Makita Spare Parts for 260MM Table Saw 2704N
€4.42
Tax included
Makita Spare Parts for 260MM Table Saw 2704N
We supply original MAKITA spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Contractors 15 Amp 10-Inch Benchtop Table Saw 2704N.- Dima side for precision cutting
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for 260MM Table Saw 2704N
We supply original MAKITA spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Contractors 15 Amp 10-Inch Benchtop Table Saw 2704N.
In the following table, look for the model of the Bench Saw and the respective parts of the code.
| Makita 2704N Table Saw Spare Parts | ||
| 2 | 268135-5 | SHOULDER PIN 10 2704 |
| 3 | 253758-2 | THIN HARD WASHER 10 BST220/KP |
| 4 | 418910-1 | *SUB COVER 2704 |
| 7 | 253758-2 | THIN HARD WASHER 10 BST220/KP |
| 8 | 961015-1 | EXT E-RING JIS JE9 1902/1219&L |
| 12 | 941151-9 | FLAT WASHER 6 DIN125-B BHS630 |
| 14 | 911138-5 | PAN HD SCREW M4X20 9032/LS081 |
| 15 | 931102-0 | HEX FULL NUT M4 DUR181/ML123 |
| 20 | 941151-9 | FLAT WASHER 6 DIN125-B BHS630 |
| 21 | 252014-7 | NYLON INSERT NUT M6-10 LS1013 |
| 23 | 345583-6 | LOCK LEVER 2704 |
| 24 | 951104-0 | TENSION PIN 4-12 DIN 1481 |
| 26 | 253731-2 | HARD WASHER 8 LS800D/DLS714 |
| 29 | 265995-6 | PT SCREW 4X18 UH4570/55/65/55 |
| 30 | 416341-8 | COVER 2702/2704 |
| 31 | 265995-6 | PT SCREW 4X18 UH4570/55/65/55 |
| 32 | 687054-0 | STRAIN RELIEF 3612C/5103R/411 |
| 33 | 643653-8 | BRUSH HOLDER CB-5 6 . 5=13 . 5 |
| 33 | 154602-5 | MOTOR HOUSING CO 2704 |
| 34 | 181044-0 | CARBON BRUSH CB-153 (CB-22)/9 |
| 35 | 643650-4 | BRUSH HOLDER CAP CB-5/HS6100 |
| 36 | 911383-2 | PAN HEAD SCREW M6X60 LS1030 |
| 37 | 266029-8 | PT SCREW 5X65 5703R |
| 37-1 | 266352-1 | TAPPING SCREW 5X65 SMA910/M90 |
| 38 | 654553-7 | CONNECTOR 34137 4157KB |
| 38 | 654020-2 | TERMINAL RING FOR FIELD CB-5 |
| 39 | 416331-1 | BAFFLE PLATE 2704/2702 |
| 40 | 211228-7 | BALL BEARING 6202DDW BO3710/1 |
| 42 | 518765-5 | ARMATURE 240V 2704 |
| 42 | 510070-6 | ARMATURE 110V 2704 |
| 43 | 681640-9 | INSULATION WASHER LS1040/F |
| 44 | 211088-7 | BALL BEARING 6000DDW |
| 45 | 253198-4 | SPECIAL WASHER 18 JS3200 |
| 46 | 261129-9 | URETHANE WASHER 18 2704 |
| 48 | 921331-3 | HEX BOLT M6X20 2704 |
| 53 | 922334-0 | HEX SOCKET HD BOLT M6X20 2704 |
| 54 | 344536-2 | GEAR HOUSING PLATE 2702/2704 |
| 55 | 911213-7 | PAN HEAD SCREW M5X12 ER2550 |
