Makita Spare Parts for Air Compressor AC320H
Makita original spare parts for to replace broken parts for to fix Air Compressor AC320H.
In the following table, look for the model of Air Compressor and the respective parts of the code.
| Air Compressor AC320H | ||
| # | Part Num. | Description |
| 1 | AM1101239A | PROTECTION COVER DUST |
| 2 | AM1101238A | DUST COVER AC320H |
| 3 | AM1101211A | SWITCH X AC320H |
| 4 | AM1101280A | CONTROL PANEL X AC320H |
| 5 | AM1101254A | SCREW 5 X AC320H |
| 9 | AM1101232A | COVER BLACK X AC320H |
| 10 | AM1101231A | SCREW M5 X AC320H |
| 11 | AM1101254A | SCREW 5 X AC320H |
| 12 | AM0802354A | SCREW X AC320H |
| 13 | AM0802278A | PILLOW X AC320H |
| 14 | AM0801992A | HOLDER FOR DX AC320H |
| 15 | AM1101219A | PRESSOMETRO 35 X AC320H |
| 16 | AM0801875C | COLLECTOR X PRESSOMETRO AC320 |
| 17 | AM0207700D | NIPPLE 1/4 "X AC320H |
| 18 | AM1101224A | REGULATOR H X AC320H |
| 19 | AM0801617B | SCREW 1/16 X AC320H |
| 20 | AM0801874F | SLEEVE HIGH PRESSURE AC320 |
| 21 | AM1101229A | PLUG H R1 / 4 X AC320H |
| 22 | AM1101229A | PLUG H R1 / 4 X AC320H |
| 23 | AM00801599 | NIPPLE R1 / 4 "X AC320H |
| 24 | AM1101208A | PLATE X AC320H |
| 25 | AM00801599 | NIPPLE R1 / 4 "X AC320H |
| 26 | AM1101222A | PRESSURE SENSOR X AC320H |
| 27 | AM1101230A | VALVE X AC320H |
| 28 | AM1101281A | TANK AIR X AC320H |
| 29 | AM0801324D | FOOT B X AC320H |
| 30 | AM1101221A | GRIP X AC320H |
| 31 | AMAF350791 | SCREW M6 X 14 X AC320H |
| 32 | AM1101209A | PROTECTION X AC320H |
| 33 | 344222-5 | 5-13 SOCKET |
| 34 | 911234-9 | SCREW M 5 X 20 X HK1820 |
| 35 | AM1101241A | RING P18 X AC320H |
| 36 | AM1101240B | CAP X AC320H |
| 37 | AM1101218A | PRESSOMETRO 15 X AC320H |
| 38 | AM0801875C | COLLECTOR X PRESSOMETRO AC320 |
| 39 | AM0207700D | NIPPLE 1/4 "X AC320H |
| 40 | AM1101217A | REGULATOR L X AC320H |
| 41 | AM1101208A | PLATE X AC320H |
| 42 | AM00801599 | NIPPLE R1 / 4 "X AC320H |
| 43 | AM00801599 | NIPPLE R1 / 4 "X AC320H |
| 44 | AM0801617B | SCREW 1/16 X AC320H |
| 45 | AM0801873E | COLLECTOR LOW PRESSURE AC320H |
| 46 | AM1101228A | JOINT 20SM X AC320H |
| 47 | AM1101228A | JOINT 20SM X AC320H |
| 48 | AM0801313D | FOOT X AC320H |
| 49 | AM0801899A | FITTING 6-R1 / 8 X AC320H |
| 50 | AM1101251A | TUBE DRAINAGE X AC320H |
| 51 | AM0801897A | ELBOW 6-R1 / 8 X AC320H |
| 52 | AM0801386D | SLEEVE DRAINAGE X AC320AH |
| 53 | AM0801307D | COCK DRAIN X AC320H |
| 54 | 941101-4 | FLAT WASHER 5 |
| 56 | AM0801895A | SCREW M5 X 12 X AC320H |
| 57 | AM1101216A | LOWER PROTECTION AC320H |
| 58 | 911114-9 | SCREW M4 X 10 |
| 59 | AM1101231A | SCREW M5 X AC320H |
| 60 | AM1101258A | COVER X AC320H |
| 61 | AM1101226C | GUIDE AC320H |
| 63 | 911114-9 | SCREW M4 X 10 |
| 65 | 911234-9 | SCREW M 5 X 20 X HK1820 |
| 66 | 344222-5 | 5-13 SOCKET |
| 67 | AM00801626 | RUBBER FOOT X AC320H |
| 68 | AM0801431A | SCREW M5x14 X AC320H |
| 69 | AM0801993A | WHEEL SX X AC320H |
| 70 | AM1101212A | CABLE SLEEVE X AC320H |
| 72 | 652014-1 | SCREW M4X8 X HM1301 |
| 73 | AM00801598 | ELBOW 10-R1 / 4 X AC320H |
| 74 | AM0802313A | TUBE 10 X AC320H |
| 75 | AM0801897A | ELBOW 6-R1 / 8 X AC320H |
| 76 | AM1101227A | TUBE 6 X AC320H |
| 77 | AM0801897A | ELBOW 6-R1 / 8 X AC320H |
| 78 | AM0801960A | SCREW M6X25 X AC320H |
| 79 | AM0801960A | SCREW M6X25 X AC320H |
| 80 | AM1101221A | GRIP X AC320H |
| 81 | AM0207700D | NIPPLE 1/4 "X AC320H |
| 82 | AM0801876C | COLLECTOR X AC320H |
| 83 | AM0502509B | PLUG 1/8 "X AC320H |
