Makita Spare Parts for Rotary Hammer HR2630T
€19.64
Tax included
Makita Spare Parts for Rotary Hammer HR2630T
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Rotary Hammer HR2630T.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Rotary Hammer HR2630T
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Rotary Hammer HR2630T.In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| HR2630T - ROTARY HAMMER SDS+800W | ||
| # | Part Num. | Description |
| 8 | 122878-2 | GRIP ASSEMBLY HR2601 |
| 9 | 346181-9 | GRIP SPRING 50 HR2300/2600/260 HR2601 |
| 10 | 266349-0 | SQUARE BOLT M8 6319/6339/6349 HR2601 |
| 11 | 451539-0 | GRIP BASE HR2300/26/2611F HR2601 |
| 13 | 141765-6 | LOCK BUTTON CO HR2300/26/2611F HR2630T |
| 14 | 233360-7 | COMPRESSION SPRING 4 MT952 |
| 15 | 154935-8 | GRIP 36 COMPLETE HR2601 |
| 16 | 142971-6 | GEAR HOUSING COMPLETE |
| 17 | 331890-3 | CUP SLEEVE HR2300/26/2611F HR2601 |
| 18 | 211294-4 | BALL BEARING 6806LLU HR2300 HR2601 |
| 19 | 232286-0 | LEAF SPRING HR2630T |
| 20 | 346833-2 | CHANGE PLATE B X HR2630T |
| 21 | 346832-4 | CHANGE PLATE A X HR2630T |
| 22 | 213278-8 | O RING 13 BHR262/HR2020/2440 HR2020 |
| 23 | 455392-6 | CHANGE LEVER HR2630T |
| 24 | 455394-2 | CHANGE LEVER CAP HR2630T |
| 25 | 455391-8 | CHANGE LEVER COVER HR2630T |
| 27 | 216019-1 | STEEL BALL 3 DHR24 * / HR26 ** |
| 28 | 140266-1 | TOOL HOLDER GUIDE CO HR2601/FT HR2611FT |
| 29 | 332139-4 | DRIVING FLANGE HR2601 |
| 30 | 227360-7 | SPUR GEAR 51 HR2601 |
| 33 | 234148-8 | COMPRESSION SPRING 31 HR2300 HR2601 |
| 34 | 267153-0 | FLAT WASHER 30 HR2300/2601/260 HR2601 |
| 35 | 257932-4 | SPIRO LOCK WASHER 30 HR2300-11 HR2601 |
| 36 | 267153-0 | FLAT WASHER 30 HR2300/2601/260 HR2601 |
| 37 | 325783-4 | SLEEVE 9B HR2601/2610T/2611FT HR2601 |
| 38 | 325791-5 | IMPACT BOLT B HR2601T/HR2611FT |
| 39 | 325795-7 | RING 10B |
| 40 | 424267-0 | CUSHION RING 12 HR2601/10/T |
| 41 | 325798-1 | O RING CASE A HR2601/10/2610T MT870 |
| 42 | 213073-6 | O RING 9 HR2020/2440/2450/2432 HR2020 |
| 43 | 233979-2 | RING SPRING 28 HR23/2600/HR2601 |
| 44 | 325784-2 | STRIKER HR2300/26/2611F HR2601 |
| 45 | 213258-4 | O RING 17.5 HR2210 / 20 |
| 46 | 310345-1 | PISTON CYLINDER HR2300/26/2611 HR2601 |
| 47 | 346036-8 | GUIDE PLATE BHR261/262/BHR262T BHR261D |
| 48 | 324215-8 | PISTON JOINT HR2020/2440/2450 |
| 49 | 234098-7 | COMPRESSION SPRING 14 BHR261/2 BHR261D |
| 50 | 210137-7 | BALL BEARING 606ZZ |
| 51 | 257336-0 | STOP RING EXT U-6 |
| 52 | 253186-1 | THIN WASHER 7 HR160D 420S |
| 53 | 233360-7 | COMPRESSION SPRING 4 MT952 |
| 54 | 346831-6 | LOCK PLATE HR2630T |
| 55 | 326448-1 | CAM SHAFT HR2630T |
| 56 | 227359-2 | SPUR GEAR 10 HR2630T |
| 57 | 332125-5 | CLUTCH CAM HR2630T |
| 58 | 219014-0 | SWASH BEARING 10 BHR200S/HR2020 |
| 59 | 257321-3 | RING 8 MT870 |
| 60 | 310344-3 | BEARING BOX HR2601 |
| 61 | 211032-4 | BALL BEARING 608ZZCNM/2A BUR18 1902 |
