Makita Spare Parts for 260MM Table Saw 2704

Name: Makita Spare Parts for 260MM Table Saw 2704
Brand: Makita
SKU: Makita 2704
Price: 88.85 EUR
Availability: InStock

€88.85

Tax included

Makita Spare Parts for 260MM Table Saw 2704

We supply original MAKITA spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Contractors 15 Amp 10-Inch Benchtop Table Saw 2704.

- Dima side for precision cutting

ITEM CODE: 122734-6

154595-6
154599-8
154602-5
154603-3
154699-4
154705-5
211051-0
211088-7
211228-7
211490-4
213107-5
214114-1
224347-0
224401-0
226602-6
226747-0
231025-5
231297-2
231315-6
231485-1
231683-7
232174-1
233229-5
240003-4
251308-7
251382-5
252014-7
252130-5
252155-9
252197-3
252650-9
253010-8
253024-7
253052-2
253143-9
253147-1
253186-1
253198-4
253731-2
253758-2
253797-2
253874-0
256029-6
256200-2
256262-0
256769-6
257161-9
257262-3
257752-6
257753-4
261129-9
262559-7
265045-7
265154-2
265155-0
265160-7
265382-9
265460-5
265536-8
265537-6
265740-9
265768-7
265995-6
266020-6
266029-8
266034-5
266035-3
266040-0
266061-2
266192-7
266264-8
266300-0
266364-4
266378-3
266492-5
267010-2
267170-0
267305-3
268135-5
271073-2
271074-0
271318-8
271320-1
271423-1
272248-6
273523-3
273524-1
286212-1
313123-8
316933-2
317010-3
317864-8
317865-6
317867-2
317868-0
317869-8
317871-1
317872-9
317874-5
317875-3
317876-1
317877-9
317879-5
317895-7
317897-3
318253-0
322967-5
322968-3
323736-7
324530-0
324554-6
324555-4
324556-2
324557-0
324558-8
324559-6
324560-1
324562-7
324563-5
324564-3
344529-9
344536-2
344543-5
345520-0
345521-8
345522-6
345523-4
345525-0
345529-2
345530-7
345533-1
345534-9
345535-7
345536-5
345537-3
345539-9
345559-3
345560-8
345561-6
345562-4
345563-2
345564-0
345565-8
345566-6
345583-6
345628-0
413097-4
416331-1
416332-9
416333-7
416339-5
416340-0
416341-8
416439-1
418616-1
418617-9
418618-7
418655-1
418907-0
418908-8
418910-1
418912-7
418915-1
418917-7
418918-5
418943-6
418944-4
418945-2
418946-0
418947-8
418948-6
419219-4
421926-7
443103-1
510071-4
599511-5
631613-2
643650-4
645006-7
646049-2
652772-9
654561-8
681640-9
682511-3
682516-3
687049-3
687052-4
687054-0
816844-6
817283-3
911108-4
911114-9
911118-1
911128-8
911133-5
911213-7
911223-4
911233-1
911238-1
911253-5
911323-0
911333-7
911344-2
911383-2
911536-3
921331-3
921342-8
921462-8
922103-9
922116-0
922126-7
922146-1
922232-8
922333-2
922334-0
931102-0
931302-2
931402-8
931502-4
941051-3
941151-9
941251-5
941302-4
951104-0
951116-3
961015-1
961016-9
181044-0
122734-6
122738-8
122739-6
125279-3

Quantity

Usually Ships in: 7/10 Business Days Approx.

