Makita Spare Parts for Rotary Hammer HR3850K
€288.66
Tax included
Makita Spare Parts for Rotary Hammer HR3850K
We are Dealers of MAKITA original spare parts at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer HR3850K.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Rotary Hammer HR3850K
We are Dealers of MAKITA original spare parts at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Rotary Hammer HR3850K.
In the following table, look for the model of Hammer and the respective parts of the code.
| Rotary Hammer HR3850K | ||
| # | Part Num. | Description |
| 1 | 212551-3 | NEEDLE BEARING 4516 |
| 2 | 267057-6 | FLAT WASHER 40XHR3850B |
| 3 | 311674-5 | BARREL X HR3850 / B |
| 4 | 213655-4 | O Ring 56, HR3510 / 20 / HM12 - Hr3851 |
| 5 | 212551-3 | NEEDLE BEARING 4516 |
| 6 | 253832-6 | FLAT WASHER 45XHR3850B |
| 7 | 221347-1 | GEAR 36 X HR3850 / B |
| 8 | 321369-2 | STRIKER X HR3850B |
| 9 | 412038-7 | Piston Ring 34, Hr3851 |
| 10 | 412041-8 | INNER RING BATT.30 |
| 11 | 412038-7 | Piston Ring 34, Hr3851 |
| 12 | 341743-8 | Inner Ring 30, Hr3851 |
| 13 | 256029-6 | PIN 8 X HR3850 / B |
| 15 | 411709-3 | CRANK CAP HR3850 / B / HM0810 |
| 16 | 213654-6 | O-RING 60 HR3850B / HM0810 |
| 17 | 312956-8 | Rod, Hm0810B |
| 18 | 212108-0 | Needle Bearing 1212, Hr3851 |
| 19 | 321726-4 | CRANKSHAFT XHR3850 / B |
| 20 | 254001-2 | WOODRUFF KEY 4 |
| 21 | 962203-3 | RETAINING RING R47 |
| 22 | 211306-3 | BALL BEARING 6204DD |
| 23 | 213606-7 | O-RING 48 HR3850 / B / HR2510 |
| 24 | 157307-6 | CRANK HOUSING HR3850 / B |
| 25 | 221689-3 | GEAR 33 X HR3850 / B |
| 26 | 212102-2 | NEEDLE BEARING BK 1210 |
| 27 | 212359-5 | NEEDLE BEARING 2216 |
| 29 | 134527-9 | TORQUE LIMITER ASS'Y X HR3850 / B |
| 34 | 253314-8 | WASHER 15 X6906 / HR3850B |
| 35 | 421689-5 | O-RING 100 X HR3850 / B |
| 36 | 157306-8 | GEAR HOUSING HR3850 / B |
| 37 | 263005-3 | RUBBER PIN 6 |
| 38 | 961011-9 | RETAINING RING E4 |
| 40 | 212011-5 | NEEDLE BEARING 609 |
| 41 | 213055-8 | O-RING 10 XHR3850 / B |
| 42 | 321727-2 | CHANGE SHAFT HR3850 / B |
| 43 | 342786-3 | PLATE X HR3850 / B |
| 44 | 216002-8 | Steel Ball 4.8, Wt01W |
| 45 | 231317-2 | SPRING 3 X HR3850 / B |
| 46 | 410331-3 | LEVER X HR3850 / B |
| 47 | 941052-1 | FLAT WASHER 4 |
| 49 | 922126-7 | SCREW M4x16 HR5000K / 3850B |
| 50 | 942101-7 | WASHER 5 |
| 51 | 922212-4 | SCREW M5x12 |
| 52 | 321370-7 | PISTON X HR3850 / B |