| 62 | 266437-3 | HEX SOCKET BOLT M4x16 HR4001C |
| 63 | 285735-6 | BEARING RETAINER HR23/26/2611F HR2601 |
| 64 | 227719-8 | HELICAL GEAR 26 HR23/26/2611F HR2601 |
| 65 | 213728-3 | O RING 68 BHR261/2 BHR261D |
| 69 | 141572-7 | INNER HOUSING CO HR2601/10/T HR2300 |
| 70 | 213407-3 | O RING 26 3901/4101RH 3901 |
| 71 | 213678-2 | OIL SEAL 12 MT870/HR2601 |
| 72 | 262569-4 | SLEEVE 9 HR2300/26/2611F HR2601 |
| 73 | 211097-6 | BALL BEARING 6000LLB HIGH SPEE 5604R |
| 74 | 961006-2 | EXT DIN 471 CIRCLIP-10 |
| 75 | 240121-8 | FAN65 HR23/26/2601/2610/2611FT |
| 76 | 515359-7 | ARMATURE ASSY 240V HR26/2610 |
| 77 | 681670-0 | INSULATING WASHER |
| 78 | 210023-2 | BALL BEARING 627DDW BHS630 9910/11 |
| 79 | 267804-5 | WAVE WASHER 15 HR2230/2460/247 |
| 83 | 266361-0 | R.H SQUARE NECK BOLT M8 9554NB |
| 84 | 451527-7 | BAFFLE PLATE HR2300/26/2611F |
| 85 | 626634-7 | FIELD 240V HR2600/2610T/2611FT |
| 86 | 451536-6 | MOTOR HOUSING HR2601/10/2610T |
| 89 | 194074-2 | CARBON BRUSH SET CB-325 X 9554NB |
| 90 | 638655-7 | BRUSH HOLDER UNIT HR2300-2611F HR2601 |
| 91 | 266556-5 | TAPPING SCREW M3X12 HR2300-261 HR26001 |
| 92 | 266361-0 | R.H SQUARE NECK BOLT M8 9554NB |
| 95 | 682566-8 | CORD GUARD 10 TD0101F/2450 HR2450 |
| 97 | 651090-2 | SWITCH TG853TB-3 |
| 99 | 687682-1 | STRAIN RELIEF GA4034/4534/5034 JS1000 |
| 100 | 266385-6 | TAPPING SCREW 4X14 GA9020S GA9020 |
| 101 | 266326-2 | TAPPING SCREW M4X18 BHR2 MT601 |
| 102 | 451528-5 | HANDLE COVER HR2300/26/2611F HR2601 |
| 103 | 266326-2 | TAPPING SCREW M4X18 BHR2 MT601 |
| 104 | 194080-7 | SDS Chuck BHR243 HR2450 HR2470 HR2811 HR2611 |
| 105 | 286263-4 | CAP 35 BHR262/HR2020/2440/2450 |
| 106 | 233940-9 | RING SPRING 19 BHR262/HR2020 HR2432 |
| 107 | 418217-5 | CHUCK COVER HR2450T/HR2610T/11 HR2450FT |
| 108 | 345333-9 | STOPPER HR2450T/2601/2611FT/BH HR2450FT |
| 109 | 216022-2 | STEEL BALL 7.0 |
| 110 | 345187-4 | GUIDE WASHER BHR262/HR2020/244 |
| 111 | 233916-6 | CONICAL COMP SPRING 21-29 HR2020 |
| 112 | 267279-8 | FLAT WASHER 21 X HR2450FT |
| 113 | 324355-2 | TOOL HOLDER HR2450T/HR2610/FT |
| 114 | 216013-3 | STEEL BALL 6 BHR262T/BHR |
| 115 | 231669-1 | TORSION SPRING HR2450T/HR2811 HR2450FT |
| 116 | 345334-7 | CHANGE RING X HR2450FT |
| 117 | 418218-3 | CHANGE COVER HR2450T/HR2811FT HR2450FT |
| 118 | 216018-3 | STEEL BALL 5.0 BHR262T/B HP2030 |
| 119 | 345335-5 | LEAF SPRING HR2450T/HR2811FT/ HR2450FT |
| 120 | 267270-6 | FLAT WASHER 24 HR2450T/HR2811 HR2450FT |
| 121 | 233924-7 | RING SPRING 21 HR2450T/HR2811 HR2450FT |
| 122 | 267447-3 | FLAT WASHER 14 HR2300/2601/260 HR2601 |
| 123 | 234343-0 | COMPRESSION SPRING 5 HR2630T |
| 999 | 195105-0 | SERVICE KIT HR2300 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s MAKITA websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to MAKITA brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