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Makita Spare Parts for 260MM Table Saw 2704

Table Saw Makita 2704 Pag.1
#	Part Num.	Description
1	122738-8	PROTECTION FOR 2704
2	268135-5	PIN 10 PER 2704
3	253758-2	FLAT WASHER 10
4	418910-1	BOTTOM COVER FOR 2704
5	418915-1	COVER FOR 2704
6	817283-3	LABEL SECURITY FOR 2704
7	253758-2	FLAT WASHER 10
8	961015-1	RING RETAINING E9 6221DW
9	252014-7	NUT M6-10
10	253010-8	FLAT WASHER 6
11	257752-6	SLEEVE 8 PER 2704
12	257752-6	SLEEVE 8 PER 2704
13	253731-2	FLAT WASHER 8 X 6300-4
14	324554-6	LOCK SHAFT 2704
15	345583-6	LOCK LEVER 2704
16	951104-0	TENSION PIN 4-12 PER 2704
24	345530-7	RIVING KNIFE FOR 2704
29	265995-6	SCREW M4X18 X 6408 / 6221DW
30	416341-8	COVER X 2702
31	265995-6	SCREW M4X18 X 6408 / 6221DW
32	687054-0	STRAIN RELIEFE HM1500
33	154602-5	MOTOR HOUSING 2704
34	181044-0	CARBON BRUSH SET CB-153 (150/52/54)
35	643650-4	BRUSH HOLDER CAP
36	911383-2	SCREW M6 X60 X 2702
37	266029-8	SCREW M5X65
38	599511-5	FIELD 220/240 X 2702
39	416331-1	BAFFLE PLATE 2702
40	211228-7	BALL BEARING 6202DD
41	253147-1	THIN WASHER15 X LF1000
42	510071-4	ARMATURE ASSY 2704
43	681640-9	INSULATION WSHER 2702
44	211088-7	BALL BEARING 6000-9527PB 9528PB
45	253198-4	FLAT WASHER 18 XJS3200
46	261129-9	URETHANE WASHER 18 PER 2704
48	921331-3	SCREW M6 X 20 FOR 2704
49	345525-0	PRESSURE PLATE 2704
50	317871-1	KNIFE HOLDER 2704
53	922334-0	SCREW M6 X 20 FOR 2704
54	344536-2	GEAR HOUSING PLATE 2702
55	911213-7	SCREW M5X12 X 5143R
56	154603-3	GEAR HOUSING 2704
57	323736-7	GUIDE BAR 2702
58	266040-0	SCREW 4X25 CT
59	416340-0	GUIDE BAR RETAINER 2702
60	266040-0	SCREW 4X25 CT
61	416340-0	GUIDE BAR RETAINER 2702
62	323736-7	GUIDE BAR 2702
63	211051-0	BALL BEARING 609 2RS
64	154595-6	SPINDLE CPL 2704
65	226602-6	GEAR 42 PER 2704
66	267170-0	WASHER 34 X 2702
67	211490-4	BALL BEARING 6203LLU X SG150-2
68	324556-2	SPINDLE 2704
69	316933-2	BEARING BOX 2702
70	911233-1	PAN HD SCREW M5X20 3600H
71	931502-4	HEX FULL NUT M10
72	266040-0	SCREW 4X25 CT
73	322968-3	SCREW BAR X 2702
74	961016-9	EXT E-RING JIS JE-10/BHR
75	416339-5	SCREW BAR RETAINER 2702
76	941302-4	WASHER 12 X 2702
77	226747-0	GEAR 2702
78	951116-3	PIN 4-20
79	226747-0	GEAR 2702
80	941302-4	WASHER 12 X 2702
81	951116-3	PIN 4-20
82	324562-7	LOCK LEVER CONNECTOR 2704
83	253024-7	WASHER 10 X LS1013
84	231315-6	PRESSION SPRING 14 X 6710DW
85	322967-5	LOCK LEVER SHAFT 2702
86	922232-8	SCREW M5X20
87	272248-6	LEVER 120 PER 2704
88	324563-5	HANDLE SHAFT 2704
89	266034-5	SCREW 4X16 CT
90	253143-9	WASHER 12 X 2702
