Makita Spare Parts for Cordless Rotary Hammer Drill DHR242RMJ
€1.36
Tax included
Makita Spare Parts for Cordless Rotary Hammer Drill DHR242RMJ
Makita Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Cordless Rotary Hammer Drill DHR242RMJ.Fix Your Rotary Hammer. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Cordless Rotary Hammer Drill DHR242RMJ
Makita Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Cordless Rotary Hammer Drill DHR242RMJ.
In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| Cordless Rotary Hammer Drill DHR242RMJ | ||
| # | Part Num. | Description |
| 1 | 286288-8 | CAP 35 HR2601 |
| 2 | 233989-9 | RING SPRING 14 HR2601 |
| 3 | 346834-0 | WASHER 16 X HR2631F |
| 4 | 233992-0 | RING SPRING 15 HR2601 |
| 5 | 267114-0 | FLAT WASHER 17 X 8412DWH |
| 6 | 424364-2 | RUBBER WASHER 16 HR2601 |
| 7 | 451533-2 | FRONT COVER HR2601 |
| 8 | 325813-1 | RING 21 HR2601 |
| 9 | 346177-0 | GUIDE WASHER HR2601 |
| 10 | 233916-6 | SPRING 21-29 X HR2020 |
| 11 | 266745-2 | SCREW M8X90 BHR242RFE |
| 12 | 453129-5 | GRIP BASE BHR242RFE |
| 13 | 158057-6 | GRIP 36 CPL HR2230 |
| 14 | 266351-3 | SCREW 4 X 35 X 9557PB |
| 15 | 144354-6 | GEAR BOX BHR242RFE |
| 16 | 331890-3 | CUP SLEEVE HR2601 |
| 17 | 211294-4 | BALL BEARING 6806LLU HR2601 |
| 18 | 454112-5 | LOCK BUTTON BHR242RFE-243 |
| 19 | 233459-8 | COMPRESSION SPRING 3 HR1830 |
| 20 | 453131-8 | GEARBOX COVER BHR242RF |
| 21 | 453125-3 | CHANGE LEVER BHR242RFE |
| 22 | 213381-5 | O-RING 21 NEW HR3510 / 20 |
| 23 | 253308-3 | WASHER 6 43SB / 6510B-2 / 5016N |
| 24 | 234147-0 | COMPRESSION SPRING 5 HR2601 |
| 25 | 326850-8 | PUSH CORN HR2601 |
| 26 | 233360-7 | COMPRESSION SPRING 4 X MT952 |
| 27 | 346537-6 | LOCK PLATE BHR242RFE |
| 28 | 216022-2 | STEEL BALL 7 |
| 29 | 216019-1 | STEEL BALL 3 X DHR24 * / HR26 ** |
| 30 | 140265-3 | TOOL HOLDER HR2601 |
| 31 | 332139-4 | FLANGE HR2601 |
| 32 | 227360-7 | GEAR 51 HR2601 |
| 35 | 234148-8 | COMPRESSION SPRING 31 HR2601 |
| 36 | 267153-0 | WASHER 30 HR2601 |
| 37 | 257932-4 | LOCK WASHER 30 HR2601 |
| 38 | 267153-0 | WASHER 30 HR2601 |
| 39 | 325783-4 | SLEEVE 9B HR2601 |
| 40 | 325789-2 | IMPACT BOLT HR2601 |
| 41 | 325792-3 | WASHER 10 HR2601 |
| 42 | 234149-6 | COMPRESSION SPRING 20 HR2601 |
| 43 | 325793-1 | SUPPORT RING B HR2601 |
| 44 | 213073-6 | O-RING 9 X HR2020 |
| 45 | 233979-2 | SPRING RING 28 HR2601 |
| 46 | 326139-4 | STRIKER BHR242RFE |
| 47 | 213258-4 | O-RING 17.5 X HR2210 / 20 |
| 48 | 310345-1 | PISTON CYLINDER HR2601 |
| 49 | 346036-8 | GUIDE PLATE BHR261D |
| 50 | 324215-8 | PISTON PIN X HR2020 |
| 51 | 234098-7 | COMPRESSION SPRING 14 BHR261D |
| 52 | 267447-3 | WASHER 14 HR2601 |
| 53 | 211012-0 | BEARING X 9524NB |
| 54 | 257336-0 | STOP RING EXT U-6 |
| 55 | 253186-1 | FLAT WASHER 7 X 420S |
| 56 | 227231-8 | GEAR 10 HR2611FT |
| 57 | 326849-3 | CLUTCH CAM TO HR2611FT |
| 58 | 326140-9 | SHAFT BHR242RFE |
| 59 | 219020-5 | SWASH BEARING 10 HR2601 |
| 60 | 227588-7 | GEAR 32 BHR242RFE |
| 61 | 257323-9 | O-RING 8 BHR242RFE |
| 62 | 266273-7 | SCREW 4 X 12 X 4604D |
| 63 | 346038-4 | BEARING RETAINER B BHR261D |
| 64 | 211032-4 | BEARING X 1902 |
| 65 | 324212-4 | RING 8 X HR2020 |
| 66 | 922147-9 | SCREW M4X25 |
| 67 | 141230-5 | SUPPORT BHR242RFE |
| 68 | 213767-3 | RING 75 BHR242RFE |
| 69 | 318810-4 | INNER HOUSING BHR242RFE |
| 70 | 443153-6 | FELT HR2601 |
| 71 | 266273-7 | SCREW 4 X 12 X 4604D |
| 72 | 346536-8 | RETAINER BEARING TO BHR242RFE P02 |
| 73 | 256536-9 | PIN 6 BHR242RFE |
| 74 | 346538-4 | WEIGHT HOLDER GUIDE BHR242RF P01 |
| 75 | 313224-2 | COUNTER WEIGHT BHR242RFE |
| 76 | 346538-4 | BALANCER SUPPORT BHR242RF P01 |
| 77 | 253726-5 | FLAT WASHER 6 |
| 78 | 961018-5 | EXT E-RING JIS JE-5 |
| 79 | 213008-7 | RING 26 |
| 80 | 141458-5 | GEAR 11 BHR242RFE |
| 81 | 210024-0 | BEARING X HR5001C |
| 82 | 253835-0 | WASHER 8 |
| 83 | 619293-4 | ARMATURE ROTOR BHR242RFE |
| 84 | 210143-2 | BEARING 626ZZ |
| 85 | 529187-4 | STATOR FIELD ASSEMBLY BHR242RFE |
| 86 | 620241-8 | CONTROLLER DHR242RFE |
| 87 | 183C02-0 | HOUSING DHR242 |
| 90 | 266326-2 | SCREW 4X18 X MT601 |
| 92 | 453124-5 | SWITCH LEVER BHR242RFE |
| 93 | 453123-7 | BHR242RFE SWITCH LEVER |
| 94 | 650709-0 | C3JW-AP SWITCH |
| 95 | 233598-4 | TORSION SPRING 6 BHR242RFE |
| 96 | 313226-8 | LEVER BHR242RFE |
| 97 | 644809-6 | TERMINAL X BLS713-BHP451 |
| 98 | 424476-1 | RUBBER BHR242RFE |
| 99 | 187377-1 | BHR242RFE BATTERY SUPPORT |
| 100 | 263036-2 | RUBBER PIN 5 X BTW251 |
| 101 | 268184-2 | SPINOT 1.5 BTW251 |
| 102 | 424473-7 | BHR242RFE DAMPER |
| 103 | 424473-7 | BHR242RFE DAMPER |
| 104 | 424734-5 | SPONG DHR242 |
| 999 | 195833-7 | SERVIVE KIT BHR242 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
