Makita Spare Parts for Angle Drill DA3010F
€1.43
Tax included
Makita Spare Parts for Angle Drill DA3010F
We have the original MAKITA parts and tool repair help you need to get your tools running like new again.Fix Your Angle Drill DA3010F. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Angle Drill DA3010F
We have the original MAKITA parts and tool repair help you need to get your tools running like new again.
Fix Your Angle Drill DA3010F. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Drill and the respective parts of the code.
| DA3010F - ANGLE DRILL 10MM with LED | ||
| # | Part Num. | Description |
| 1 | 266048-4 | T. SCREW 4X40, BO4556 |
| 2 | 317635-3 | GEAR HOUSING, DA3010F |
| 3 | 227436-0 | SPIRAL BEVEL GEAR 9, DA3010F |
| 4 | 210029-0 | BALL BEARING 608ZZ, 5007NK |
| 6 | 226567-2 | HELICAL GEAR 28, DA301F |
| 7 | 210026-6 | BALL BEARING 696ZZ,DA3010F |
| 8 | 418036-9 | GASKET, DA3010F |
| 9 | 418042-4 | GEAR HOUSING COVER, DA3010F |
| 10 | 211051-0 | BALL BEARING 609LLB HR2400 |
| 11 | 240061-0 | FAN 48, DA3010F |
| 12 | 517581-2 | ARMATURE ASS'Y 115V, DA3010F |
| 13 | 681636-0 | INSULATION WASHER, GA4030 |
| 14 | 211021-9 | BALL BEARING 607LLB, HR2475 |
| 15 | 421494-0 | LABYRINTH RUBBER RING,HR2455, DA3010F |
| 16 | 210029-0 | BALL BEARING 608ZZ, 5007NK |
| 17 | 961052-5 | RETAINING RING S-12, LS1016L |
| 18 | 227437-8 | SPIRAL BEVEL GEAR 26, DA3010F |
| 19 | 211419-0 | BALL BEARING 6806DDW, DA3010F |
| 21 | 254201-4 | KEY 4, DA3010F |
| 22 | 763174-5 | DRILL CHUCK S10, DA3010F |
| 23 | 285842-5 | BEARING RETAINER 36-43, DA3010F |
| 25 | 266315-7 | TAPPING SCREW MT4X65, DA3010F |
| 26 | 418033-5 | BAFFLE PLATE, DA3010F |
| 27 | 635076-4 | FIELD, DA3010F |
| 28 | 183560-8 | MOTOR HOUSING,DA3010F |
| 31 | 631516-0 | LED CIRCUIT, DA3010F |
| 32 | 266053-1 | P.T. SCREW 4X35, 4304 |
| 33 | 265995-6 | TAPPING SCREW 4X18, BO4556K |
| 34 | 183559-3 | REAR COVER SET,DA3010F |
| 35 | 643802-7 | BRUSH HOLDER, DA3010F |
| 36 | 687139-2 | SUPPORT, DA3010F |
| 37 | 643801-9 | BRUSH HOLDER, DA3010F |
| 38 | 191962-4 | CARBON BRUSH SET, CB-419 (406,407) 418 |
| 40 | 265995-6 | TAPPING SCREW 4X18, BO4556K |
| 41 | 687063-9 | STRAIN RELIEF, 4323K |
| 42 | 650539-9 | SWITCH,DA3010F |
| 43 | 418038-5 | F/R CHANGE LEVER, DA3010F |
| 44 | 631527-5 | POWER SUPPLY CIRCUIT, DA3010F |
| 45 | 664064-4 | CORD (2X18X8 SJ), BO4556 |
| 47 | 213034-6 | O RING 3, AF502 |
| 48 | 418040-8 | CAM, DA3010F |
| 49 | 153477-9 | SWITCH LEVER CPL., DA3010F |
| 50 | 418037-7 | SPEED CHANGE DIAL, DA3010F |
| 501 | 411780-7 | KEY HOLDER,6402 |
| 502 | 763415-9 | CHUCK KEY, DA301DW |
| 503 | 153489-2 | GRIP 36, 9557NB |
| 504 | 152490-4 | GRIP 36, 9227C |
| 505 | 810134-9 | CAUTION LABEL, 3709 |