| 56 | 263005-3 | RUBBER PIN 6 DUR/DHR/DTW/DG |
| 57 | 323736-7 | GUIDE BAR 2704/2702 |
| 58 | 266040-0 | CT SCREW M4X25 |
| 59 | 416340-0 | GUIDE BAR RETAINER 2704/2704 |
| 63 | 211051-0 | BALL BEARING 609LLB BUC121/12 |
| 64 | 154595-6 | SPINDLE 2704 |
| 65 | 226602-6 | HELICAL GEAR 42 2704 |
| 66 | 267170-0 | FLAT WASHER 34 TW1000/2702 |
| 67 | 211278-2 | BALL BEARING 6203DDW RP0900/9 |
| 68 | 324556-2 | SPINDLE 2704 |
| 69 | 316933-2 | BEARING BOX 2704/2702 |
| 70 | 911233-1 | PAN HD SCREW M5X20 W/CP WASHER |
| 71 | 931502-4 | HEX FULLNUT M10 2708/LF1000 |
| 72 | 266040-0 | CT SCREW M4X25 |
| 73 | 322968-3 | SCREW BAR 2704/2702 |
| 74 | 961016-9 | EXT E-RING JIS JE-10 BHR262 |
| 75 | 416339-5 | SCREW BAR RETAINER 2702 |
| 76 | 941302-4 | FLAT WASHER 12 DIN125-A 2704 |
| 77 | 226747-0 | STRAIGHT BEVEL GEAR 2704/2702 |
| 78 | 951116-3 | TENSION PIN 4-20 DIN 1481 903 |
| 79 | 226747-0 | STRAIGHT BEVEL GEAR 2704/2702 |
| 80 | 941302-4 | FLAT WASHER 12 DIN125-A 2704 |
| 81 | 951116-3 | TENSION PIN 4-20 DIN 1481 903 |
| 82 | 324562-7 | LOCK LVER CONNECTOR 2704 |
| 83 | 253024-7 | FLAT WASHER 10 LS1013/LF1000 |
| 85 | 322967-5 | LOCK LEVER SHAFT 2704/2702 |
| 86 | 922232-8 | CAP HD SCREW M5X20 JS3200/CA |
| 87 | 931202-6 | HEX FULL NUT M5 RP0900/AN510 |
| 87 | 272248-6 | LEVER 120 2704 |
| 88 | 324563-5 | HANDLE SHAFT 2704 |
| 89 | 266034-5 | CT SCREW M4X16 HS6100/DLS714 |
| 90 | 253143-9 | NARROW WASHER 12 4110C |
| 91 | 213107-5 | O RING 12 JR3000/BFR540/550 |
| 92 | 253052-2 | NARROW THIN WASHER 12 TW100D |
| 93 | 214114-1 | PLANE BEARING 6410 |
| 94 | 345520-0 | STAY 2704 |
| 95 | 344543-5 | POINTER 2704/2702 |
| 96 | 922103-9 | CAP HD SCREW M4X6 |
| 97 | 271074-0 | ARM 60 2704 |
| 97 | 931202-6 | HEX FULL NUT M5 RP0900/AN510 |
| 99 | 251382-5 | PAN HD SCREW 2704 |
| 100 | 271423-1 | KNOB 32 2704 |
| 101 | 267010-2 | BLUE WASHER 5 JS1660/PM7651H |
| 102 | 240003-4 | FAN 80 HM1317C-CB/2702/LF1000 |
| 103 | 271073-2 | HANDLE 100 2704 |
| 105 | 252155-9 | HEX . NUT M12-19 2704 |
| 106 | 224401-0 | INNER FLANGE 53 2704 |
| 107 | 273523-3 | GRIP 2704 273523-3 . A2273523-3 |
| 108 | 345534-9 | HANDLE PLATE 2704 |
| 109 | 257161-9 | RING 4 2704 |
| 111 | 922116-0 | HEX SOCKET HD BOLT M4X12 2704 |
| 112 | 252130-5 | NYLON INSERT NUT M10X17 2414B |
| 113 | 941251-5 | FLAT WASHER 10 DIN125-B N1923 |