91	213107-5	O-RING 12 JR3000 / V
92	253052-2	WASHER 12
93	214114-1	PLAIN BEARING 12 X 6410
94	345520-0	LEVER 2704
95	344543-5	POINTER 2702
96	922103-9	BOLT M4 X 6 X 2702
97	271074-0	ARM 60 PER 2704
98	911223-4	PAN HEAD SCREW M5X16
99	251382-5	SCREW M5 FOR 2704
100	271423-1	KNOB 32 PER 2704
101	267010-2	FLAT WASHER 5 XJS1650
102	240003-4	FAN X 2702
103	271073-2	HANDLE 100 2704
104	224347-0	OUTER FLANGE X 2702
105	252155-9	HEX NUT M12-19 X 2702
106	224401-0	INNER FLANGE 53 PER 2704
310	257262-3	RING 16 X LH1040F
107	273523-3	KNOB 2704
108	345534-9	HANDLE PLATE 2704
109	257161-9	RING 4 PER 2704
110	941051-3	FLAT WASHER 4
111	922116-0	SCREW M4X12 FOR 2704
112	252130-5	NUT M10-17 X 2414B
113	941251-5	FLAT WASHER 10
114	911223-4	PAN HEAD SCREW M5X16
115	345539-9	HANDLE PLATE HOLDER 2704
116	345534-9	HANDLE PLATE 2704
117	257161-9	RING 4 PER 2704
118	941051-3	FLAT WASHER 4
119	922116-0	SCREW M4X12 FOR 2704
120	257753-4	SLEEVE 10 PER 2704
121	265536-8	SCREW M16x65 2704
122	273523-3	KNOB 2704
123	265382-9	SCREW M5 X 20 FOR 2704
124	324559-6	HOOK RING 2704
125	233229-5	COMPRESSION SPRING 8 PER 2704
126	418655-1	ROD HOLDER 8 X LS0714FL
127	418655-1	ROD HOLDER 8 X LS0714FL
128	345535-7	JOIN PLATE 2704
130	922116-0	SCREW M4X12 FOR 2704
131	922116-0	SCREW M4X12 FOR 2704
132	941051-3	FLAT WASHER 4
133	257161-9	RING 4 PER 2704
134	324560-1	ROD JOINTR 2704
135	324557-0	AUCTION BACK FOR 2704
136	324558-8	ROD 2704
137	911128-8	SCREW M4x16 X HR4000C
138	911128-8	SCREW M4x16 X HR4000C
140	922116-0	SCREW M4X12 FOR 2704
141	922116-0	SCREW M4X12 FOR 2704
142	941051-3	FLAT WASHER 4
143	257161-9	RING 4 PER 2704
144	324560-1	ROD JOINT 2704
145	911128-8	SCREW M4x16 X HR4000C
146	418655-1	ROD HOLDER 8 X LS0714FL
147	911323-0	SCREW M6X16 X LS1013
148	687049-3	CLAMP X 2702
149	251308-7	SCREW M4X10 X 2702
151	345628-0	PLATE 2704
152	416333-7	RACK PLATE 2702
153	911213-7	SCREW M5X12 X 5143R
154	418655-1	ROD HOLDER 8 X LS0714FL
155	233229-5	COMPRESSION SPRING 8 PER 2704
156	324559-6	RING 2704
157	265382-9	SCREW M5 X 20 FOR 2704
158	911128-8	SCREW M4x16 X HR4000C
159	317010-3	ADJUST BLOCK 2702
160	344529-9	SLIDE SEAT 2702
161	232174-1	LEAF SPRING 2702
162	345535-7	DUST FLANGE 2704
163	416439-1	GUIDE 2702
164	266034-5	SCREW 4X16 CT
165	318253-0	FRAME 2704
166	418917-7	DUST JOINT 2704
167	266061-2	SCREW M4 X 8 JN1601
168	154599-8	FRAME COVER 2704
169	911114-9	SCREW M4 X 10
170	911333-7	SCREW M6 X 20 X 2702
171	416332-9	FRAME RETAINER 2702
172	265460-5	BOLT M6 X 20 X 2702
174	266300-0	SCREW 4 X 18 X LS1040F
