Makita Spare Parts for Jigsaw 4329

€12.95
Tax included

Makita Spare Parts for Jigsaw 4329

We have the original Makita Parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.

Fix Your Jigsaw 4329. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 152600-3
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Jigsaw 4329

Fix Your Jigsaw 4329. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of jackhammers and the respective parts of the code.
Makita 4329

Jigsaw 4329
# Part Num. Description
2 645239-4 CAPACITOR 4326
3 651286-5 SWITCH
7 233151-6 SPRING 4 X 4304T X 4305T
8 216008-6 STEEL BALL 4
9 961011-9 RETAINER RING E4
10 272239-7 LEVER X 4324
11 188338-4 MOTOR CASING X 4329
12 643562-1 BRUSH HOLDER MT601
13 191627-8 CARBON BRUSH CB-64 (56.57)
14 620411-9 REGULATOR FOR 4327
15 210025-8 BEARING X 4324
16 515718-5 ARMATURE X 4326
17 241881-5 FAN 52 X 6408
18 210005-4 BALL BEARING 608 DDW
19 152600-3 GEAR BOX CPL 4324
20 344683-9 PUSH PLATE X 4324
21 344614-8 PLATE 4322
22 256254-9 PIN X 4322
23 153260-4 GEAR X 4324
24 213038-8 GASKET 4322
25 313082-6 SLIDE GUIDE 4322
26 213038-8 GASKET 4322
27 344613-0 SLIDER 4322
28 232183-0 BAND SPRING X 4324
29 922107-1 BOLT M4X8
30 323748-0 PROTECTION 4322
31 416476-5 DUST COVER 4322
32 313140-8 BLADE CLAMP 4326
33 313086-8 CURSOR SUPPORT X 4324
34 423307-1 URETANE SPONGE X 4322
35 344686-3 SAFETY PLATE 4324
36 266177-3 M3X10 6914DW BOLT
37 257683-9 SLEEVE X 4322
38 961002-0 RETAINING RING S6
39 416703-0 DUST COVER X 4324
41 633658-6 STATOR X 4326
42 158392-2 BLADE GUIDE X 4329
43 256117-9 PIN X 4324
44 343540-8 CLAMP X 4320
45 317796-9 BASE FOR 4329
46 345441-6 BASIC PLATE X 4329
47 912107-9 SCREW M4X8
48 344685-5 STATIONARY BASE PLATE X 4324
49 922128-3 M4X16 4300BA BOLT
50 265995-6 SCREW M4X18 X 6408 / 6221DW
51 266048-4 SCREW M 4 X 40 X 4334D
52 863970-2 LABEL MOD. 4329
53 682569-2 CORD GUARD CMT601
54 687124-5 STRAIN RELIEF MT953
55 265995-6 SCREW M4X18 X 6408 / 6221DW
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
