Bosch Spare Parts for Router GOF 1600 CE
We are BOSCH original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Router GOF 1600 CE - 3601F24000.
In the following table, look for the model of the Router and the respective parts of the code.
| Router GOF 1600 CE/3 601 F24 000 | ||
| # | Part Num. | Description |
| 1 | 2610011547 | Motor Housing |
| 2 | 1619P05305 | Field 230V |
| 5 | 2610006401 | Cord |
| 6 | 1600703034 | Grommet Ø7,3-Ø8,6x66 MM |
| 7 | 2601035001 | Cable Clip |
| 12 | 2610006567 | Suppression Capacitor |
| 13 | 3600905513 | groove ball bearing |
| 14 | 3600905512 | groove ball bearing |
| 16 | 2610913034 | Brush Holder |
| 19 | 2910141158 | Hex Socket Head Cap Screw DIN 912-M5X16-8.8 |
| 21 | 3604652500 | Spiral Spring |
| 22 | 1604477005 | Blade terminal |
| 23 | 2610955195 | Baffle |
| 24 | 2610011225 | Spindle Nut |
| 25 | 2610957779 | Housing |
| 26 | 2610991375 | Bearing Holder |
| 27 | 1900210115 | O-Ring |
| 29 | 2910611006 | Tapping Screw DIN 7981-ST2,9x13-C-H |
| 30 | 2610991306 | Tapping Screw |
| 31 | 2910641122 | Oval-Head Screw DIN 7985-M4X12-4.8-H |
| 32 | 2610910566 | Tapping Screw |
| 34 | 2610957736 | Cover |
| 35 | 2610957739 | Connector |
| 36 | 2610001624 | Light-Emitting-Diode |
| 37 | 2610957738 | Clamp |
| 38 | 2910641054 | Screw |
| 39 | 2610011549 | shaft lock |
| 40 | 2610011958 | Bosch Label |
| 41 | 2610041829 | Nameplate |
| 42 | 2610000607 | Clamp |
| 43 | 2916680005 | Spring Lock Washer B 4 DIN 127 |
| 44 | 2610957778 | Locating ring |
| 45 | 2610003090 | Screw |
| 47 | 2610003185 | Cable Set |
| 48 | 2610001625 | Sensor |
| 49 | 2610011569 | Cover |
| 205 | 2610003067 | Set screw |
| 207 | 2610956312 | Base Plate |
| 208 | 2610917210 | Screw |
| 210 | 2610001597 | Spring |
| 211 | 2610001598 | Guide |
| 212 | 2610001599 | Retaining snap ring |
| 214 | 2610001600 | Spring |
| 218 | 2610001602 | Washer |
| 219 | 2600590006 | Ratchet Cap |
| 220 | 2610957846 | Locking Piece |
| 221 | 2610957844 | Cover |
| 222 | 2610959394 | Lock Bolt |
| 223 | 2610001604 | Spring |
| 224 | 2610011957 | Scale |
| 225 | 2910641122 | Oval-Head Screw DIN 7985-M4X12-4.8-H |
| 226 | 2916680005 | Spring Lock Washer B 4 DIN 127 |
| 227 | 2610957845 | Stud |
| 228 | 2610957840 | Cover |
| 229 | 2610957841 | Cover |
| 230 | 2610002911 | Screw |
| 231 | 3600100527 | Washer |
| 232 | 2610006391 | Washer |
| 234 | 2610957812 | Handle |
| 235 | 2610001605 | Handle |
| 236 | 2610996143 | Screw |
| 237 | 2610913441 | Screw |
| 238 | 2610957811 | Handle |
| 239 | 2610001607 | Handle |
| 240 | 2610001608 | Mains switch |
| 241 | 2610001609 | Terminal Plate |
| 242 | 2610003210 | Trigger |
| 243 | 2610956413 | Rod |
| 244 | 2610956414 | Sleeve |
| 245 | 2610957843 | Knob |
| 246 | 2610957842 | Indicator Ring |
| 247 | 2610956415 | Screw |
| 251 | 2610956416 | Indicator |
| 253 | 2610000606 | Button |
| 255 | 2610001606 | Spring |
| 259 | 2610003062 | Retaining snap ring |
| 260 | 2610003063 | Washer |
| 261 | 2610003064 | Washer |
| 262 | 2610004460 | Pipe |
| 263 | 2610008283 | Pipe |
| 264 | 2610005997 | Screw |
| 265 | 2610005516 | Screw |
| 266 | 2610004411 | Spring |
| 305 | 2610003067 | Set screw |
| 306 | 2610956311 | Base Plate |
| 307 | 2610917210 | Screw |
| 308 | 2610957812 | Handle |
| 309 | 2610001605 | Handle |
| 310 | 2610996143 | Screw |
| 311 | 2610913441 | Screw |
| 312 | 2610957811 | Handle |
| 313 | 2610001607 | Handle |
| 314 | 2610001608 | Mains switch |
| 315 | 2610003184 | Terminal Plate |
| 316 | 2610005997 | Screw |
| 317 | 2610957843 | Knob |
| 318 | 2610957842 | Indicator Ring |
| 319 | 2910641122 | Oval-Head Screw DIN 7985-M4X12-4.8-H |
| 321 | 2610001817 | Rod |
| 322 | 2610996054 | Retaining snap ring |
| 323 | 2610001818 | Lever |
| 327 | 2610003210 | Trigger |
| 328 | 2610000606 | Button |
| 329 | 2610004411 | Spring |
| 330 | 2610001606 | Spring |
| 331 | 2610991372 | Cover |
| 332 | 2610006340 | Spring |
| 334 | 2916680005 | Spring Lock Washer B 4 DIN 127 |
| 651 | 2610992417 | Single-Head Eng. Wrench |
| 652 | 2610923193 | Adjusting Wrench |
| 800 | 2610003974 | Motor Carrier |
| 801 | 2610003969 | Motor Carrier |
| 803 | 2610025596 | Armature 230V |
| 806 | 2610003970 | Base |
| 808 | 2610014382 | Nameplate |
| 810 | 2610007957 | Carbon-Brush Set |
| 816 | 2610003971 | Depth-Gauge |
| 824 | 2610003973 | Lever |
| 828 | 2610011286 | Cover |
| 838 | 2610018987 | Electronic Module |
