Makita Spare Parts for Wall Chaser SG150/2
search
  • Makita Spare Parts for Wall Chaser SG150/2
  • Makita Spare Parts for Wall Chaser SG150/2 - Drawing

Makita Spare Parts for Wall Chaser SG150/2

€8.27
Tax included

Makita Spare Parts for Wall Chaser SG150/2

We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Wall Chaser 1800W 150 mm Makita SG150/2.
ITEM CODE: 211066-7
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Wall Chaser SG150/2

We are MAKITA original spare parts Worldwide Dealers

 at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Wall Chaser 1800W 150 mm Makita SG150/2.

In the following table, look for the model of Groover and the respective parts of the code.
Makita SG150/2

Wall Chaser Makita SG150/2
# Part Num. Description
1 B47720 BOLT X SG150
2 B03384 WRENCH 13/17 X SG150
3 B35915 ARMATURE X SG150
4 211066-7 BEARING HM1301 - 6200
5 B32615 RING X SG150
6 B50815 GEAR BOX X SG150
7 B33415 SCREW M5 X 20 X SG150
8 B07450 SCREW M4,8 X 80 X SG150
9 B30379 PLATE 0.2X SG150
9 B30387 PLATE X 0.3 SG150
9 B30361 PLATE 0.15 X SG150
13 B30130 BEARING X SG150
14 B30015 SOCKET X SG150
15 211490-4 BEARING 6203LLU X SG150-2
16 B46748 POST X SG150
17 B30148 RING 46X2 X SG2150
18 B11122 BOLT M 8 X 90 X SG150
19 B11189 WASHER 8.4 X SG150
20 B33415 SCREW M5 X 20 X SG150
21 B10777 TENSION ROLLER X SG150
22 B11247 TUBE X SG150
23 B18952 NUT M8 X SG150
24 B33407 BOLT M 8 X 55 X SG150
25 B10983 BOLT M 8 X 16 X SG150
26 B29934 EXTERNAL FLANGE X SG150
27 B30486 RING 3 X SG150
28 B10678 RING 10 X SG150
29 B30494 RING 18 X SG150
30 B50831 SAFETY COVER X SG150
31 B11528 BOLT M 8 X 25 X SG150
32 B29884 RING 2.7X SG150
33 B30171 STOP BEARING X SG150
34 B50823 BEARING BOX X SG150
35 B21071 WASHER M8 X SG150
36 B18952 NUT M8 X SG150
38 B41418 VANE X SG150
39 B36137 SCREW M4 X 80 X SG150
40 B50849 STATOR 220 X SG150
41 B08482 HANDLE SIDE X SG150
42 B21030 SCREW M3,9 X 13 X SG150
43 B45625 COVER PORTACARBONCINI X SG150
44 B32508 PORT CARBON BRUSHES X SG150
45 B45872 CARBON BRUSHE (1 pc) X SG150
47 B45443 HOUSING MOTOR X SG150
48 B31096 TUBE X SG150
49 B09506 TENSION ROLLER X SG150
50 B26948 WASHER 13 X SG150
51 B30981 BOLT M 7 X 12 X SG150
52 B31070 WASHER 7.4 X SG150
53 B10801 HOLDER X SG150
54 B32607 HANDLE COMPLETE X SG150
55 B14886 MUFFLER X SG150
56 B25221 SAVE CABLE X SG150
58 B17913 CLAMP X 2702
59 B20990 SCREW M3,9 X 16 X SG150
60 B31468 SWITCH X SG150
61 B44941 SCREW M4,8 X 38 X SG150
62 B42721 SCREW M3,9 X 19 X SG150
63 B35055 CONTROLLER X SG150