| 114 | 911223-4 | PAN HD SCREW 5X16 W/CP/DLS714 |
| 115 | 345539-9 | HANDLE PLATE HOLDER 2704 |
| 116 | 345534-9 | HANDLE PLATE 2704 |
| 117 | 257161-9 | RING 4 2704 |
| 118 | 941051-3 | FLAT WASHER 4 DIN125 - B BHX2 |
| 119 | 922116-0 | HEX SOCKET HD BOLT M4X12 2704 |
| 120 | 257753-4 | SLEEVE 10 2704 |
| 121 | 265536-8 | HEX BOLT M16X65 2704 |
| 122 | 273523-3 | GRIP 2704 |
| 123 | 265382-9 | HEX S HD BOLT M5X20 2704 |
| 124 | 324559-6 | HOOK RING 2704 |
| 125 | 233229-5 | COMPRESSION SPRING 8 2704 |
| 126 | 418655-1 | ROD HOLDER LS0714/FL/2704 |
| 127 | 418655-1 | ROD HOLDER LS0714/FL/2704 |
| 128 | 345535-7 | JOINT PLATE 2704 |
| 130 | 922116-0 | HEX SOCKET HD BOLT M4X12 2704 |
| 131 | 922116-0 | HEX SOCKET HD BOLT M4X12 2704 |
| 132 | 941051-3 | FLAT WASHER 4 DIN125 - B BHX2 |
| 133 | 257161-9 | RING 4 2704 |
| 134 | 324675-4 | ROD JOINT 2704 |
| 135 | 324673-8 | ROD R 2704 |
| 136 | 324674-6 | ROD F 2704 |
| 137 | 911128-8 | PAN HEAD SCREW M4X16 BHX2501 |
| 138 | 911128-8 | PAN HEAD SCREW M4X16 BHX2501 |
| 140 | 922116-0 | HEX SOCKET HD BOLT M4X12 2704 |
| 141 | 922116-0 | HEX SOCKET HD BOLT M4X12 2704 |
| 142 | 941051-3 | FLAT WASHER 4 DIN125 - B BHX2 |
| 143 | 257161-9 | RING 4 2704 |
| 144 | 324675-4 | ROD JOINT 2704 |
| 145 | 911128-8 | PAN HEAD SCREW M4X16 BHX2501 |
| 146 | 418655-1 | ROD HOLDER LS0714/FL/2704 |
| 147 | 911323-0 | PAN HD SCREW M6X16 LS1013 |
| 148 | 687049-3 | STRAIN RELIEF LF1000 |
| 149 | 251308-7 | PAN HD SCREW M4X10 3703 |
| 151 | 345628-0 | PLATE 2704/2702 |
| 152 | 416333-7 | RACK PLATE 2704/2702 |
| 153 | 911213-7 | PAN HEAD SCREW M5X12 ER2550 |
| 154 | 418655-1 | ROD HOLDER LS0714/FL/2704 |
| 155 | 233229-5 | COMPRESSION SPRING 8 2704 |
| 156 | 324559-6 | HOOK RING 2704 |
| 157 | 265382-9 | HEX S HD BOLT M5X20 2704 |
| 158 | 911128-8 | PAN HEAD SCREW M4X16 BHX2501 |
| 159 | 318020-3 | ADJUST BLOCK 2704 |
| 160 | 344529-9 | SLIDE SEAT 2704/2702 |
| 161 | 232174-1 | LEAF SPRING 2704 |
| 162 | 345535-7 | JOINT PLATE 2704 |
| 163 | 416439-1 | DUST GUIDE 2702/2704 |
| 164 | 266034-5 | CT SCREW M4X16 HS6100/DLS714 |
| 165 | 318253-0 | FRAME 2704 |
| 166 | 418917-7 | DUST JOINT 2704 |
| 167 | 266061-2 | CT SCREW M4X8 JN1601/DLS714 |
| 168 | 154599-8 | FRAME COVER CO 2704 |
| 169 | 911114-9 | PAN HD SCREW M4X10/DLS714 |
| 170 | 911333-7 | PAN HD SCREW M6X20 2414B/NB |
| 172 | 265460-5 | *HEX HD SCREW M6X20 |
