Makita Spare Parts for Cordless Rotary Hammer Drill DHR164Z
search
  • Makita Spare Parts for Cordless Rotary Hammer Drill DHR164Z
  • Makita Spare Parts for Cordless Rotary Hammer Drill DHR164Z

Makita Spare Parts for Cordless Rotary Hammer Drill DHR164Z

€33.39
Tax included

Makita Spare Parts for Cordless Rotary Hammer Drill DHR164Z

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Cordless Rotary Hammer Drill DHR164Z.
ITEM CODE: 154840-9
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Cordless Rotary Hammer Drill DHR164Z

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Cordless Rotary Hammer Drill DHR164Z

In the following table, look for the model of the Cordless Rotary Hammer Drill and the respective parts of the code.
Makita DHR164Z

Cordless Rotary Hammer Drill DHR164Z
# Part Num. Description
1 286263-4 CAP 35 X HR2020
2 233940-9 SPRING RING 19 FOR HR2432
3 419220-9 CHUCK COVER X HR1830
4 257241-1 RING 21 X HR2020
5 345187-4 GUIDE WASHER X HR2020
6 233916-6 SPRING 21-29 X HR2020
7 921923-8 SCREW M 8 X 120 X HR2020
8 417911-6 BASE HANDLE X HR1830
9 158057-6 HANDLE 36 CPL HR2230
10 266048-4 SCREW M 4 X 40 X 4334D
11 162242-5 CPL CHANGE LEVER X HR1830
12 233459-8 COMPRESSION SPRING 3 HR1830
13 455413-4 BUTTON
14 213278-8 RING 13 X HR2020
15 213535-4 OIL SEAL 25
16 211375-4 BALL BEARING 6805LLB 6221D
17 211012-0 BEARING X 9524NB
18 154840-9 GEAR BOX HR1830
19 961135-1 RING RING W25
20 267304-5 WASHER 25 HR1830
21 233457-2 COMPRESSION SPRING 25 HR1830
22 331707-0 GEAR 46 HR1830
26 154843-3 TOOL HOLDER HR1830
27 216022-2 BAL 7
28 213183-9 RING 13 HR1830
29 324611-0 IMPACT BOLT HR1830
30 257275-4 RING 11 HR1830
31 233942-5 SPRING RING 22
32 267175-0 FLAT WASHER 24 6914DW
33 345681-6 FLANGE HR1830
34 324613-6 STRIKER X HR1830
35 213182-1 RING 14 X HR1830
36 331708-8 PISTON HR1830
37 267130-2 SPRING WASHER 9 HR2410
38 324612-8 PISTON PIN X HR1830
39 267130-2 SPRING WASHER 9 HR2410
40 227152-4 GEAR 10 HR1830
41 331706-2 CLUTCH CAM HR1830
42 219019-0 SWASH BEARING 9 HR1830
43 226623-8 GEAR 22 FOR BHR162
44 423346-1 SEAL RING X HR1830
45 233458-0 COMPRESSION SPRING 32 HR1830
46 268147-8 PIN 4 HR1830
47 443123-5 FELT 4X3 FOR HR1830
48 345645-0 CHANGE PLATE HR1830
49 233460-3 COMPRESSION SPRING 3 HR1830
50 345654-9 STOPPER PLATE FOR HR1830
51 211012-0 BEARING X 9524NB
52 154841-7 INNER HOUSING X HR1830
53 213953-6 RING 24 HR2430
54 619182-3 ARMATURE FOR BHP162
55 911011-9 SCREW M3X10
57 638446-6 YOKE UNIT BHR162
58 632D97-1 BRUSH HOLDER
59 419457-8 CHANGE LEVER FOR BHR162
61 424128-4 COVER CAP FOR BHR202R
63 643929-3 CAP BRUSH X 6213 / 6203DW
64 191971-3 CARBON BRUSH CB-430
65 632D93-9 SWITCH
67 265995-6 SCREW M4X18 X 6408 / 6221DW
68 183A24-8 HOUSING
69 620366-8 LIGHT CIRCUIT
71 643867-9 BATTERY TERMINAL BJR141
72 689098-6 HEAT SINK X 6503D
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
