Makita Spare Parts for Angle Grinder GA7050R
€13.41
Tax included
Makita Spare Parts for Angle Grinder GA7050R
Makita genuine spare parts or replacement parts for to fix Angle Grinder GA7050R.Fix Your Angle Grinder. All Spares can be supplyed at discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Angle Grinder GA7050R
Makita genuine spare parts or replacement parts for to fix Angle Grinder GA7050R.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GA7050CR | ||
| # | Part Num. | Description |
| 1 | 451485-7 | PIN CAP GA9050R |
| 2 | 233292-8 | COMPRESSION SPRING 12 |
| 3 | 266373-3 | TAPPING SCREW 5x35 GA9020 |
| 4 | 140223-9 | GEAR HOUSING COMPLETE GA9050R |
| 5 | 213487-9 | O-RING 31 AF550H |
| 6 | 264010-3 | HEX.NUT M7 GA5010 |
| 7 | 227564-1 | SPIRAL BEVEL GEAR 10B |
| 8 | 211137-0 | BALL BEARING 6201LLU HM0860C |
| 9 | 257965-9 | O-RING R-32 GA9050R |
| 10 | 240120-0 | FAN 80 GA9050R |
| 11 | 518747-7 | ARMATURE ASSEMBLY 240V GA9050R |
| 12 | 681657-2 | INSULATION WASHER GA9050R |
| 13 | 210059-1 | BALL BEARING 6000 HR2010 |
| 14 | 421490-8 | RUBBER RING 26 1805B |
| 15 | 451480-7 | BAFFLE GA9050R |
| 16 | 527700-2 | FIELD ASSY GA9050R |
| 17 | 266389-8 | SCREW 5X70 FOR UC3020A |
| 18 | 140222-1 | MOTOR HOUSING GA9050R |
| 19 | 643710-2 | BRUSH COVER HM1500 |
| 20 | 191957-7 | CARBON BRUSH SET CB-204 (201.202) |
| 22 | 188849-9 | HANDLE SET GA9050R |
| 23 | 645088-9 | CAPACITOR GA9020 |
| 24 | 631944-9 | CONTROLLER GA9050R |
| 25 | 650107-8 | SWITCH TG08-2300-013 GA9050R |
| 26 | 266192-7 | TAPPING SCREW 4X14 HR4001C / HR4010C |
| 27 | 687169-3 | STRAIN RELIEF HP1620 |
| 28 | 682574-9 | CORD GUARD 10-90 PC5000C |
| 31 | 265999-8 | TAPPING SCREW 4X25 |
| 32 | 213026-5 | O-RING 7 GA9010C |
| 33 | 256516-5 | SHOULDER PIN 11 GA9050R |
| 34 | 263002-9 | RUBBER PIN 4 |
| 35 | 210029-0 | BALL BEARING 608Z MT601 |
| 36 | 233925-5 | O-RING 13 6413 |
| 37 | 227562-5 | SPIRAL BEVEL GEAR 38 |
| 38 | 285851-4 | BEARING RETAINER GA9050R |
| 39 | 911128-8 | TAPPING SCREW M4x16 HR4000C |
| 40 | 211241-5 | BALL BEARING 6202DDW MT601 |
| 41 | 213720-9 | O-RING 67 HR2400 |
| 42 | 922221-3 | TAPPING SCREW M5X16 HM1303 |
| 43 | 318523-7 | BEARING BOX GA9050R |
| 44 | 140224-7 | SPINDLE COMPLETE A GA9050R |
| 45 | 122889-7 | HWHEEL COVER 230K ASSEMBLY GA7020 |
| 46 | 224415-9 | INNER FLANGE 42 GA95010 |
| 47 | 224543-0 | LOCK NUT 14-45 9047F 9049F 9049SF |
| 48 | 892805-0 | CLEAR LABEL GA9050R |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