| 174 | 266300-0 | TAPPING SCREW 4X18 LS1040F/HM |
| 175 | 413097-4 | SLIDE COVER 2704 |
| 176 | 266035-3 | CT SCREW M5X12 9031 |
| 177 | 418918-5 | SWITCH BOX 2704 |
| 179 | 265995-6 | PT SCREW 4X18 UH4570/55/65/55 |
| 180 | 687054-0 | STRAIN RELIEF 3612C/5103R/411 |
| 181 | 418912-7 | SWITCH BASE 2704 |
| 183 | 265995-6 | PT SCREW 4X18 UH4570/55/65/55 |
| 185 | 265995-6 | PT SCREW 4X18 UH4570/55/65/55 |
| 186 | 687053-2 | STRAIN RELIEF 110V UK360/HS61 |
| 190 | 266192-7 | TAPPING SCREW 4X14 VC3211M |
| 191 | 816844-6 | INNER SCALE PLATE 2704 |
| 192 | 251308-7 | PAN HD SCREW M4X10 3703 |
| 194 | 418908-8 | INNER RAIL END 2704 |
| 195 | 922146-1 | CAP HD SCREW M4X25 4300BA |
| 196 | 154705-5 | FRONT OUTER RAIL CO 2704 |
| 196 | 816843-8 | OUTER SCALE PLATE 2704 |
| 199 | 317877-9 | SUB TABLE 2704 |
| 202 | 158104-3 | FRONT INNER RAIL 2704 |
| 203 | 911233-1 | PAN HD SCREW M5X20 W/CP WASHE |
| 206 | 418907-0 | OUTER RAIL END 2704 |
| 207 | 265045-7 | PAN HD SCREW M5X18 2704 |
| 210 | 213023-1 | O RING 4 BPJ140/180/BURAT1827H |
| 212 | 266264-8 | GRUB SCREW M5X6 BPJ140/BPJ180 |
| 214 | 418907-0 | OUTER RAIL END 2704 |
| 215 | 911233-1 | PAN HD SCREW M5X20 W/CP WASHER |
| 216 | 317867-2 | REAR OUTER RAIL 2704 |
| 217 | 345529-2 | RAIL STOPPER 2704 |
| 218 | 251308-7 | PAN HD SCREW M4X10 3703 |
| 221 | 158103-5 | REAR INNER RAIL 2704 |
| 222 | 345533-1 | BASE FRONT COVER 2704 |
| 223 | 266192-7 | TAPPING SCREW 4X14 VC3211M |
| 225 | 911253-5 | PAN HD SCREW M5X30 W/CP WASHER |
| 226 | 922146-1 | CAP HD SCREW M4X25 4300BA |
| 227 | 418908-8 | INNER RAIL END 2704 |
| 228 | 286212-1 | CAP 20 LS1030/LC1230/LS800DWB |
| 229 | 154608-3 | BASE 2704 |
| 229 | 810107-2 | LABEL/CAUTION 2704 |
| 229 | 819176-0 | MAKITA LOGO PLATE 2704 |
| 230 | 265995-6 | PT SCREW 4X18 UH4570/55/65/55 |
| 231 | 687052-4 | STRAIN RELIEF HS7100/BO5041 |
| 231 | 687053-2 | STRAIN RELIEF 110V UK360/HS61 |
| 232 | 682504-0 | CORD GUARD HP1641/BO5031/HP16 |
| 232 | 682516-3 | CORD GUARD 9 . 3-85 MT814/815 |
| 233 | 692527-0 | LEAD WIRE HS7100/GD0801C/HP16 |
| 234 | 931302-2 | HEX FULL NUT M6 LF1000/DST111 |
| 235 | 271318-8 | KNOB 37 2704 |
| 236 | 941151-9 | FLAT WASHER 6 DIN125-B BHS630 |
| 237 | 921342-8 | HEX HD SCREW M6X25/LF1000 |
| 238 | 271320-1 | KNOB 37 2704 |
| 239 | 252197-3 | HEX NUT M14 2704 |
| 240 | 421926-7 | HOLDER 2704 |
| 241 | 931402-8 | HEX FULLNUT M8 LS1013/HR1840 |