| 84 | AM0502509B | PLUG 1/8 "X AC320H |
| 85 | AM0502509B | PLUG 1/8 "X AC320H |
| 86 | AM1101213A | PRESSOMETRO 6.0 X AC320H |
| 87 | AM1101252A | CABLE RESET X AC320H |
| 88 | AM1101244A | CABLE SWITCH X AC320H |
| 89 | AM1101253A | CABLE PLUG X AC320H |
| 90 | AM1101242A | CABLE CONTROL PANEL X AC320H |
| 91 | AM1101223A | SENSOR CABLE X AC320H |
| 162 | AMAF350767 | SCREW M5 X 10 X AC320H |
| 163 | AM1101272A | TERMINAL NE-8 X AC320H |
| 164 | 911114-9 | SCREW M4 X 10 |
| 165 | AM1101270A | CONNECTOR X AC320H |
| 166 | AM1101271A | TERMINAL NE-6 X AC320H |
| 55 | AM1101278B | SPACER X AC320H |
| 62 | AM1101279A | SPACER S X AC320H |
| 92 | AMAF350774 | SCREW M5 X AC320H |
| 93 | AM1101225C | STATOR X AC320H |
| 94 | AM1101275B | HOUSING ROD X AC320H |
| 95 | 263005-3 | RUBBER PIN 6 |
| 96 | AM0801886A | BEARING 6204 X AC320H |
| 97 | AM0801323A | KEY 6 X AC320H |
| 98 | AM0802277A | SHAFT X AC320H |
| 99 | AM0802274A | Balancer X AC320H |
| 102 | AM1101287B | LOCKING PISTON X AC320H |
| 103 | AM0801905A | RING X AC320H |
| 104 | AM0503188E | RING X AC320H |
| 105 | AM00503229 | RING S5 X AC320H |
| 106 | AM00503242 | SCREW M5x14 X AC320H |
| 107 | AM0802281A | CONVOGLIATORE SX X AC320H |
| 108 | AM0802344A | CYLINDER SX X AC320H |
| 109 | AM0801359F | SEAL CYLINDER SX X AC320H |
| 110 | AM0802119A | PLATE BULB SX X AC320H |
| 111 | AM0801361F | SEAL HEAD SX X AC320H |
| 112 | AM0801363D | CYLINDER HEAD SX X AC320H |
| 113 | AM00801591 | SCREW M6x60 X AC320H |
| 114 | 942151-2 | WASHER 6 4101R |
| 115 | AM00801598 | ELBOW 10-R1 / 4 X AC320H |
| 116 | AM1101273A | TUBE 10 X AC320H |
| 119 | AM1101288B | PISTON X AC320H |
| 120 | AM0802258A | SHIRT X AC320H |
| 121 | AM0802256A | SPRING 94H X AC320H |
| 122 | AM0802257A | RING 41 X AC320H |
| 123 | AM0802282A | CONVEYOR H X AC320H |
| 124 | AM0802252A | CYLINDER H X AC320H |
| 125 | AM0802268A | SEAL CYLINDER H X AC320H |
| 126 | AM0802326A | PLATE BULB H X AC320H |
| 127 | AM00801589 | RING S12 X AC320H |
| 128 | AM00801598 | ELBOW 10-R1 / 4 X AC320H |
| 129 | AM00801578 | RING S42 X AC320H |
| 130 | AM0802323A | HEAD X AC320H |
| 131 | AMAF456457 | SCREW 4 X 12 X AC320H |
| 132 | AM00801598 | ELBOW 10-R1 / 4 X AC320H |
| 133 | 942151-2 | WASHER 6 4101R |
| 134 | AM00801591 | SCREW M6x60 X AC320H |
| 135 | AM0802274A | Balancer X AC320H |
| 136 | AM0802356A | SPACER X AC320H |
| 137 | AM0801895A | SCREW M5 X 12 X AC320H |
| 138 | AM0801717B | RETAINING CUSC. F 41.5 AC320H |
| 139 | AM0801886A | BEARING 6204 X AC320H |
| 140 | AM0802276A | BOX CUSC.F X AC320H |
| 141 | AM0801884A | SPACER BEARING AC320H |
| 142 | AM0801442B | WASHERS 18 X AC320H |
| 143 | AMAF430730 | NUT M18 X AC320H |
| 144 | 911234-9 | SCREW M 5 X 20 X HK1820 |
| 145 | AM0802290A | SEAL FILTER X AC320H |
| 146 | AM0802284A | FILTER X AC320H |
| 147 | AM0802283A | FILTER COVER X AC320H |
| 148 | AM00502451 | SCREW 5X8 X AC320H |
| 149 | 253744-3 | FLAT WASHER 12 24B / 12N / 14 |
| 150 | AM0801391E | FAN 190 X AC320H |
| 151 | 941201-0 | FLAT WASHER 8 |
| 152 | 931402-8 | NUT M8 X LS1013 |
| 153 | AMAF350385 | SCREW M4X12 X AC320H |
| 154 | AM0801889A | PLATE X AC320H |
| 155 | AM0801926B | FAN X AC320H |
| 156 | AMAF350767 | SCREW M5 X 10 X AC320H |
| 157 | AM0802028A | ARMATURE X AC320H |
| 158 | AM0801940A | SCREW M8 X 25 X AC320H |
| 159 | AMAF450405 | WASHER ELAST. 8 X AC320H |
| 160 | AM1101276A | SPACER STATOR X AC320H |
| 161 | AM0802279A | KEY 6 X AC320H |
