Makita Spare Parts for Wall Chaser SG1251J/2

€38.65
Tax included

Makita Spare Parts for Wall Chaser SG1251J/2

Makita original spare parts for to replace broken parts for to fix Wall Chaser 1400W 125 mm Makita SG1251J/2.

Fix Your Wall Chaser. All Spares are Ready For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 153488-4
Quantity
on 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Wall Chaser SG1251J/2

Fix Your Wall Chaser 1400W 125 mm Makita SG1251J/2. All Spares can be supplied at disconted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of Groover and the respective parts of the code.
Makita SG1251J/2

Wall Chaser Makita SG1251J/2
# Part Num. Description
1 265995-6 SCREW M4X18 X 6408 / 6221DW
2 187942-6 HANDLE
3 266048-4 SCREW M 4 X 40 X 4334D
4 911263-2 HEAD SCREW CILIND. M5x40
5 424457-5 DUST COVER
6 650113-3 SWITCH SGEL 115CDY-15
7 421459-2 COVER ANTIPOLV.4101RH
8 687169-3 CLAMP cable tie HP1620
9 266192-7 SCREW 4 X 14 X HR4001C / HR4010C
10 682573-1 CABLE 10 X GA9010C
12 413076-2 VANE X GD0800C
13 259039-2 LOCKING 6 X 9566CV
14 688117-5 SOCKET X GD0800C
15 267756-0 WAVY WASHER X BO6040
16 421738-8 RING LABYRINTH 22 X 9561CV
17 626678-7 STATOR
18 417237-6 COVER INSULATION X GD0800C
19 344871-8 RETAINING X GD0800C
20 266258-3 SCREW 4 X 70 X 9564
21 210027-4 BEARING 627DDW X 9561CV
22 253823-7 ROND. FLAT 7 X JS1600
23 681656-4 INSULATING WASHER X GD0810C
24 515208-8 ARMATURE X 9566CV
25 240033-5 FAN 57 X 9561CV
26 253084-9 ROND.P.12 8419B / 5016NB
27 317359-1 COVER BOX INPUT. X 9561
28 210105-0 BEARING 6001LLU X PW5000CH
29 961052-5 RETAINING RING S12
30 233901-9 STOP RING 12 X GD0800C
31 253052-2 WASHER 12
32 227429-7 GEAR X 9566CV
33 253077-6 ROND.P. 6 4300 / 01BV
34 961002-0 RETAINING RING S6
36 452942-8 COVER SWITCH
38 455385-3 HOUSING MOTOR
39 643760-7 BRUSH X BO6040
40 266256-7 SCREW 3 X 10 X GD0800C
41 191978-9 CARBON BRUSHES CB 318 (EX 310)
42 455386-1 MOTOR COVER
44 620336-7 REGULATOR
46 266256-7 SCREW 3 X 10 X GD0800C
50 224577-3 FLANGE 14-45 X SG1250 / 2
51 331661-8 DISTANCE 3 X SG1250 / 2
52 331662-6 DISTANCE 6 X SG1250 / 2
53 257732-2 SOCKET 14 X SG1250 / 2
54 224415-9 INTERNAL FLANGE 42 GA95010
55 324393-4 POST X SG1250 / 2
56 415300-9 DISTANCE X 9541
57 265490-6 SCREW M4 X 16 X 9561CV
58 318302-3 BEARING BOX X 9566CV
59 213673-2 RING 52 X 9561CV
60 211129-9 BALL BEARING NSK 6201DD
61 285841-7 RETAINING BEARING X 9566CV
62 227430-2 GEAR 35 X 9566CV
63 256459-1 PIN X 9561CV
64 213048-5 RING 6 X 9561CV
65 153488-4 RECEIVER INPUT. CPL FOR SG1250
66 233072-2 SPRING COMPRESSION 8 X 9541
67 418067-8 PLUG PLUG FOR SG1250
68 266257-5 SCREW M4 X 28 X 9561CV
69 961011-9 RETAINING RING E4
70 257227-5 RING 6 X SG1250 / 2
71 961014-3 RETAINING RING E-8
72 153685-2 CAP BLADE X SG1250 / 2
73 324392-6 PIN X SG1250 / 2
74 231655-2 SPRING TWIST 11 X SG1250 / 2
75 266040-0 SCREW 4X25 CT
76 418390-1 PARA POWDER X SG1250 / 2
78 416741-2 JOINT VACUUM X X SG1250 / 2
79 213423-5 SEAL X 2702
80 317725-2 HEADPHONES DISCO
81 922466-3 SCREW M8x45 X SG1250 / 2
82 961006-2 RETAINING RING S10
84 317723-6 BASE X CAP BLADE SG1250 / 2
85 922487-5 SCREW M8x65 X SG1250 / 2
86 941201-0 FLAT WASHER 8
87 223145-9 FRONT-HOLDER HANDLE
88 417665-5 FRONT HANDLE SG1250 / 2
90 252185-0 PANEL NUT M6 X SG1250 / 2
91 344391-2 RETAINING X 6213 / 6203DW
92 922251-4 SCREW X KP312S
93 941201-0 FLAT WASHER 8
94 922462-1 SCREW M8X40 X SG1250 / 2
95 345364-8 INDICATOR X SG1250 / 2
96 942151-2 WASHER 6 4101R
97 257731-4 SOCKET 7 X SG1250 / 2
98 251897-2 SCREW M6 X 33 X SG1250 / 2
99 253310-6 WASHER 10 56DW / HR3850B
100 267783-7 WASHER 10 X SG1250 / 2
101 253310-6 WASHER 10 56DW / HR3850B
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