175	413097-4	SLIDE COVER FOR 2704
176	266035-3	SCREW M5 X 12 9031
177	418918-5	SWITCH BOX 2704
178	682511-3	RING X LF1000
179	265995-6	SCREW M4X18 X 6408 / 6221DW
Bench Saw Makita 2704 Pag.2
180	687054-0	CLAMP Cable tie X HM1500
181	418912-7	SWITCH SUPPORT FOR 2704
183	265995-6	SCREW M4X18 X 6408 / 6221DW
184	682511-3	RING X LF1000
185	265995-6	SCREW M4X18 X 6408 / 6221DW
186	687052-4	CLAMP Cable tie X 6408
190	266192-7	SCREW 4 X 14 X HR4001C / HR4010C
312	345536-5	COVER FRAME FOR 2704
313	266020-6	SCREW M4 X 12
314	418618-7	SPINA X LH1040F
315	418618-7	SPINA X LH1040F
316	418616-1	BUTTON ON X LH1040F
317	443103-1	FELT RING 6 X LH1040F
318	443103-1	FELT RING 6 X LH1040F
319	231025-5	SPRING COMPRES.8 X 8411DW
320	231025-5	SPRING COMPRES.8 X 8411DW
321	253186-1	PLAIN WASHER 7 X 420S
322	253186-1	PLAIN WASHER 7 X 420S
323	418617-9	KEY OFF X LH1040F
324	652772-9	RELAY 305.232.01 X LH1040F
325	631613-2	STARTING CIRCUIT X LH1040F
326	654561-8	CLAMP X LH1040F
327	645006-7	NOISE SUPPRESSOR X LS1013
328	645006-7	NOISE SUPPRESSOR X LS1013
329	646049-2	Diode X JR3000VT
191	816844-6	GRADUATED PLATE FOR 2704
192	251308-7	SCREW M4X10 X 2702
193	911253-5	SCREW M 5 X 30 X JR3030T
194	418908-8	INSIDE COVER FOR 2704
195	922146-1	BOLT ESAG.M4X25X4602DW
196	154705-5	TRACK FRONT. ESTER. FOR 2704
199	317877-9	LOWER TABLE FOR 2704
200	317876-1	TABLE FOR 2704
201	922126-7	SCREW M4x16 HR5000K / 3850B
202	317868-0	TRACK FRONT. INTER. FOR 2704
203	911233-1	HEAD SCREW M5X20 3600H
206	418907-0	EXTERNAL COVER FOR 2704
207	265045-7	SCREW M 5 X 18 FOR 2704
208	126901-5	ex 125279-3 COVER FOR 2704
211	317875-3	COVER AREA CUTTING FOR 2704
212	266264-8	SCREW M5 X 6 X BSR730
214	418907-0	EXTERNAL COVER FOR 2704
215	911233-1	HEAD SCREW M5X20 3600H
216	317867-2	RAIL POST. OUTSIDE FOR 2704
217	345529-2	PLATE FOR TRACK FOR 2704
218	251308-7	SCREW M4X10 X 2702
220	922126-7	SCREW M4x16 HR5000K / 3850B
221	317869-8	RAIL POST. OUTSIDE FOR 2704
222	345533-1	FRONT COVER FOR 2704
223	266020-6	SCREW M4 X 12
225	911253-5	SCREW M 5 X 30 X JR3030T
226	922146-1	BOLT ESAG.M4X25X4602DW
227	418908-8	INSIDE COVER FOR 2704
228	286212-1	HOOD 20 X LS1013
229	154608-3	BASE FOR 2704
230	265995-6	SCREW M4X18 X 6408 / 6221DW
231	687052-4	CLAMP Cable tie X 6408
232	682516-3	CABLE SLEEVE 9.3-85
234	931302-2	NUT M6 HR4000C
235	271318-8	KNOB 37 PER 2704
236	941151-9	WASHER 6 X HM1303
237	921342-8	HEXAGON BOLT 6X25
238	271320-1	KNOB 37 PER 2704
239	252197-3	NUT M14 FOR 2704
240	421926-7	SUPPORT FOR 2704
241	931402-8	NUT M8 X LS1013
