at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Impact Wrench TW1000.
In the following table, look for the model of Impact Wrench and the respective parts of the code.![]()
| Impact Wrench TW1000 | ||
| 1 | 421895-2 | PROTECTION X TW1000 |
| 2 | 154555-8 | CARCASS ELASTIC RING X TW1000 |
| 3 | 256253-1 | PIN 5 X 6908DW |
| 4 | 253909-7 | WASHER 35 |
| 5 | 231921-7 | SNAP RING 22 |
| 6 | 325587-4 | ANVIL |
| 7 | 325415-3 | ELASTIC RING |
| 8 | 216002-8 | BALL 4.8 |
| 9 | 253712-6 | WASHER 36 X 9554NB |
| 10 | 231211-8 | SPRING COMP. 36 |
| 11 | 333112-7 | RING 79 X TW1000 |
| 12 | 216010-9 | BALL 10.3 X TW1000 |
| 13 | 324666-5 | POST |
| 14 | 227149-3 | GEAR 37 X TW1000 |
| 15 | 256051-3 | PIN 10 |
| 16 | 221815-4 | GEAR 82 |
| 17 | 267170-0 | WASHER 34 X 2702 |
| 18 | 310154-8 | BEARING BOX X TW1000 |
| 19 | 213459-4 | SEAL 32 X HR3850B |
| 20 | 213855-6 | SEAL 95 X HM1400 |
| 21 | 317841-0 | HOUSING COVER ELASTIC RING |
| 22 | 211137-0 | BEARING 6201LLU X HM0860C |
| 23 | 240003-4 | FAN X 2702 |
| 24 | 516919-8 | ARMATURE X TW1000 |
| 25 | 681665-3 | INSULATING WASHER X TW1000 |
| 26 | 211066-7 | BEARING HM1301 - 6200 |
| 27 | 265345-5 | SCREW M5X20 X HM1100C |
| 28 | 418814-7 | VANE X TW1000 |
| 29 | 528940-5 | STATOR X TW1000 |
| 30 | 154556-6 | HOUSING MOTOR X TW1000 |
| 31 | 263005-3 | PIN RUBBER 6 |
| 32 | 345517-9 | PLATE X TW1000 |
| 33 | 266157-9 | SCREW M 6 X 12 X TW1000 |
| 34 | 282018-5 | RING X TW1000 |
| 35 | 941151-9 | WASHER 6 X HM1303 |
| 36 | 265538-4 | SCREW M6 X 60 X TW1000 |
| 37 | 421896-0 | REAR X TW100 |
| 38 | 183935-1 | GRIP X TW1000 |
| 39 | 911233-1 | HEAD SCREW M5X20 3600H |
| 40 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 41 | 421897-8 | PROTECTION GRIP TW1000 |
| 42 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 43 | 687052-4 | CLAMP Cable tie X 6408 |
| 44 | 654531-7 | CLAMP X 420S |
| 45 | 682564-2 | SLEEVE FOR CABLE X KP312S |
| 48 | 263005-3 | PIN RUBBER 6 |
| 49 | 645253-0 | CAPACITOR X 6408 |
| 50 | 685722-9 | SPONGE X 4302C |
| 51 | 646755-9 | RESISTANCE X DA6301 |
| 52 | 685725-3 | SPONGE X UH3000 |
| 54 | 181044-0 | CARBON BRUSHES CB-153 (CB-152.154) |
| 55 | 643650-4 | PLUG BRUSH |
| 56 | 651572-4 | SWITCH SL220SD-19 |
| 57 | 685725-3 | SPONGE X UH3000 |
| 58 | 231212-6 | SPRING COMP. 49 |
| 59 | 253713-4 | FLAT WASHER 35 |
