Makita Spare Parts for Demolition Hammer HM1100C
€1.44
Tax included
Makita Spare Parts for Demolition Hammer HM1100C
We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Demolition Hammer SDS MAX HM1100C.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Demolition Hammer HM1100C
We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Demolition Hammer SDS MAX HM1100C.
In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| HM1100C - DEMOLITION HAMMER 1050W SDS-MAX | ||
| # | Part Num. | Description |
| 1 | 962154-0 | RETAINING RING X HM1100C |
| 2 | 213479-8 | O-RING 33 X HM1100C |
| 3 | 322982-9 | TOOL HOLDER X HM1100C |
| 4 | 322908-1 | ROLLER 8 X HM1100C |
| 5 | 322882-3 | TOOL HOLDER SUPPORT X HM1100C |
| 6 | 922351-0 | HEX SOCKET HEAD BOLT M6 X 30 X HM1100C |
| 7 | 216041-8 | STEEL BALL 5.6 |
| 8 | 416086-8 | SIDE HANDLE SUPPORT X HM1 |
| 9 | 231972-0 | RING SPRING 52 X HM1100C |
| 10 | 213554-0 | O-RING 44 HR2210 / 20/3510 |
| 11 | 416087-6 | CHANGE RING X HM1100C |
| 12 | 331489-4 | STEEL BALL GUIDE HM1100C |
| 13 | 233167-1 | COMPRESSION SPRING 44 X HM1100C |
| 15 | 416085-0 | TOOL HOLDER COVER X HM1100C |
| 16 | 213270-4 | X RING 18 X HM1100C / 4000 |
| 17 | 286246-4 | TOOL HOLDER CAP X HM1100/1100C |
| 18 | 213269-9 | X RING 17 X HM1100C2400 |
| 19 | 213311-6 | O RING 19 X HM1100C |
| 20 | 323845-2 | IMPACT BOLT X HM1100C |
| 21 | 331487-8 | IMPACT BOLT GUIDE X HM1100C |
| 22 | 421570-0 | RING 36 X HM1100C |
| 23 | 213391-2 | RING 25 X HM1100C |
| 24 | 331488-6 | SLEEVE GUIDE X HM1100C |
| 25 | 213554-0 | O-RING 44 HR2210 / 20/3510 |
| 26 | 415698-4 | HOUSING COVER ASSY X HM P20 |
| 27 | 322757-6 | CYLINDER LINER 34 X HM1100C |
| 29 | 213614-8 | O-RING 50 X HM1100C |
| 30 | 331486-0 | SLEEVE 39 X HM1100C |
| 31 | 233190-6 | COMPRESSION SPRING 39 X HM1100 / C |
| 32 | 267156-4 | FLAT WASHER |
| 33 | 231971-2 | RING SPRING 36 X HM1100C |
| 34 | 322907-3 | STRIKER X HM1100C |
| 35 | 213429-3 | O-RING 27 X HM1100C |
| 36 | 316672-4 | BARREL X HM1100C |
| 37 | 922341-3 | HEX SOCKET HEAD BOLT M6X25 |
| 38 | 213606-7 | O-RING 48 HR3850 / B / HR2510 |
| 39 | 213429-3 | O-RING 27 X HM1100C |
| 40 | 256165-8 | PIN 8 HM0810 |
| 41 | 415773-6 | PISTON X HM1100C |
| 42 | 213415-4 | O-RING 28 X HM1100C |
| 43 | 415689-5 | ROD X HM1100C |
| 44 | 415699-2 | SWITCH BOX X HM1100C |
| 45 | 263002-9 | RUBBER PIN 4 |
| 46 | 417447-5 | CONTROLLER COVER |
| 47 | 415692-6 | STOPPER X HM1100 |
| 48 | 421507-7 | HANDLE X HM1100C |
| 49 | 266135-9 | HEX SOCKET HEAD BOLT M6X9O X HM1100C |
| 50 | 922371-4 | HEX SOCKET HEAD BOLT M6X50 |
| 51 | 415691-8 | SWITCH LEVER X HM1100C |
| 52 | 213107-5 | O-RING 12 JR3000 / V |
| 53 | 651481-7 | SWITCH STE215K X HM1100C |
| 54 | 211033-2 | BALL BEARING 608SS (LLB) HR2010 |
| 55 | 681650-6 | INSULATION WASHER X HR4000C |
| 56 | 516288-7 | ARMATURE ASSY X HM1100C |
| 57 | 241876-8 | FAN 76 |
| 58 | 213160-1 | OIL SEAL 14 XHR3850 / B |
| 59 | 211129-9 | BALL BEARING 6201DD NSK |
| 61 | 134875-6 | CRANK HOUSING X HM1100C |
| 62 | 213720-9 | O-RING 67 |
| 63 | 210054-1 | BALL BEARING X HM1100C |
| 64 | 962105-3 | RETAINING RING R26 |
| 65 | 212259-9 | NEEDLE BEARING 2116 X HM1100C |
| 66 | 153249-2 | CRANK SHAFT |
| 67 | 216116-3 | INNER SLEEVE 812 HM1100C |
| 68 | 415690-0 | CRANK CAP X HM1100C |
| 69 | 252640-2 | WING NUT M8 X |
| 70 | 417002-3 | HANDLE RING HM1202C |
| 71 | 152620-7 | SIDE HANDLE CPL 60 |
| 72 | 417002-3 | HANDLE RING HM1202C |
| 73 | 265439-6 | HEX BOLT M8X150 X HM1100C |
| 74 | 417003-1 | SIDE HANDLE X HM1202C |
| 75 | 415693-4 | BAFFLE PLATE X HM1100C |
| 76 | 632678-7 | SUPPORT X HM1100C |
| 77 | 631204-9 | CONTROLLER X HM1100C |
| 78 | 265995-6 | TAPPING SCREW M4X18 X 6408 / 6221DW |
| 79 | 687063-9 | STRAIN RELIEF X 4304T |
| 80 | 417715-6 | FIX ROD |
| 81 | 682560-0 | CORD GUARD X HM1202C / 9079S |
| 83 | 266021-4 | TAPPING SCREW 5X20 |
| 84 | 415700-3 | REAR COVER X HM1100C |
| 85 | 643750-0 | BRUSH HOLDER CAP |
| 86 | 191961-6 | CARBON BRUSH SET CB 304 X HM1100C |
| 87 | 922364-1 | HEX SOCKET HEAD BOLT M6X40 |
| 89 | 152662-1 | MOTOR HOUSING X HM1100C |
| 90 | 263014-2 | RUBBER PIN 4 |
| 91 | 634283-6 | FIELD X HM1100C |
| 92 | 265345-5 | HEX BOLT M5X20 X HM1100C |
| 93 | 645006-7 | NOISE SUPPRESSOR X LS1013 |
| 94 | 213385-7 | O-RING 24 X HR2400 |
| 95 | 134909-5 | SIDE HANDLE ASSY HM1200 / 1100 |
| 999 | 193243-2 | SERVICE KIT HM1100 / C |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