242	253797-2	WASHER P.14 X HR2210 / 20
243	265537-6	SCREW M14X65 FOR 2704
244	921462-8	BOLT M8 X 40 9031
246	911344-2	SCREW M6 X 25 X 2702
311	262559-7	COMPASS 14 PER 2704
337	911233-1	HEAD SCREW M5X20 3600H
247	317865-6	REG PLATE. CORNER FOR 2704
248	266364-4	SCREW M8x35 FOR 2704
249	345522-6	GUIDE ANGLE FOR 2704
250	256769-6	PIN 6 PER 2704
251	317872-9	TRACK X TAGLIANGOL. FOR 2704
252	266378-3	SCREW M5x5 FOR 2704
253	345523-4	LIMIT FOR 2704
254	324530-0	The PIN FOR 2704
255	911536-3	SCREW M4x20
256	931102-0	HEX NUT M4
257	252650-9	NUT M 8 PER 2704
258	273524-1	HANDLE 28 PER 2704
259	922333-2	SCREW M6 X 20 FOR 2704
260	317897-3	REGOLO FOR 2704
261	345521-8	REGOLO GUIDE FOR 2704
262	317864-8	ADAPTER X REGOLO FOR 2704
263	911108-4	SCREW M4X8 X 5103R
264	418945-2	LENS FOR 2704
265	418943-6	COPERC. X SUPP.REGOLO FOR 2704
266	317895-7	REGOLO SUPPORT FOR 2704
267	265768-7	SCREW M6X52 FOR 2704
268	418948-6	COPERC.X SUPP. GUIDE 2704
269	266492-5	SCREW M4X25-9527PB 9528PB
270	231485-1	SPRING 4 X N500
271	418947-8	MEDIA GUIDE 2704
272	231485-1	SPRING 4 X N500
273	345560-8	PLATE FRAME 2704
274	265155-0	SCREW M5X25 FOR 2704
275	418946-0	LEVER FOR 2704
276	231297-2	SPRING 9 X LS1030
277	418944-4	LOCK LEVER FOR 2704
278	253874-0	FLAT WASHER 4
279	266020-6	SCREW M4 X 12
280	911133-5	SCREW M4X18
281	911238-1	SCREW M5X22 FOR 2704
282	345566-6	CAM FOR 2704
283	345559-3	CAM SUPPORT FOR 2704
284	256029-6	PIN 8 X HR3850 / B
285	256200-2	PIN 5 PER 2704
286	911118-1	SCREW M4X12
287	345564-0	SUPP. X PIAST.BLOC. FOR 2704
288	256200-2	PIN 5 PER 2704
289	345565-8	HOOK CAM FOR 2704
290	265154-2	AUCTION M5X655 FOR 2704
291	324555-4	NUT M 5 PER 2704
292	256262-0	PIN M5 FOR 2704
293	345562-4	JOINT 2704
294	256262-0	PIN M5 FOR 2704
295	231683-7	SPRING TWIST 8 PER 2704
296	313123-8	KEY FOR SLIDE RULE FOR 2704
297	345563-2	REGOLO GUIDE FOR 2704
298	911118-1	SCREW M4X12
299	911118-1	SCREW M4X12
300	345561-6	SUPPORT FOR SLIDE RULE FOR 2704
301	256262-0	PIN M5 FOR 2704
302	154699-4	STOP X REGOLO FOR 2704
303	317874-5	GONIOMETER FOR 2704
304	122734-6	GONIOMETER CPL FOR 2704
305	122739-6	REGOLO CPL FOR 2704
306	265160-7	SCREW M4X8 FOR 2704
308	267305-3	WASHER 8 PER 2704
309	419219-4	GONIOMETER COVER FOR 2704
330	265740-9	SCREW M 5X 15X RP1100C
331	317879-5	SUPP. AUCTION SLIDING FOR 2704
332	324564-3	AUCTION BACK FOR 2704
333	345537-3	BANK BACK FOR 2704
334	911223-4	HEAD SCREW CILIND. M5X16
335	931502-4	NUT ESAG.M10
336	961016-9	RETAINING RING E1O

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
