Makita Spare Parts for SDS-Plus Rotary Hammer HR2450F
Fix Your SDS-Plus Rotary Hammer HR2450F. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of jackhammers and the respective parts of the code.
| HR2450F - ROTARY HAMMER 24MM 780W W/LED | ||
| # | Part Num. | Description |
| 1 | 286263-4 | CAP 35 X HR2020 |
| 2 | 233940-9 | RING SPRING 19 FOR HR2432 TECH INFO C.T.89/1 |
| 3 | 417629-9 | CHUCK COVER X HR2020 |
| 4 | 257241-1 | RING 21 X HR2020 |
| 5 | 345187-4 | GUIDE WASHER X HR2020 |
| 6 | 233916-6 | CONICAL COMP. SPRING 21-29 X HR2020 |
| 7 | 921923-8 | HEX. BOLT M 8 X 120 X HR2020 |
| 8 | 417630-4 | GRIP BASE BHR262/HP1641/2450/7 HR2020 |
| 9 | 153503-4 | GRIP X MT811 |
| 10 | 266069-6 | PT SCREW 4X45 HR1840/HR1841F HR2410 |
| 11 | 417794-4 | CAP HR2450/HR2432 HR2450 |
| 12 | 162229-7 | CHANGE LEVER COMP HR2450/2432 |
| 13 | 213278-8 | O-RING 13 X HR2020 |
| 14 | 183441-6 | GEAR HOUSING SET HR2450/HR2432 |
| 15 | 153290-5 | NEEDLE BEARNG CO BHR262/HR2020 |
| 16 | 233918-2 | RING SPRING 28 X HR2020 |
| 17 | 267228-5 | WASHER 30 X HR2020 |
| 18 | 233328-3 | COMPRESSION SPRING 31 X HR2020 |
| 19 | 227028-5 | SPUR GEAR 51 X HR2450 HR2432 |
| 20 | 216022-2 | STEEL BALL 7.0 M3601/M8701 |
| 21 | 153365-0 | TOOL HOLDER COMP HR2450/HR2432 |
| 22 | 267229-3 | FLAT WASHER 28 BHR262/HR2020/2 |
| 23 | 213128-7 | O-RING 12 X HR2020 |
| 24 | 324396-8 | IMPACT BOLT X HR2450 TECH INFO C.T.72/1 |
| 25 | 324218-2 | RING 9 HR2020/2440/2450/2432 |
| 26 | 213232-2 | O RING 15 HR2020/2440/2450/243 |
| 27 | 324216-6 | O RING CASE HR2020 |
| 28 | 213073-6 | O-RING 9 X HR2020 |
| 29 | 233917-4 | RING SPRING 28 X HR2020 |
| 30 | 324214-0 | STRIKER HR2020/2440/2450/2432 |
| 31 | 213227-5 | O-RING 16 X HK0500 |
| 32 | 331632-5 | PISTON CYLINDER HR2450/2432 |
| 33 | 267104-3 | FLAT WASHER 12 X HR2400 |
| 34 | 324215-8 | PISTON JOINT HR2020 |
| 35 | 267104-3 | FLAT WASHER 12 X HR2400 |
| 36 | 211012-0 | BALL BEARING 606ZZ 9524NB |
| 37 | 961003-8 | RETAINING RING S7 |
| 38 | 233343-7 | COMPRESSION SPRING X HR2450 |
| 39 | 331993-3 | CLUTCH X HR2450 |
| 40 | 324248-3 | CLUTCH SHAFT X HR2450 |
| 41 | 219014-0 | SWASH BEARING 10 HR2020 |
| 42 | 226550-9 | HELICAL GEAR 26 HR2020/2440/24 |
| 43 | 266273-7 | HEX S H BOLT M4X12 HR2020/244 |
| 44 | 345179-3 | BEARING RETAINING X HR2020 |
| 45 | 267234-0 | FLAT WASHER 8 X HR2020 |
| 46 | 211032-4 | BALL BEARING 608ZZCNM/2A BUR1 |
| 47 | 324212-4 | RING 8 X HR2020 |
| 48 | 213725-9 | O-RING 68 X HR2020 |
| 49 | 153687-8 | INNER HOUSING X HR2450 |
| 50 | 213380-7 | O RING 24 HR2020/2440/6805B |
| 51 | 210060-6 | BALL BEARING 609LLU HR2430 |
| 52 | 267231-6 | FLAT WASHER 9 X HR2020 |
| 53 | 240047-4 | FAN 60 X HR2020 |
| 54 | 515668-4 | ARMATURE ASSY HR2440 TECH INFO C.T.89/1 |
| 55 | 681636-0 | INSULATION WASHER |
| 56 | 211021-9 | BALL BEARING 607LLB |
| 57 | 266052-3 | SCREW PT 4X60 |
| 58 | 419201-3 | BAFFLE PLATE HR2020 TECH INFO C.T.89/1 |
| 59 | 633488-5 | FIELD 240V HR2440/2450/2432 HR2020 |
| 60 | 417973-4 | MOTOR HOUSING DA3010F-HR2440 |
| 62 | 689111-0 | SPACER HR2020/2440/2450/HP2050 |
| 63 | 643988-7 | BRUSH HOLDER X HR2020 |
| 65 | 191962-4 | CARBON BRUSH SET CB-419 (406,407) 418 |
| 66 | 643989-5 | BRUSH HOLDER X HR2020 |
| 68 | 650508-0 | SWITCH TG813TLB-1 HR2020 |
| 69 | 153284-0 | HANDLE COVER COMP HR2450/2432 HR2020 |
| 70 | 265999-8 | PT SCREW 4X25 VC3211M/BSS500 |
| 71 | 682566-8 | CORD GUARD 10 GD0801C/GD0811C HR2450 |
| 74 | 687124-5 | STRAIN RELIEF HS7100/BO5041 MT953 |
| 75 | 265995-6 | PT SCREW 4X18 UH4570/55/65/55 6408 / 6221DW |
| 76 | 265999-8 | PT SCREW 4X25 VC3211M/BSS500 |
| 77 | 421494-0 | RUBBER RING 19 4305/T/3707/HP2 9521NB |
| 78 | 417795-2 | LOCK BUTTON X HR2450 |
| 79 | 233341-1 | COMPRESSION SPRING X HR2450 |
| 80 | 226399-7 | SPUR GEAR 10 X BHR200 |
| 81 | 265999-8 | PT SCREW 4X25 VC3211M/BSS500 |
| 82 | 345363-0 | CHANGE PLATE X HR2450 |
| 83 | 961017-7 | EXT E-RING JIS JE-3 BPJ140/81 4305T |
| 84 | 417796-0 | GUIDE BASE BHR262/HR2450/HR243 |
| 85 | 233344-5 | COMPRESSION SPRING 4 |
| 86 | 961011-9 | EXT E-RING JIS E-4 EA3201 |
| 87 | 941102-2 | FLAT WASHER 5 DIN125-A/GN420 |
| 88 | 233342-9 | COMPRES SPRING. 6 X HR2450 |
| 89 | 163430-7 | LOCK PLATE COMP BHR262/HR2450 |
| 90 | 345280-4 | HEX WASHER BHR262/HP1641/51 |
| 91 | 631471-6 | LIGHT CIRCUIT X HP2051F |
| 999 | 193606-2 | SERVICE KIT HR2020 |
| 1001 | 324219-0 | DEPTH GAUGE |
| 1002 | 824650-5 | PLASTIC CARRYING CASE |
| 1003 | 122573-4 | CHUCK ADAPTER ASS'Y |
| 1004 | 654091-9 | NON INSULATED TERMINAL GD0801 |
