Makita Spare parts for Cordless Chainsaw UC250D
search
  • Makita Spare parts for Cordless Chainsaw UC250D
  • Makita Spare parts for Cordless Chainsaw UC250D - Drawing

Makita Spare parts for Cordless Chainsaw UC250D

€20.07
Tax included

Makita Spare parts for Cordless Chainsaw UC250D

Makita original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Chainsaw UC250D.
ITEM CODE: 451972-6
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare parts for Cordless Chainsaw UC250D

Makita original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Cordless Chainsaw UC250D.

In the following table, look for the model of the Cordless Chain Saw and the respective parts of the code.
Makita UC250D

Makita UC250D Cordless Chainsaw 36v Spare Parts
# Part Num. Description
1 451972-6 Front handle AS3625
2 266351-3 Tapping Screw 4x35
2 266048-4 Tapping Screw 4x35
3 265A48-7 Tapping Screw 4x18
4 643941-3 Holder cap
5 194928-3 Carbon Brush Pair CB-442, new model
6 643891-2 Brush Holder Bss610
7 643892-0 BRUSH HOLDER
8 869535-8 Rating plate with the main characteristics
9 631971-6 CONTROLLER
10 188910-2 Housing Set Buc250Rd
11 266173-1 Tapping Screw 5x30
12 140494-8 FRONT HAND GUARD COMPLETE
13 231298-0 Compression spring 6
14 451973-4 Handle Guard support AS3625 Buc250Rd
15 416178-3 Lock Off Button Buc121/122
16 233173-6 Compression spring 4
17 650631-1 On / Off Power Safety Switch For Chainsaws & Circular Saws
18 450212-9 Switch lever Buc121/122
19 643849-1 Terminal Bub360Z/Bbc231/Bbc250
20 346039-2 Support plate Bhr261
21 632H52-7 Yoke Unit Bjr182/Bss611 DUC302
22 451970-0 Baffle Plate Buc250Rd MUC350D
23 266292-3 Pt Screw 4X65 Bjr240
24 210062-2 Ball Bearing 607Zz Bo3710 / 11 Td0101F / Sma900 / Mt952
24 211382-7 ball Bearing 607ZZ
25 519268-2 Armature 36V Buc250 AS3625
26 210194-5 Ball Bearing For 629Ddw Bo5031/3613612/C
27 227252-0 Spur Gear 16 Buc250Rd
28 252186-8 Hex Nut M6 9553-9558Nb
29 256123-4 Pin 5
30 158047-9 Link Plate Complete Uc4020A Uc3520A
31 233175-2 Compression Spring 9 Dcs230T
32 265A48-7 Tapping Screw 4x18
33 267195-4 Flat Washer DCS230T, series UC3020A
34 210213500 Brake Band
35 140488-3 BEARING HOUSING COMPLETE
36 213039-6 O Ring 6 An942/Uc3520A/Uc4020A
37 422058-3 Connector AS3625
38 211012-0 Ball bearing 606ZZ
39 961006-2 Ext Din 471 Circlip-10
40 221422-3 Worm Gear Dcs230T
41 227251-2 Spur Gear 73 Buc250Rd
42 325931-5 SPINDLE
43 210163-6 Ball Bearing 6001DDW DUC302
43 210163-6 Ball Bearing 6001DDW DUC302
44 265A48-7 Tapping Screw 4x18
45 257311-6 RING 28
46 168393-2 oil pump
47 421875-8 Grommet Dcs230T
48 265A48-7 Tapping Screw 4x18
49 422313-3 Connector AS3625 Buc250Rd
50 450437-5 Filter AS3625
51 451974-2 OIL TANK
52 424326-0 Sponge Sheet AS3625
53 188910-2 Housing Set
54 140L60-3 Housing Set Buc250Rd
55 221526-1 Sprocket For UC3520A UC4020A UC300D DUC302 BUC250 UC250D DUC252
56 961014-3 8mm External E-Ring
56 259054-6 Stop ring E-8 AK3622
57 265A48-7 Tapping Screw 4x18
58 266007-8 Pt Screw 3X10 Tribular DCS230T BO3700 9558NB DCS551 DRT180
59 419241-1 Cover Uc4020A/3520A
60 227496-2 Spiral Bevel Gear 14 UC4020A UC3520A DUC306 DUC256 UC3020A, UC3020A
61 227495-4 Spiral Bevel Gear 14 UC4020A UC3520A UC4030A BUC300, UC3020A
62 324620-9 Adjust Screw UC4020A UC3520A BUC250 UC300D UC3541A
63 324621-7 Adjust Pin Uc4020A/3520A
64 233033-2 Compression Spring 4 Uc4020A Uc3520A
65 216008-6 Steel Ball Bearing Size 4mm
66 140486-7 SPROCKET COVER COMPLETE
67 252168-0 Hex Nut M8-13 Uc4020A/3520A
68 231025-5 Compression spring 8
69 317977-5 Lever Holder Uc4020A/3520A
70 453061-3 Cup Washer 20 Uc4020A/3520A
71 154763-1 Lever Complete Uc4020A/3520A, UC3020
72 951122-8 Spring Pin 4-28 2012Nb
73 915106-0 Binding Hd Screw M4x8 Uc4020A Uc3520A
74 253874-0 Large Blue Washer 4
75 419233-0 Dial 40 Uc4020A/3520A
1001 182229-1 OIL SUPPLY 100CC
1002 168408-5 GUIDE BAR 10 - 250 mm 3/8" 1.3 mm
** 191H08-4 250 mm (10") Saw Chain, 3/8" LP, .050"
1003 452093-7 GUIDE BAR CASE
1004 196205-9 10 Inch Chain Saw Chain 250 mm 3/8 1.3 mm 40L DUC250
1005 744003-1 FILE 4
1006 195471-5 DC36WA BATTERY CHARGER
1007 195410-5 Battery Li-ion BL3622A 36 V
1008 451153-2 BATTERY COVER
5001 688131-1 Line Filter Td0101F / Hm1810 Gn900Se / Mt240 / Hr2432
5002 688172-7 LINE FILTER
5003 BHL360/KIT KIT BHL360+195471-5+195410-5
5004 BHL360/KIT1 KIT BHL360+195471-5+2 195410-5
5005 BHL360/KIT2 KIT BHL360+195471-5+4 195410-5
5006 BHL360/KIT3 KIT BHL360+195471-5+195410-5
5007 BHL360/KIT4 KIT BHL360+195471-5+2 195410-5
5008 BHL360/KIT5 KIT BHL360+195471-5+4 195410-5
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