| 53 | 254231-5 | Key 4x2,5x21,5-22, HR3520 / HR3850B - Hr3851 |
| 54 | 152335-6 | CYLINDER LINER 34 X HR3850 / B |
| 55 | 321934-7 | IMPACT BOLT X HR3850K |
| 56 | 216004-4 | Steel Ball 7.9, Hr385 |
| 57 | 213471-4 | O-RING 31.5 HR5000K |
| 58 | 213419-6 | O-RING 30 HR5000K |
| 60 | 213604-1 | O Ring 50, HR3850 / B - 6911D |
| 61 | 331301-8 | TOOL RETAINER X HR3850B |
| 62 | 322860-3 | TOOL HOLDER X HR3850K |
| 65 | 922341-3 | SCREW M6X25 |
| 66 | 213459-4 | O Ring 32,HR3850B - 5007F |
| 67 | 211109-5 | BALL BEARING 6201 X HM1303 |
| 68 | 213160-1 | OIL SEAL 14 XHR3850 / B |
| 69 | 241634-2 | FAN 94 X HR3850 / B |
| 70 | 514773-4 | ARMATURE X HR3850 / B |
| 71 | 681646-7 | Insulation Washer, HM1200 / 3612BR - Hm1211B |
| 72 | 211066-7 | BALL BEARING HM1301 - 6200 V |
| 73 | 213406-5 | O Ring 30, 58NB / SB / HM1200 - Hr5000 |
| 74 | 410163-8 | BAFFLE PLATE HM1200 / HR3850 |
| 75 | 265347-1 | SCREW M5X45 |
| 76 | 524633-2 | STATOR X HM1200 / HR3850 / B |
| 79 | 159034-1 | MOTOR HOUSING HM1200 / HR3850 / B |
| 80 | 643650-4 | Brush Holder Cap, 5007F |
| 81 | 181048-2 | Carbon Brush Set, CB155 (CB-161) |
| 82 | 284055-5 | REAR COVER HM1200 / HR3850 |
| 83 | 942101-7 | WASHER 5 |
| 84 | 922222-1 | SCREW M5X16 |
| 85 | 922376-4 | SCREW M6x55 |
| 87 | 941151-9 | WASHER 6 X HM1303 |
| 88 | 252014-7 | NUT M6-10 |
| 89 | 942151-2 | WASHER 6 4101R |
| 90 | 941151-9 | WASHER 6 X HM1303 |
| 91 | 911243-8 | SCREW M5x25 HR2010 |
| 93 | 182077-8 | HANDLE SET XHM1200 / K |
| 94 | 911129-6 | P.H. Screw M4X16, Hr5000 |
| 95 | 421265-5 | DUST COVER HR3850 / B |
| 96 | 273472-4 | KNOB 32 X HR3850 |
| 97 | 924321-5 | SCREW M6x18 |
| 98 | 261049-7 | RUBBER WASHER 5.5 X HR3850 / B |
| 99 | 164543-7 | GRIP BASE X HR3510 / 3850B |
| 100 | 164572-0 | GRIP HOLDER XHR3850 |
| 101 | 922316-2 | BOLT M6 X 14 |
| 103 | 343754-9 | PLATE XHR3850 / HR5000K |
| 105 | 321210-9 | Handle Shaft, 3850/B - Hr3851 |
| 106 | 682505-8 | CABLE SLEEVE 10/90 |
| 108 | 687001-1 | CABLE CLAMP |
| 109 | 911133-5 | SCREW M4X18 |
| 110 | 922341-3 | SCREW M6X25 |
| 112 | 651145-3 | SWITCH C3D-H-MS |
| 113 | 645179-6 | CAPACITOR |
| 114 | 231375-8 | SPRING 15 X HR3850B |
| 115 | 265321-9 | BOLT M8x12 X HR3850B |
| 118 | 262051-3 | RUBBER RING 9-6 XHR 3850 |
| 119 | 262052-1 | RUBBER RING 9-3 XHR 3850 |
| 120 | 257636-8 | SLEEVE 6 X HR3850 |
| 121 | 654020-2 | TERMINAL RING CB-5 94 |
| 999 | 193282-2 | SERVICE KIT HR3850K |
