Makita Recipro Saw JR3051T Parts
€5.43
Tax included
Makita Spare Parts for Reciprocatng Saw JR3051T
We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3051T.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Reciprocatng Saw JR3051T
We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Reciprocating Saw JR3051T.
In the following table, look for the model of Saw and the respective parts of the code.
| MAKITA JR3051T RECIPRO SAW | ||
| # | Part Num. | Description |
| 1 | 162704-3 | SHOE |
| 2 | 265844-7 | HEX. SOCKET HEAD BOLT M6X20 |
| 3 | 422537-1 | INSULATION COVER |
| 4 | 422223-4 | PROTECTOR |
| 5 | 257430-8 | RETAINING RING(EXT)18 |
| 6 | 310848-5 | DRIVING SLEEVE |
| 7 | 327043-0 | GUIDE SLEEVE |
| 8 | 268094-3 | PIN 3 |
| 9 | 234381-2 | COMPRESSION SPRING 6 |
| 10 | 256569-4 | SHOULDER PIN 5 |
| 11 | 458968-8 | CONNECTING SLEEVE |
| 12 | 310912-2 | PUSH PIN |
| 13 | 232472-3 | COMPRESSION SPRING 2 |
| 14 | 233594-2 | TORSION SPRING 17 |
| 15 | 961018-5 | STOP RING E-5 |
| 16 | 256934-7 | COLLARED PIN 6 |
| 17 | 327441-8 | BLOCK |
| 18 | 911258-5 | PAN HEAD SCREW M5X35 |
| 19 | 911243-8 | PAN HEAD SCREW M5X25 |
| 20 | 140R13-8 | GEAR HOUSING COVER COMPLE TE |
| C10 | 213174-0 | X RING 14 |
| 21 | 214169-6 | PLANE BEARING 14 |
| 22 | 347596-3 | SLIDE PLATE |
| 23 | 911225-0 | PAN HEAD SCREW M5X16 |
| 23-1 | 265C32-4 | P.H.SCREW M5X16 WITH WM |
| 24 | 162705-1 | SLIDER |
| 25 | 341462-6 | PLATE |
| 26 | 136188-1 | GEAR HOUSING COVER ASS'Y |
| 26 | INC. 4-17,20-25 | |
| 26-1 | 136962-7 | GEAR HOUSING COVER ASS'Y |
| 26-1 | INC. 4-17,20-25 | |
| 27 | 422538-9 | SEAL RING |
| 28 | 911225-0 | PAN HEAD SCREW M5X16 |
| 28-1 | 265C32-4 | P.H.SCREW M5X16 WITH WM |
| 29 | 911225-0 | PAN HEAD SCREW M5X16 |
| 29-1 | 265C32-4 | P.H.SCREW M5X16 WITH WM |
| 30 | 347597-1 | GEAR PLATE A |
| 31 | 346715-8 | GEAR PLATE |
| 32 | 212959-1 | NEEDLE BEARING 708 |
| 33 | 140R15-4 | GEAR COMPLETE |
| 34 | 267290-0 | FLAT WASHER 18 |
| 35 | 266459-3 | TAPPING SCREW 5X25 |
| 35-1 | 265D56-6 | TAPPING SCREW 5X25 |
| 36 | 140R12-0 | GEAR HOUSING COMPLETE |
| 37 | 961052-5 | RETAINING RING (EXT) S-12 |
| 38 | 211131-2 | BALL BEARING 6001DDW |
| 38-1 | 210105-0 | BALL BEARING 6001LLU |
| 39 | 285036-2 | BEARING RETAINER 80 |
| 40 | 265353-6 | HEX. SOCKET HEAD BOLT M4X12 |
| 41 | 511A03-0 | ARMATURE ASS'Y 220-240V |
| 41 | INC. 37-39,42,43,66 | |
| 42 | 681644-1 | INSULATION WASHER |
| 43 | 210029-0 | BALL BEARING 608ZZ |
| 44 | 459919-4 | BAFFLE PLATE |
| 45 | 266056-5 | TAPPING SCREW 5X45 |
| 46 | 521894-5 | FIELD ASS'Y 240V |
| C10 | 654020-2 | RING TERMINAL |
| C20 | 654501-6 | CONNECTOR P-1.25 |
| 49 | 459920-9 | HOOK COVER |
| 50 | 191963-2 | CARBON BRUSH CB-303 |
| 50-1 | 194996-6 | CARBON BRUSH SET CB-303 |
| 51 | 140R14-6 | MOTOR HOUSING COMPLETE |
| C10 | 644501-4 | BRUSH HOLDER 5X11 |
| 52 | 266326-2 | TAPPING SCREW 4X18 |
| 52-1 | 265B67-9 | TAPPING SCREW 4X18 |
| 53 | 183N40-8 | HANDLE SET |
| 53 | INC. 60 | |
| 53-1 | 183N41-6 | HANDLE SET |
| 53-1 | INC. 60 | |
| 54 | 651374-8 | SWITCH C3VT-2L-C-H50 |
| 54-1 | 650068-2 | SWITCH C3VT-2-C-H50 |
| 55 | 643750-0 | BRUSH HOLDER CAP 7-11 |
| 56 | 266326-2 | TAPPING SCREW 4X18 |
| 56-1 | 265B67-9 | TAPPING SCREW 4X18 |
| 57 | 687124-5 | STRAIN RELIEF |
| 58 | 682574-9 | CORD GUARD 10-90 |
| 59 | 665890-4 | POWER SUPPLY CORD 1.0-2-4.0 |
| 60 | 183N40-8 | HANDLE SET |
| 60 | INC. 53 | |
| 60-1 | 183N41-6 | HANDLE SET |
| 60-1 | INC. 53 | |
| 61 | 856M49-4 | JR3051T NAME PLATE |
| 62 | 807G78-4 | CLEAR LABEL |
| 63 | 856M54-1 | JR3051T SERIAL NO. LABEL |
| 64 | 8010T0-1 | CLEAR LABEL |
| 65 | 688165-4 | LINE FILTER |
| 66 | 241863-7 | FAN 70 |
| 67 | 253804-1 | FLAT WASHER 6 |
| A02 | 821795-0 | PLASTIC CASE |
| C10 | 162315-4 | LATCH |
| A03 | 8007C1-9 | JR3051TK MODEL NO. LABEL |
| A04 | B-05038 | RECIPRO SAW BLADE FOR METAL |
| A05 | B-05044 | RECIPRO SAW BLADE FOR PLYW OOD |
| A06 | B-05153 | RECIPRO SAW BLADE FOR WOO D |
