266429-2 | SCREW 3X16 FOR TD0101F |
| 5 | 453055-8 | LEVER REVERSIBILITA'MT690-691 |
| 6 | 632A37-1 | SWITCH MT690-691 |
| 7 | 643869-5 | TERMINAL MT071 |
| 8 | 231951-8 | RING IN SPRING 11 X 6903VDW |
| 9 | 267085-1 | FLAT WASHER 12 X 6903VDW |
| 10 | 233005-7 | SPRING 13 X 6903VDW / BTD130F |
| 11 | 324420-7 | SLEEVE X 6903VDW / BTD130F |
| 12 | 266374-1 | SCREW 4X25 FOR GA9020 |
| 13 | 141725-8 | HOUSING LEAF X MT690-691 |
| 14 | 261151-6 | WASHER NYLON 19 BTD134 |
| 15 | 216040-0 | BALL 3.5 |
| 16 | 326188-1 | ANVIL M MT690-691 |
| 17 | 326110-8 | SWING MT690-691 |
| 18 | 216040-0 | BALL 3.5 |
| 19 | 267175-0 | FLAT WASHER 24 6914DW |
| 20 | 233430-2 | SPRING COMP. 24 X BTD130F |
| 21 | 267766-7 | FLAT WASHER 24 6914DW |
| 22 | 216011-7 | BALL 5.6 X BTD130F |
| 23 | 226336-1 | GEAR 22 X 6908DW / BTD130 |
| 24 | 326109-3 | SHAFT MT690-691 |
| 25 | 256253-1 | PIN 5 X 6908DW / BTD130F |
| 26 | 267212-0 | FLAT WASHER 12 X 6916DW |
| 27 | 227279-0 | GEAR 51 MT690-691 |
| 28 | 211131-2 | BALL BEARING 6001DD |
| 29 | 453056-6 | BOX BEARING MT690-691 |
| 30 | 629973-4 | ENGINE DC MT691 |