| 242 | 253797-2 | HARD NARROW WASHER 14 HR2210 |
| 243 | 265537-6 | HEX BOLT M14X65 2704 |
| 244 | 921462-8 | HEX HD SCREW M8X40 9031 |
| 246 | 911344-2 | PAN HD SCREW M6X25 2702 |
| 310 | 257262-3 | RING 16 LS1214/LS1013/LS1040 |
| 311 | 262559-7 | SLEEVE 14 2704 |
| 312 | 345536-5 | BASE UNDER COVER 2704 |
| 313 | 266192-7 | TAPPING SCREW 4X14 VC3211M |
| 315 | 418618-7 | PIN LH1040/F/LF1000 |
| 316 | 418616-1 | SWITCH BUTTON ON LH1040/F |
| 317 | 443103-1 | FELT RING 6 LH1040/F/LF1000 |
| 318 | 443103-1 | FELT RING 6 LH1040/F/LF1000 |
| 319 | 231025-5 | COMPRESSION SPRING 8 PS32TLC |
| 320 | 231025-5 | COMPRESSION SPRING 8 PS32TLC |
| 321 | 253186-1 | THIN WASHER 7 HR160D/LF1000 |
| 322 | 253186-1 | THIN WASHER 7 HR160D/LF1000 |
| 323 | 418617-9 | SWITCH BUTTON OFF LH1040/FLF1 |
| 324 | 652772-9 | RELAY 305 . 232 . 01 240V LS1040 |
| 325 | 631612-4 | SOFT START CIRCUIT 110V LS10 |
| 326 | 654561-8 | TERMINAL BLOCK 2012NB/LH1040 |
| 327 | 645089-7 | NOISE SUPPRESSOR GD0801C/0811 |
| 327 | 645006-7 | NOISE SUPPRESSOR/CONDENSOR 64 |
| 328 | 645105-5 | NOISE SUPPRESSOR/CONDENSOR 64 |
| 329 | 646049-2 | CHOKE COIL HR2420/JR3060T/307 |
| 331 | 317879-5 | SLIDE ROD HOLDER 2704 |
| 332 | 324564-3 | REAR ROD 2704 |
| 333 | 345537-3 | REAR TABLE 2704 |
| 334 | 922221-3 | CAP HD SCREW M5X16 HM1200 |
| 335 | 931502-4 | HEX FULLNUT M10 2708/LF1000 |
| 336 | 961016-9 | EXT E-RING JIS JE-10 BHR262 |
| 337 | 911233-1 | PAN HD SCREW M5X20 W/CP WASHER |
| 341 | 253010-8 | LARGE FLAT WSHER 6 5100BR |
| 342 | 252014-7 | NYLON INSERT NUT M6-10 LS1013 |
| A02 | 419093-0 | JOINT 2704 |
| A04 | 781038-1 | WRENCH 19 2704 |
| A05 | 782024-5 | WRENCH 13-22 2704 |
| A06 | 783203-8 | HEX WRENCH 5 BHS630/PC5000/01C |
| A07 | 127069-0 | *ANGLE RULE ASSY 2704 |
| A08 | 122739-6 | RULER ASSY 2704 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita 2704N
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- MORE INFO:
- info@bricoutensili.com
New
You might also like
Comments (0)
No customer reviews for the moment.
Viewed products
Customers who bought this product also bought:
16 other products in the same category:
Makita Spare Parts for 260MM Table Saw 2704N
We supply original MAKITA spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Contractors 15 Amp 10-Inch Benchtop Table Saw 2704N.- Dima side for precision cutting
